QUICK SETUP GUIDE
32" 720p
60Hz LED TV
NS- 32D220NA20
ACCESSORIES
Remote and two TV stands
AAA batteries
+ + +
M4 screws (12 mm length)
(4 pcs.)
STOP
Before using your new product, please read
these instructions to prevent any damage.
Do not plug your power cord in until all other
devices have been connected.

INSTALLING THE STANDS OR A WALL MOUNT

1
Place your TV face-down on a cushioned, clean surface.
STANDS
1 Align the TV stand screw holes with
the holes on your TV's bottom.
2 Use a Phillips screwdriver and two
provide screws to secure each
stand to your TV.
OR
WALL MOUNT
Before you mount your TV, make sure that:
• You remove the stands.
• The wall-mount bracket supports the weight of your TV.
See the instructions that came with your wall mount for more information
about how to correctly mount your TV.
WARNING: Your TV has four VESA mounting holes on the back. You must secure a
wall-mount bracket to all four holes. If you do not use all four holes, your TV may fall
and cause property damage or personal injury.
Note: Wall-mount screws are not included.

MAKING CONNECTIONS

2
HDMI
(best video quality)
Note: You can use the
HDMI 1 (ARC) jack to
connect a digital
audio system.
AV
(good video quality)
AUDIO/VIDEO OUT
Coaxial
(good video quality)
HD HD
Connect an antenna to
access live over-the-air TV.
L
R
VESA Mounting Pattern
100 x 100 mm—Type M4 screws, 10 mm min.
HDMI options
FEATURES
Power indicator/
Remote control sensor
Note: Images do not necessarily represent
the exact design of your television.
AUDIO OPTIONS
ANALOG
L
R
SOUNDBAR
AUDIO IN
DIGITAL
You can use the DIGITAL
OPTICAL OUTPUT jack or the
HDMI 1 (ARC) jack.
OPTICAL
Note: To change the digital audio
AUDIO IN
format, on your TV's Audio
SOUNDBAR
menu, select Audio Format/Audio
Delay, then set Audio Format to
PCM.
