Tote Vision LCD-2300HD Specification Sheet

LCD-2300HD
The Biggest Thing in
LCD HDTV Monitors
Active Matrix 23" Color LCD HD Monitor
Display: 23.0" TFT LCD active matrix
Back Light: Built-in (12 CCFT)
Input Signal:
Composite NTSC/PAL, S-Video
component, analog RGB, HDMI, DVI
Has digital RGB
C compatibility: IBM compatible
Dot Pitch:
0.39(V) x 0.39(H)mm
Colors: 16.7M
Contrast Ratio: 400:1
Number of Pixels:
983,040
Response Time: 15/10mS
Audio output:
10W x 2
Speakers: 10W + 10W
Viewing angle L/R/T/B:
85/85/85/85 degrees
Pixel Configuration: Stripe
Input Signal Level:
1.0V P-P (positive) 75 Ohm
Dimensions (WHD): 720 x 475 x 240mm / 28.3" x 18.7" x 9.4"
Dimensions w/o deskstand (WHD): 720 x 413 x 81mm / 28.3" x 16.3" x 3.2"
Actual visible screen size (WH):
499 x 299mm / 19.6" x 11.8"

Optional Accessories

Operating temperature/humidity: 50 ~ 104°F / 10 ~ 40°C, 20% ~ 90% humidity
Power Requirements:
12VDC, 10A
Power Consumption: 120 W (max)
Rear Terminal Connections:
[RCA video IN and RCA R/L IN audio jack] x 2
S-Video IN jack x 2, [RCA Y/Pb/Pr inputs & R/L audio inputs] ,
[RCA Y/Cb/Cr & R/L audio inputs]
RCA audio R & L output, PC audio IN jack,
15-pin D-sub, AC IN, 9-pin RS-232,
HDMI, DVI
Net Weight: 11.58 kg. / 25.5 lbs.
Gross Weight:
14.56 kg. / 32.8 lbs.
