Tote Vision LCD-2600HD Specification Sheet

The Biggest Thing in
HD LCD Monitors
LCD-3200HD
Shown without detachable speakers.
Active Matrix 32" and 26" LCD HD Monitors
• HD compatible (supports 480p/i, 720p, 1080i)
• RS-232 feature allows external devices to
control the monitor through the serial port.
• PIP : Picture in picture capability
• Widescreen 16:9 aspect ratio, 4:3, zoom
• LCD-3200HD: 2 detachable speakers provide 3D MTS stereo
and superior listening pleasure.
LCD-2600HD: 2 built-in 10W speakers provide 3D MTS stereo
and superior listening pleasure
• Environmental protection includes power-saving
capabilities, and the unit emits no x-ray radiation
• Absence of video oscillations and anti-reflective
hard coating provides enhanced viewing pleasure
• Composite, S-Video, component, DVI, PC
• Case made of of durable plastic (black color)
• Built-in removable desk stand included
• Wireless remote control works within 30 ft.
• 3-comb filter
• LCD-3200HD: Response time: 12/12ms (rising/falling)
LCD-2600HD: Response time: 15/5ms (rising/falling)

Optional Accessories

PLT-2300 VESA conversion plate (for landscape & portrait positioning)
WM-3018VT Fixed wall mount bracket
WM- 4200VT 4-way pan/tilt wall mount bracket (order w/ PLT-2300)
WMC -2342 Ceiling mount (order w/ PLT-2300)
For unit in flush mount kit order
model LCD-3200HDL.
Dimensions (WH): 33-3/8" x 21-3/8"
Distance between horizontal mounting holes: 32-3/8"
Specifications subject to change without notice
P. 5
LCD-3200HD: Dimensions (WHD):
LCD-2600HD: Dimensions (WHD):
LCD-3200HD: Dimensions w/o speakers & deskstand (WHD):
LCD-2600HD: Dimensions w/o deskstand (WHD):
60K
©2008 ToteVision
LCD-3200HD
LCD-3200HDL
LCD-2600HD
LCD-2600HD
Resolution:
1366 (H) x 768 (V) dots
Brightness rating:
500 cd/m² (Nit)
Contrast Ratio: 800:1
Display:
LCD-3200HD: 32.0" TFT LCD active matrix
LCD-2600HD: 26.0" TFT LCD active matrix
Input Signal: Composite NTSC/PAL, S-Video,
analog RGB, component, HDMI, DVI
PC compatibility: IBM compatible
Colors:
16.7M
Viewing angle L/R/T/B:
85/85/85/85 degrees
Number of Pixels: 983,040
1026 x 536 x 231mm / 40.4" x 21.1" x 9.1"
804 x 536 x 230mm / 31.6" x 21.1" x 9.1"
804 x 496 x 120mm / 31.7" x 19.5" x 4.7"
804 x 496 x 120mm / 31.7" x 19.5" x 4.7"
Actual visible screen size (WH): LCD-3200HD: 988 x 406mm / 38.9" x 16"
LCD-2600HD: 567 x 340mm / 22.3" x 13.4"
Operating temperature/humidity:
50 ~ 104°F / 10 ~ 40°C, 20% ~ 90% humidity
Power Requirements: 12VDC, 10.5A
Power Consumption:
130W (max.)
[RCA video IN and RCA R/L IN audio jack] x 2
Rear Terminal Connections:
S-Video IN jack x 2,
[RCA Y/Pb/Pr inputs & R/L audio inputs] ,
[RCA Y/Cb/Cr & R/L audio inputs]
RCA audio R & L output, PC audio IN jack,
15-pin D-sub, AC IN, 9-pin RS-232,
HDMI, DVI
LCD-3200HD: Weight: Net: 16 kg./ 35 lbs.
LCD-2600HD: Weight:
Net: 15.1 kg./ 33 lbs. Gross: 19 kg./ 42 lbs.
1319 Dexter Ave. N • Ste. 020 • WA 98109
Tel: 206-623-6000 • FAX: 206- 623-6609
E-mail: sales@totevision.com
http://www.totevision.com
Gross: 24 kg./ 52 lbs.
