Toshiba REGZA 32HLV66 Operation Manual

Integrated high definition lcd tv/dvd combination

Hide thumbs Also See for REGZA 32HLV66:

Specifications (2 pages)

Operating manual (70 pages)

Operating manual (98 pages)

Table Of Contents

Table of Contents

Quick Links

Troubleshooting

Summary of Contents for Toshiba REGZA 32HLV66

Page 1 Owner’s Record The model number and serial number are on the back of your TV. Record these numbers in the spaces below. Refer to these numbers whenever you communicate with your Toshiba dealer about this TV. Model number: Serial number: YC/M...
Page 2: Fcc Declaration Of Conformity
• Consult the dealer or an experienced radio/TV technician for help. Caution: Changes or modifications to this equipment not expressly approved by Toshiba could void the user’s authority to operate this equipment. Important notes about your LCD TV/DVD combination The following symptoms are technical limitations of LCD Display technology and are not an indication of malfunction;...
Page 3: Table Of Contents
Chapter 1: Introduction ......5 Welcome to Toshiba ....... . 5 Features of your new TV .
Page 4 MP3/JPEG CD operation ......58 MP3/JPEG CD information ..... 58 MP3 CD playback .
Page 5: Chapter 1: Introduction
Welcome to Toshiba Thank you for purchasing this Toshiba LCD TV/DVD combination, one of the most innovative LCD TVs on the market. This digital television is capable of receiving analog basic, digital basic, and digital premium cable television programming by direct connection to a cable system providing such programming.
Page 6: Overview Of Steps For Installing, Setting Up, And Using Your New Tv
Inadequate ventilation may cause overheating, which will damage the TV. THIS TYPE OF DAMAGE IS NOT COVERED UNDER THE TOSHIBA WARRANTY. Do not plug in any power cords until AFTER you have connected all cables and devices to your TV.
Page 7: Tv Front And Side Panel Controls And Connections
TV front and side panel controls and connections Left side panel Remote sensor — Point the remote control toward this remote sensor (- “Remote control effective range” on page 9). Blue and Yellow LEDs Blue = Power indicator Yellow = Disc indicator See “LED indications”...
Page 8: Tv Back Panel Connections
® (Toshiba Home Interactive Network Connection) The RJ-45 (Ethernet) port allows your Toshiba TV to connect to your home network. This revolutionary home entertainment networking system lets you access MP3 audio files and JPEG picture files that are stored on a networked PC (as shared files) and play/display them on your TV.
Page 9: Chapter 2: Using The Remote Control
If you have a Toshiba device: Your TV remote control is preprogrammed to operate most Toshiba devices (- page 13). If you have a non-Toshiba device or a Toshiba device that the remote control is not preprogrammed to operate: You can program the TV remote control so it will operate the other device (- pages 11–15).
Page 10: Learning About The Remote Control
Learning about the remote control The buttons used for operating the TV only are described here. For a complete list of the remote control’s functions, see the remote control functional key chart (- page 12). Note: The error message “NOT AVAILABLE” may appear if you press a key for a function that is not available.
Page 11: Using The Remote Control To Control Your Other Devices
Using the remote control to control your other devices If you have a non-Toshiba device or a Toshiba device that the remote control is not preprogrammed to operate, you must first program the remote control to recognize the device (if you have not already done so) (- pages 13–15).
Page 12: Remote Control Functional Key Chart
• “---” = key does not send a signal in that remote control mode. • sTV = key will affect the TV, even when the remote control is not in the “TV/DVD” device mode. Toshiba TV/ REMOTE CONTROL KEY Built-in DVD...
Page 13: Programming The Remote Control To Control Your Other Devices
Your Toshiba TV remote control is preprogrammed to operate most Toshiba devices. To program your TV remote control to operate a non-Toshiba device (or a Toshiba device that it is not preprogrammed to operate), follow the steps below. For details on using the remote control to operate the device, see page 11.
Page 14: Remote Control Codes
008, 009, 013, 016 Realistic Samsung Sony 014, 055 Star Choice Star Trak 025, 026, 037, 054 Toshiba 000, 001, 002, 003, 004, 005, 006, 007, 020, 031, 056 Uniden 021, 028, 030, 032, 035, 039, 043, 045, 047, 058...
Page 15 018, 051, 053, 073, Tandy Tashiko Tatung Teac 018, 029, 037 Technics Teknika 010, 018, 065 Toshiba 000, 011, 021, 023, 024, 028, 030, 039, 057, 074, 078, 079 Totevision 009, 010, 065 Unitec Unitech Vector Research 005, 006, 011, 012,...
Page 16: Chapter 3: Menu Layout And Navigation
Chapter 3: Menu layout and navigation Main menu layout The tables below and on the next page provide a quick overview of your TV’s menu system. To open the main menus (illustrated below), press Y on the remote control or TV control panel. Icon Item Picture Viewer...
Page 17: Setup/Installation Menu Layout
Setup/Installation menu layout The Installation menu contains the Terrestrial, Network, and System Status menus. To open the Installation menu (illustrated below), press Y on the remote control or TV control panel, open the Setup menu, select Installation, and press T. Icon Press Y, Terrestrial...
Page 18: Chapter 4: Setting Up Your Tv
Chapter 4: Setting up your TV Selecting the menu language You can choose from three different languages (English, French and Spanish) for the on-screen display of menus and messages. To select the menu language: Press Y and open the Preferences menu. Highlight Menu Language and press c.
Page 19: Programming Channels Into The Tv's Channel Memory
Programming channels into the TV’s channel memory When you press < or , on the remote control or TV control panel, your TV will stop only on the channels you programmed into the TV’s channel memory. Follow the steps below to program channels into the TV’s channel memory.
Page 20: Programming Your Favorite Channels
To add a channel to the channel memory: Highlight the unchecked box next to the channel number you want to add, and then press T to check the box. To manually add digital subchannels on a physical channel: Use the Channel Numbers and the Dash (=) on the remote control to enter the channel number (for example, 56–1).
Page 21: Setting The Hdmi ™ Audio Mode
To clear your Favorite Channels list: Press Y and open the Preferences menu. Highlight Favorite Channels and press T. Highlight Edit and press T. Highlight Reset and press T. All channels in the Favorite Channels list will be deleted (unchecked). Highlight Done and press T.
Page 22: Viewing The System Status
Press C c to scroll through the menu bar to select either the Product Information or Software Version and view the related information. System Information System Information Product Information Brand: Toshiba Model: 32HLV66 Done To close the screen and return to the Installation menu: Highlight Done and press T.
Page 23: Chapter 5: Using The Tv's Features
Chapter 5: Using the TV’s features Selecting the video input source to view To select the video input source to view: Press + on the remote control or INPUT on the TV control panel. To select the input: Press 0–7 to select the input source you want to view: a) You can select the video input which will depend on the input terminals you used to connect your devices...
Page 24: Tuning Channels
Input labeling example: The screen below left shows the default Input Selection screen (with none of the inputs labeled as a specific device). The screen below right is an example of how you could label the inputs if you connected a VCR to VIDEO 1, Cable TV to VIDEO 2, a video recorder to ColorStream HD1, and a DTV set-top box to HDMI.
Page 25 ™ To open the Channel Browser banner: Either… press 3 C, # c, or i on the remote control. • Or… press C to open the THINC menu, highlight Channel Browser and press T. Press 3 C to surf backward through the previously tuned 32 •...
Page 26: Tuning Your Favorite Channels
Using the Home feature When you press i on the remote control, the TV will be tuned to the channel or input you set as “Home.” To set a channel or input as Home: Tune the TV to the channel or input you would like to set as the Home source.
Page 27: Selecting The Picture Size
Selecting the picture size You can view many program formats in a variety of picture sizes—Natural, TheaterWide 1, TheaterWide 2, TheaterWide 3, and Full. The way the image displays in any of the picture sizes will vary depending on the format of the program you are viewing. Select the picture size that displays the current program the way that looks best to you.
Page 28: Scrolling The Theaterwide Picture (Theaterwide 2 And 3 Only)
TheaterWide 3 picture size (for letter box programs with subtitles) The picture is stretched wider to fill the width of the screen, • but only slightly stretched taller. The top and bottom edges are hidden. To view the hidden • areas (such as subtitles or captions), see “Scrolling the ®...
Page 29: Using The Auto Aspect Ratio Feature
Using the auto aspect ratio feature When the auto aspect ratio feature is set to On, the TV will automatically select the picture size when one of the following input sources is received: A 480i signal from the VIDEO 1, VIDEO 2, ColorStream •...
Page 30: Adjusting The Picture
Adjusting the picture Selecting the picture mode You can select your desired picture settings from four different modes, as described below. Mode Picture Quality Sports Bright and dynamic picture (factory setting) Standard Standard picture settings (factory setting) Lower contrast for darkened room (factory Movie setting) Preference...
Page 31: Using The Closed Caption Mode
Using the closed caption mode The closed caption mode has two options: Captions—An on-screen display of the dialogue, narration, • and sound effects of TV programs and videos that are closed captioned (usually marked “CC” in program guides). Text—An on-screen display of information not related to •...
Page 32: Digital Closed Captions
Digital closed captions You can use the Digital CC/Audio Selector to select digital closed caption services (if available), which will temporarily override closed captions for digital channels only. When such services are not available, the Digital CC/Audio Selector presents a default list of services. If the selected service is not available, the next best service will be used instead.
Page 33: Selecting Stereo/Sap Broadcasts
Selecting stereo/SAP broadcasts The multi-channel TV sound (MTS) feature allows you to output high-fidelity stereo sound. MTS also can transmit a second audio program (SAP) containing a second language, music, or other audio information (when provided by individual stations). When the TV receives a stereo or SAP broadcast, the word “STEREO”...
Page 34: Using The Stablesound ® Feature
Using the StableSound ® feature The StableSound ® feature limits the highest volume level to prevent extreme changes in volume when the signal source changes (for example, to prevent the sudden increase in volume that often happens when a TV program switches to a commercial).
Page 35: If You Cannot Remember Your Pin Code
When the correct PIN code is entered, the Locks menu opens. Locks Enable Rating Blocking Edit Rating Limits Channels Block Input Lock Front Panel Lock New PIN Code Navigate ENTER Select EXIT Exit MENU If you cannot remember your PIN code While the PIN code entering screen is displayed, press E four times within five seconds.
Page 36: Blocking Tv Programs And Movies By Additional Ratings
• The additional rating system is not designed, transmitted, or controlled by the TV or Toshiba, nor is the availability of an additional rating system determined or controlled by Toshiba. Similarly, the rating of programs in an additional rating system is not determined, transmitted, or controlled by the TV or Toshiba.
Page 37: Blocking Channels
Blocking channels With the Channels Block feature, you can block specific channels. You will not be able to tune blocked channels unless you unlock them. To block channels: Press Y and highlight the Locks menu icon. Press b to display the PIN code entering screen. Enter your four-digit PIN code and press T (- page 34).
Page 38: Using The Input Lock Feature
Using the input lock feature You can use the Input Lock feature to lock the video inputs (Built-In DVD, VIDEO 1, VIDEO 2, ColorStream HD-1, ColorStream HD-2, HDMI, and PC) and channels 3 and 4. You will not be able to view the input sources or channels until you unlock the inputs.
Page 39: Using The Pc Setting Feature
Using the PC setting feature You can view the image from a PC on the TV screen. The PC must be connected to the TV’s PC IN terminals (- Installation Guide). You can use the PC Settings feature to adjust the picture’s horizontal position/width, vertical position/height, clock phase, and sampling clock.
Page 40: Setting The Sleep Timer
Setting the sleep timer You can set the sleep timer to turn off the TV after a set length of time (maximum of 180 minutes). To set the sleep timer using the remote control: Press [ on the remote control to set the length of time until the TV turns off.
Page 41: Understanding The Auto Power Off Feature
Chapter 5: Using the TV’s features Understanding the auto power off feature The TV will automatically turn itself off after approximately 15 minutes if it is tuned to a vacant channel or a station that completes its broadcast for the day. This feature functions in ANT 1 mode only.
Page 42: Chapter 6: Using The Tv's Advanced Features
Chapter 6: Using the TV’s advanced features Using the advanced picture settings features Using dynamic contrast When dynamic contrast is set to On, the TV will detect changes in the picture quality that affect the appearance of your contrast settings and then automatically adjust the video. When dynamic contrast is set to Off, the settings selected in the Contrast field in the Picture Settings menu will be used (- page 30).
Page 43: Selecting The Color Temperature
Selecting the color temperature You can change the quality of the picture by selecting from three preset color temperatures (Cool, Medium, and Warm), as described below. Mode Picture Quality Cool blueish Medium neutral Warm reddish To select the color temperature: Press Y and open the Video menu.
Page 44: Using The Advanced Audio Settings Features
Using the advanced audio settings features Using the SRS WOW ™ surround sound feature ™ SRS WOW is a special combination of SRS Labs audio technologies (SRS 3D, SRS FOCUS, and SRS TruBass) that creates a thrilling surround sound experience with deep, rich bass from stereo sound sources.
Page 45: Chapter 7: Using The Thinc ™ Home Network Feature
If you think your Toshiba TV and router might have compatibility problems, please contact the following: In the U.S., call TACP Consumer Solutions at •...
Page 46: Manually Setting Up The Network Address
Chapter 7: Using the THINC The message “Please wait…” will display while the TV is attempting to load the network address information from the DHCP server. Basic Network Setup Please wait... If the automatic network address setup is successful, go to step 7. If the automatic network address setup is not successful, go to step 8.
Page 47: Resetting The Network Address
Chapter 7: Using the THINC Resetting the network address Press Y and open the Setup menu. Highlight Installation and press T. The Installation menu appears. Open the Network menu. Highlight Basic Network Setup and press T. The message “Your Basic Network Setup is complete. Would you like to start over?”...
Page 48: Setting Up File Sharing On A Pc With Microsoft Windows 2000
Chapter 7: Using the THINC In the Properties window for the selected folder: a) Click to display the “Sharing” tab. b) Click to select “Share this folder.” c) Click “Permissions” (which will open the Permissions window for the selected folder). Note: If the “Sharing”...
Page 49: Setting Up File Sharing On The Tv
Chapter 7: Using the THINC In the Properties window: Click “OK” (which closes the Properties window). The shared folder will display with a “shared folder” icon (a hand holding a folder). Go to section D, “Setting up file sharing on the TV”. For home network troubleshooting tips, see Chapter 9.
Page 50: About The Software Upgrade Feature
• If you are viewing/playing files stored on a networked PC, IT IS RECOMMENDED THAT YOU BACK UP YOUR DATA. Toshiba is not liable for any damage caused by the use of any networked PC, or shared files with this TV. Toshiba will not compensate for any lost data or recording(s) caused by the use of such PCs, or data.
Page 51: Using The Picture Viewer
• You must obtain any required permission from copyright owners to download or use copyrighted content. Toshiba cannot and does not grant such permission. Accessing JPEG files stored on a networked PC Make sure you have correctly set up your home network and file sharing (- Installation Guide and pages 45–49).
Page 52 Chapter 7: Using the THINC Viewing JPEG files on the TV After accessing your JPEG files from your networked PC, the images automatically display on-screen, with one as a large picture and six in thumbnail format. Picture Viewer //ALLENMPC/Pics/Directory3/Subdirectory1/shelby concept.jpg. 1 of 8 Nov 2 05 2 of 8...
Page 53: Using The Audio Player
• You must obtain any required permission from copyright owners to download or use copyrighted content. Toshiba cannot and does not grant such permission. Accessing MP3 files stored on a networked PC Make sure you have correctly set up your home network and file sharing (- Installation Guide and pages 45–49).
Page 54: Chapter 8: Dvd Playback
Because of problems and errors that can occur during the creation of DVD and CD software and/or the manufacture of DVD and CD discs, Toshiba cannot assure that the DVD player contained in this television will successfully play every disc bearing the DVD and CD logos. If you happen to...
Page 55: Using The Dvd Aspect Ratio Feature
About icons on the heading bar show the playable discs for the function described under that heading. : You can use this function with DVD video discs. : You can use this function with Video CDs. : You can use this function with Audio CDs and CD-R/ RW discs.
Page 56: Playing In Fast Reverse Or Fast Forward
Playing in fast reverse or fast forward Press H or J during playback. H: Fast reverse playback (DVD : 2X-64X, VCD/CD: 2X- 16X) J : Fast forward playback (DVD : 2X-64X, VCD/CD: 2X- 16X) Each time you press H or J , the playback speed changes. To resume normal playback: Press S.
Page 57: Title Selection
Title selection Two or more titles are recorded on some discs. If the title menu is recorded on the disc, you can select the desired title. Press N during playback. Title menu appears on the screen. Press B b C c to select the desired title. Press T or S.
Page 58: Disc Status
Note: • Depending on the DVD, you may not be able to change subtitles, or to turn subtitles on or off. • While playing a DVD, the subtitle may change when you loaded or eject the disc. • In some cases, a selected subtitle language may not be changed immediately.
Page 59: Jpeg Cd Playback
Use of CD-RW for MP3 files is not recommended. • You must obtain any required permission from copyright owners to download or use copyrighted content. Toshiba cannot and does not grant such permission. About the file menu...
Page 60: Chapter 9: Troubleshooting
Chapter 9: Troubleshooting General troubleshooting Before calling a service technician, please check this chapter for a possible cause of the problem and some solutions you can try. Black box on screen The Closed Caption feature is set to one of the Text •...
Page 61 Sound problems Check the antenna/cable connections (- Installation • Guide). The station may have broadcast difficulties. Try another • channel. The sound may be muted. Press VOLUME. • • If you hear no sound, try setting the MTS feature to Stereo mode (- page 33).
Page 62: Home Network Troubleshooting
Picture Viewer problems “No pictures found” message is displayed. Sharing is not correctly set up on the networked PC. • Make sure you connected your home network correctly (- Installation Guide) and set up the network address properly (- Chapter 7). The JPEG files exceed the specified limits (- “Media •...
Page 63: Dvd Troubleshooting
Home server setup problems The PC (“Home Server”) name is not displayed The Ethernet cables are not connected properly or at all. • Connect all cables (- Installation Guide). The network setup on the PC is incorrect. Make sure both •...
Page 64: Led Indications
If, after trying the solutions, the problem still exists: In the U.S., call TACP Consumer Solutions at 1-800-631-3811. • In Canada, locate the nearest Toshiba authorized service depot by directing your web browser to www.toshiba.ca; click • “Home Entertainment,” and then click “Support.”...
Page 65: Chapter 10: Appendix
Specifications Note: • This model complies with the specifications listed below. • Designs and specifications are subject to change without notice. • This model may not be compatible with features and/or specifications that may be added in the future. Television System NTSC standard ATSC standard (8VSB) Digital Cable (64 QAM, 256 QAM;...
Page 66: Limited United States Warranty
Limited United States Warranty for LCD TV/DVD Combinations 26” and Larger Toshiba America Consumer Products, L.L.C. (“TACP”) makes the following limited warranties to original consumers in the United States. THESE LIMITED WARRANTIES EXTEND TO THE ORIGINAL CONSUMER PURCHASER OR ANY PERSON RECEIVING THIS LCD TV/DVD COMBINATION AS A GIFT FROM THE ORIGINAL CONSUMER PURCHASER AND TO NO OTHER PURCHASER OR TRANSFEREE.
Page 67: Limited Canada Warranty
Read this owner ’s manual thoroughly before operating this LCD TV/DVD Combination. If you purchased your LCD TV/DVD Combination in Canada, register it online at www.toshiba.ca as soon as possible. By registering your product you will enable TCL to bring you new products specifically designed to meet your needs and help us to contact you in the unlikely event a safety notification is required.
Page 68 A copy of the GPL source code in this product may be obtained by contacting Toshiba Consumer Solutions at (800)631-3811. There will be a charge to cover the costs of providing the source code. A copy of the LGPL source code in this product may be obtained by contacting Toshiba Consumer Solutions at (800)631-3811.
Page 69: Index
Index Antenna input configuration ... 18 ... 53 Audio Player ... 33 Audio quality adjustments Auto aspect ... 29 ... 41 Auto power off Back of the TV ... 8 ... 37 Blocking channels CableClear ® ... 42 CH Bb buttons ... 26 ...
Page 70 Notes...
Page 71 Notes...
Page 72 Notes...
Page 73 Notes...
Page 74 VANCOUVER: 13551 COMMERCE PARKWAY, SUITE 110, RICHMOND, B.C., V6V 2L1, CANADA – TEL: (604) 303-2500 MANUFACTURED BY CableClear, ColorStream, StableSound, and TheaterWide are registered trademarks of Toshiba America Consumer Products, L.L.C. Channel Browser, SurfLock, THINC, and LCDVD logo are trademarks of Toshiba America Consumer Products, L.L.C. PRINTED IN USA (06-07)
