Tote Vision LCD-642 Specification Sheet

The Biggest Thing in
Little LCD Monitors
LCD- 642
monitor with 2 Video inputs
and LED indicators
Active Matrix 6.4"
Color LCD Monitor
• Slim space saving design
• For color and B&W applications
• Low power consumption
• Case made of durable ABS plastic
• Compact and light weight for easy installation or mobile use
• Active matrix technology allows wide viewing angle
• Active matrix technology eliminates distortion
• A/C adaptor Part No. AC-2000 included
• For LCD-642 mirror image capable
(order optional Part No. LCD-642RCBL)

Optional Accessories

BB-5000 Metal bracket for Anton-Bauer battery for LCD-642
BP-563 Rechargeable 2600mAH battery pack
Provides approximately 5 hrs. of operation
DC-12 Car Cord
DC-12D Dual Car Cord
HS-1 Hot Shoe mount
LCD-642RCBL Cable to affect mirror image for LCD-642
LM-642 Flush mount kit, black metal
9.1"(W) x 8.3"(H) x 0.8"(D)
Installer's Cut-Out: 7.1" (W) x 5.4" (H)
MB-1 Desk Stand (shown above)
MB-72M Mounting Brackett
RM-642 Dual rack mount panel, black metal
19"(W) x 7"(H) x 1.5"(D) (occupies 4 RU)
• Included with LCD-642D rack mount kit order
TB-640 Custom Totebag with sunshield for LCD-640
WM-1 Wall mount bracket
For LCD-642D only.
GS-07F-0069L, SIN: 246-42(1), 246-50
Specifications subject to change without notice
Available through:
P.25
Shown with
MB-1 optional
desk stand
LCD- 640
monitor with audio
©2008 ToteVision 30K
LCD- 642D Dual 19" Rack Mount Unit
Display:
Back Light:
Input Signal:
Dot Format:
Dot Pitch:
Brightness rating:
Number of Pixels:
Contrast Ratio:
Pixel Configuration:
Power Requirements:
Power Consumption:
Input Signal Level:
LCD-640: Audio IN:
LCD-640: Audio output:
LCD-640: Speakers:
Viewing angle (L/R/T/B):
Dimensions (WHD):
Actual visible screen size (WH):
Monitor Mounting:
Operating temperature:
Connections:
Weight:
1319 Dexter Ave. N. • Ste. 020 • Seattle, WA 98109
Tel: 206-623-6000 • FAX: 206- 623-6609
LCD-642
LCD-642D
LCD-640
LCD-642 shown with
Flush Mount Kit
6.4" TFT LCD active matrix
Built-in CCFT
NTSC/ PAL (auto switching)
960(H) x 234(V) dots
0.416mm(H) x 0.136mm(V)
LCD-642: 250 cd/m² (Nit)
LCD-640: 300 cd/m² (Nit)
224,640 dots
150 : 1
Stripe
12~24 VDC(ripple 0.5V p-p),1000mA,+ pin
8 W (max)
1.0V P-P (positive) 75 Ohm
100 ~ 300mv (RMS)
0.4W
1.5"
45/45/10/30 degrees
LCD-642: 180 x 135 x 35mm / 7.1" x 5.3" x 1.4"
LCD-640: 175 x 140 x 35mm / 6.8" x 5.5" x 1.4"
130 x 98mm / 5.2" x 3.9"
mounting pad with ¼ -20 threaded socket
50~104°F or 10~40°C
DIN cable w/ 2 RCA video IN jacks (LCD-642),
DIN cable w/ BNC video and RCA audio (LCD-640),
2.1mm DC IN jack
LCD-642D: Net: 4.7 kg. / 10.4 lbs. Gross: 5.4 kg. / 12 lbs.
LCD-642: Net: 500g/17.5oz. Gross: 1.4 kg. / 3.1 lbs.
LCD-640: Net: 0.6 kg. / 1.2 lbs. Gross: 1.2g. / 2.6 lbs.
