Tote Vision LCD-5200HD Specification Sheet

• True HD displays 1080p/i without down scaling
(also supports 480p/i, 576p/i, 720p)
• PIP: Picture in picture capability
• 2 detachable speakers provide 3D MTS stereo
• Surround sound experience with SRS technology
• User- selected color temperature (9300º, 7500º, 6500º)
with no video oscillations
• Hard anti-glare coating enhances viewing
• Composite, S-Video, component, DVI, PC, HDMI
• Top controls for channel up/down, volume up/down, source, and menu
• Black case made of durable ABS plastic
• Wide viewing angle
• Active matrix technology eliminates distortion
• Built-in removable desk stand
• Built-in power supply 110~240 VAC
• IR remote control works within 30 feet
• RS-232 serial port control
• 180º rotation display option
• Widescreen 16:9 aspect ratio, 4:3 zoom
• Environmentally safe: RoHS compliant, no x-radiation,
power- saving feature
47" Free-standing HD LCD Monitor is also available
Model # LCD- 4700HD:
Resolution:
Brightness rating:
Contrast Ratio:
Optional Accessories
WM- 4700VT Heavy duty dual arm mount for LCD-4700HD, 200 lbs. limit, 4-way adjustable
WM- 3742VT Fixed wall mount bracket
Specifications subject to change without notice
P. 2
The Biggest Thing
in LCD HD Monitors
Active Matrix 52" Color LCD HD Monitor
1920 (H) x 1080 (V) dots
550 cd/m² (Nit)
1600:1
©2008 ToteVision
LCD- 5200HD
Resolution:
Brightness rating:
Contrast Ratio:
Back Light:
Input Signal:
PC compatibility:
Dot Pitch:
Number of Pixels:
Response Time:
Audio output:
Speakers (separate):
Viewing angle L/R/T/B:
Pixel Configuration:
Input Signal Level:
Dimensions w/ desk stand (WHD):
Dimension w/o desk tand:
Actual visible screen size (WH):
Operating temperature/humidity:
Power Requirements:
Power Consumption:
Rear Terminal Connections:
50K
1920 (H) x 1080 (V) dots
500 cd/m² (Nit)
1500:1
Display:
52.0" TFT LCD active matrix
Built-in (24 CCFT)
Composite NTSC/PAL, S-Video, component,
analog RGB, HDMI, DVI
IBM compatible
0.2(V) x 0.2(H)mm
Colors: 16.7M
2,073,600
6.5mS (rising/falling)
10W x 2
10W + 10W
88/88/88/88 degrees
Stripe
1.0V P-P (positive) 75 Ohm
1310 x 892 x 350mm / 51.6" x 35.1" x 13.8"
1310 x 832 x 100mm / 51.6" x 32.8" x 3.9"
1152 x 648mm / 45.5" x 25.5"
50 ~ 104°F / 10 ~ 40°C, 20% ~ 90% humidity
110 ~ 240 VAC , 50/60 Hz
236 W (max)
2 composite RCA Video IN
Component: RCA YPbPr & R/L audio inputs, and
RCA Y/Cb/Cr & R/L audio inputs
2 S-Video IN
Audio: 2 RCA R/L audio inputs, PC audio IN, and
RCA audio R/L outputs
PC: RGB 15-pin D-sub
HDMI, DVI, RS-232: 9-pin
Power: AC IN
Weight: Net: 39.1 kg. / 86.2 lbs. Gross: 52.1 kg. / 114.9 lbs.
