- Page 1 LCD-703HD Series High Definition 7.0” TFT LCD Monitor Model : LCD-703HD (Stand Alone) Model: LCD-703HD2 (19” Rack Mount unit) www.totevision.com...
- Page 2 LCD-703HD Series features our completely Digital million pixel TFT LCD high resolution screen, excellent color reproduction. Analog signals are digitized using an advanced 10 bit process with 4x over sampling and adaptive 5 line comb filter plus exacting color space conversion. Video is scaled to fit on screen in the highest resolution using a state of the art Triple gate technology LCD panel that incorporates with precision Gamma correction to product the best images available.
- Page 3 Power Consumption 1. Overview The LCD-703HD Series represents a state of art LCD display technology in broadcast and professional video applications. This is a low cost stand alone monitor and is constructed with a VESA holes and 1/4-20 or flanges for 19” Rack mount option.
-
Page 4: Electrical Specifications
S-Video (Y/C) (4 pin mini din female) DVI, RS-232/TALLY (DB-9 Female) S-Video (Y/C) (4 pin mini din female) Component Video (3 BNC) Composite Video (BNC) LCD-703HD 174x133x35 5-20 VDC, Approx. 5 Watts -20° C to 60° C Ambient -30° C to 80° C... -
Page 5: Operational Setup
Vehicle power. Input power range is 5.0 to 20 Volt D.C. In operation, the LCD-703HD will draw approx. 0.4 amp. @ 12VDC. 4. Turn on the LCD-703HD by tapping the power switch located on the front of the unit. - Page 6 RS-232 TALLY TALLY SYSTEM - The tally system on the LCD-703HD is accessed via the DB-09 connector on the back of the unit labeled ‘RS-232/TALLY’. The system works by closing the contacts between the ground pin and the corresponding LED pin. The system is self powered, DO NOT GIVE POWER TO THE PINS.
- Page 7 Applicable signal format Signals Frames per Second 30/29.97 525-60i 480i 60/59.94/50 625-50i 480P 60/59.94/50/30/29.97 /25/24/23.976 720P 60/59.94/50/30/29.97 /25/24/23.976 1035i 60/59.94 1080i 60/59.94/50/48/47.96 1080P 30/29.97/25/24/23.976 Switch Settings, Functions and Indicators CVBS, S-Video, YPrPb and DVI select input source and LED on when active. Mode : select under scan or normal mode Note: Tapping any active input signal toggles BLUE GUN On/Off.
- Page 8 Model numbers of LCD-703HD Series LCD-703HD LCD-703HDL LCD-703HDX LCD-703HDL back LCD-703HD1 (single unit) LCD-703HD2 (two units)
