Summary of Contents for Lipco HSA 30
- Page 1 Translation of Hydraulic shaker HSA 30 for narrow cultivation original instructions LIPCO GmbH Am Fuchsgraben 5b D-77880 Sasbach Tel. +49 7841 6348-0 +49 7841 6348-300 E-mail mail@lipco.com www.lipco.com...
-
Page 2: Introduction
- will be able to have a complete reference on hand at all times. Note: The illustrations, descriptions and specifications in this manual are not binding. LIPCO reserves the right to make modifications without notice. 2 - 32 220074-01-EN BA HSA 30 / 28.09.2019... -
Page 3: Table Of Contents
Driving on public roads. Maintenance 15.1. Hydraulic unit 15.2. Transmission of hydraulic pump 15.3. Shaking unit 15.4. Lubrication chart Others Machine storage Machine disposal after end of lifetime Notes Warranty EC declaration of conformity 3 - 32 220074-01-EN BA HSA 30 / 28.09.2019... -
Page 4: Designated Use
It may be necessary to transport the LIPCO hydraulic shaker HSA 30 on a flatbed truck. • Note LIPCO hydraulic shaker HSA 30 is also referred to in this operating manual only as LIPCO-HSA. 4 - 32 220074-01-EN BA HSA 30 / 28.09.2019... -
Page 5: Warning Signs Attached To The Machine
Always shut off the motor and remove the ignition key when performing maintenance or repairs! Operate the unit only at the specified speed (max. 540 rpm)! 5 - 32 220074-01-EN BA HSA 30 / 28.09.2019... -
Page 6: General Safety Regulations
• The operator is responsible for compliance with applicable acci- dent prevention regulations, in addition to the generally recog- nized safety, occupational health and traffic safety regulations! 6 - 32 220074-01-EN BA HSA 30 / 28.09.2019... - Page 7 • Persons not involved must keep out of the work area of the ma- chine. • Keep children away from the LIPCO HSA! 7 - 32 220074-01-EN BA HSA 30 / 28.09.2019...
-
Page 8: Accident Prevention
Prior to any operation, check PTO dive shaft length / overlap- ping. Possibly a length adjustment will be required. • Operate the machine only at the specified speed (max. 540 rpm)! 8 - 32 220074-01-EN BA HSA 30 / 28.09.2019... - Page 9 This concerns driving parallel to the slope or downslope. Any operation not adapted to local conditions can cause serious personal injuries or material damages because of tilting of the combination of tractor + LIPCO HSA. 9 - 32 220074-01-EN BA HSA 30 / 28.09.2019...
-
Page 10: Technical Details - Standard Equipment
Universal joint shaft 8. Technical details – special equipment • Overrun brake (hydraulic) • Backfitting of the overrun brake • Rear attachment including hydraulic unit • Front attachment including hydraulic unit 10 - 32 220074-01-EN BA HSA 30 / 28.09.2019... -
Page 11: Technical Data
Gripper Shaking efficiency Bup to 400 trees / hour Required power 40 kW Weight: Gripper + parallel shift 345 kg Pump + aggregat 180 kg Main dimensions in public road condition: 11 - 32 220074-01-EN BA HSA 30 / 28.09.2019... -
Page 12: Functions Of Shaking Arm
10. Functions of shaking arm The shaking arm has following functions: • Lateral shift: von 1,20 m – 2,80 m • Parallelogram shift • Clamp 90° / 0° • Tree clamping 12 - 32 220074-01-EN BA HSA 30 / 28.09.2019... -
Page 13: Attachment To Tractor
Lower links of the tractor may only be plugged between the mounting brackets of the HSA. Depending on category (CAT 1 / CAT 2) of tractor reductions will be required for upper link. Fig. 2 13 - 32 220074-01-EN BA HSA 30 / 28.09.2019... - Page 14 Prior to connecting the hydraulic hoses, clean the coupling ele- ments on tractor- and machine side properly. • Note: Any dirt within the hydraulic circuit will damage the sealing of hy- draulic valves and hydraulic motor. 14 - 32 220074-01-EN BA HSA 30 / 28.09.2019...
-
Page 15: Attachment Of The Universal Joint Shaft
When connecting the universal joint shaft to the machine, make sure that the protective cover covers completely the universal joint shaft guard in all operating positions! • For your personal safety, replace damaged or worn protective devices immediately. 15 - 32 220074-01-EN BA HSA 30 / 28.09.2019... - Page 16 Disconnect 12-V plug after end of operation, to prevent the bat- tery from excessive load. Fig. 7 16 - 32 220074-01-EN BA HSA 30 / 28.09.2019...
-
Page 17: Operating Hsa
Fig. 9 • Functions of different Joystick-levels / level 2: Following functions are activated by keeping green buttons pushed: • Lateral shift in / out • Parallelogramm in / out Fig. 10 17 - 32 220074-01-EN BA HSA 30 / 28.09.2019... - Page 18 • F2 - swivel parallelogram in a way, that 0° clamp is touching tree from outside. • F1 – Activate tree clamp • F1- release shaking by keeping red button pushed 18 - 32 220074-01-EN BA HSA 30 / 28.09.2019...
-
Page 19: Driving On Public Roads
Switch off hydraulic drive (PTO drive shaft) • To get a minimum protrusion of LIPCO HSA to tractor, please set as follows: • Lateral shift completely in, • Set clamp to 90°, • Parallelogramm completely in. 19 - 32 220074-01-EN BA HSA 30 / 28.09.2019... -
Page 20: Maintenance
Drain used oil via drain plugs on lower side of oil tank. (Fig. • Two drain plugs are available. (Inner- / outer oil tank) – for draining open both. Fig. 12 20 - 32 220074-01-EN BA HSA 30 / 28.09.2019... - Page 21 Proceed with filling procedure up to the middle of oil level indica- tor. Close oil filler cap. Change of filter cartridge: • Change filter cartridge parallel to hydraulic oil change. (Fig. Filter cartridge Fig 14. 21 - 32 220074-01-EN BA HSA 30 / 28.09.2019...
-
Page 22: Transmission Of Hydraulic Pump
1x per year. It is recommended to do it at beginning of the sea- son. Transmission oil: Type SAE 90 Volume: 0,2 l. Oil level indicator: Required oil level center of indicator Drain screw Fig. 15 Oil filler cap Fig. 16 22 - 32 220074-01-EN BA HSA 30 / 28.09.2019... -
Page 23: Shaking Unit
Drain plug see on lower side of shaking unit. Drain / filler plug Fig. 16 For refilling of shaking unit, tilt shaking head sideward 90°and fill with oil – volume see above. Close drain / filler plug. 23 - 32 220074-01-EN BA HSA 30 / 28.09.2019... -
Page 24: Lubrication Chart
Fig. 17 Guide tube of lateral shift: Lubricate guide tube on right side all around. Fig. 18 Guide tube of tree clamp: Lubricate guide tube all around. Fig. 19 24 - 32 220074-01-EN BA HSA 30 / 28.09.2019... - Page 25 To prevent the shaking unit from excessive load, the com- plete unit is freely suspended with 4 chains. Check suspension chains for damages on a regular base. Replace damaged components immediately. Fig. 22 25 - 32 220074-01-EN BA HSA 30 / 28.09.2019...
-
Page 26: Others
For the first time after 10 hours of operation, later on at the be- ginning of the season. Strength class 8.8 Tightening torque (Nm) Tightening torque [Nm] valid for coarse thread Total friction coefficient µ = 0,12; 90 % usage of stud yield strength 26 - 32 220074-01-EN BA HSA 30 / 28.09.2019... -
Page 27: Machine Storage
18. Machine disposal after end of lifetime A disposal of the complete machine / or machine components and the operating supplies has to be done separated according to valid legal regulations. 27 - 32 220074-01-EN BA HSA 30 / 28.09.2019... -
Page 28: Notes
Instructions Hydraulic shaker HSA 30 19. Notes 28 - 32 220074-01-EN BA HSA 30 / 28.09.2019... - Page 29 Instructions Hydraulic shaker HSA 30 29 - 32 220074-01-EN BA HSA 30 / 28.09.2019...
-
Page 30: Warranty
Each machine bears a rating plate with the following data: • Manufacturer • Year of manufacture • Machine no. • Model designation Always include this data when ordering replacement parts or for ser- vicing. 30 - 32 220074-01-EN BA HSA 30 / 28.09.2019... -
Page 31: Ec Declaration Of Conformity
LIPCO. Willi Lipp - Technical director - Sasbach, 2015.10.21 (Place and date of issue) (Name, function and signature of responsible) 31 - 32 220074-01-EN BA HSA 30 / 28.09.2019... - Page 32 32 - 32 Design: mail@bauer-ib.com...
