- Page 1 TEC Digital Scale SL-47-N-1 SERIES Table of Contents TEC CORPORATION Document No. EM1-31061A...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION 2. APPLICABLE MODEL 3. SPECIFICATIONS 4. OVERVIEW 5. LEVEL ADJUSTMENT 6. INSTALLING THE REMOTE PIPE 7. CONNECTING THE INTERFACE 8. TROUBLESHOOTING 9. BEFORE YOU CALL FOR SERVICE CAUTION: This manual may not be copied in whole or in part without prior written permission The contents of this manual may be changed... -
Page 3: Introduction
1. INTRODUCTlON 1. INTRODUCTION We thank you very much for purchasing been designed with TEC reliability. Should you have any questions concerning this manual for future reference. This equipment has been tested pursuant to Part 15 of the FCC Rules. against harmful interference... - Page 4 1. INTRODUCTION Safety Precautions This Owner’s Manual and the products should be observed in order to use the machines damage to property. The meanings Read these indications and become familiar with their contents The following safety precaution Unplug the printer whenever Keep your work environment Meanings of Each Symbol This symbol indicates warning...
- Page 5 1. INTRODUCTION Prohibited If foreign objects (metal fragments, water, liquids) enter the machines, turn off the power switches disconnect the power cord plugs from the outlet, and the contact your sales agent (or maintenance agent). Continued in that condition may cause fire or electric shock.
- Page 6 1. INTRODUCTION Di x onnecl the plug. When moving the machines, sure to first unplug the power cords. Moving the machines cords plugged in may damage the cords H Do not lean against the machine. may fall and be damaged. w Be sure to move large scale machines with two or more people.
-
Page 7: Applicable Model
2. APPLICABLE MODEL 2. APPLICABLE MODEL Model name description lb base scale Blank: kg base scale Series name -+-.I Interface T: TEC ECR I/F I : IBM ECR I/F (Serial) P: IBM ECR I/F (Parallel) N: NCR ECR I/F R: RS-232C r- us Destination Display type / Key type... -
Page 8: Specifications
3. SPEClFlCATlONS 3. SPECIFICATIONS Item Maximum Capacity Minimum Scale Division Display Range Display (Weight) 4 digits Power Requirement AC 12OV & lo%, Current Consumption 12OV, 0.2A Operating Temperature 32°F - 104°F Relative Humidity 45% - 85% RH (no condensation) Dimensions (approx.) Built-in Type 13.58”... -
Page 9: Overview
