Magnetic flux density - adjustment aid

10 Appendix
10.1 Magnetic flux density - adjustment aid
Depending on the material used, the thickness of workpieces and the measuring instrument used, the
winding numbers or current values may vary. Ideally, the measured flux density should be in the middle of
the parameter field.
Number of turns
2
3
4
5
6
7
8
9
10
11
12
13
14
15
[1] Example of use:
The measured value is 25 mT. This results in a number of turns of 9 and a degaussing current of 175
A if the activgauss process is used.
10.2

Guide values of magnetic flux density, weldability

TIG welding
Magnetic flux density
<0.5 mT
0.5-1 mT
1-2 mT
2-5 mT
>5 mT
36
50 A 100 A 125 A
3 4
4 6
4 7
5 8
5 9
5 10
7 12
8 13
10 15
12 16
15 18
16 20
18 22
18 24
Weldability
very good
good
possible
poor
unsuitable
Welding current (I )
2
150 A 175 A
Magnetic flux density mT
5 5
7 8
8 9
9 11
11 12
12 14
15 18
17 22 25
20 26
23 27
26 29
29 30
32 32
35 33
GMAW welding
Magnetic flux density
<3 mT
3-4 mT
4-6 mT
6-8 mT
>8 mT
200 A 250 A
6 6
9 10
10 12
12 14
14 16
16 19
21 24
[1]
29
30 34
35 39
39 45
44 50
48 55
53 61
Weldability
very good
good
possible
poor
unsuitable
