- Page 1 LF/LFd Assembly manual Spare part list + Assembling guideline LF/LFd Light filter Ag/MIT/IGB-2239-03/15 Rev. 1.1...
-
Page 2: Assembly Manual
Munters Italy S.p.A. reserves the right to effect modifications to the apparatus in accordance with technical and legal developments. - Page 3 • Max environment temperature during operation and/or stockage shall not exceed 50°C. • Protect filter from direct sunrays when not in operation. • Do not stock in sealed packages under direct sunrays. • Verify that adequate ventilation is provided. © Munters AB, 2019...
-
Page 4: Spare Part List
Spare part list fig.1 Ref. 8 to fix on top panel EM/ED24HE or distance kit for EC/ED36HE/ED30HE. © Munters AB, 2019... -
Page 5: Spare Parts
Spare parts Ref. Picture Description Q.ty SELF TAPPING SCREW (ROUND HEAD) 6.3X13 SELF TAPPING SCREW (FLAT HEAD) 6.3X16 EMBOSSED ANGLE BRACKET BOTTOM PANEL PLASTIC WAVE CIRCLE TAB.1 PLASTIC WAVE TRIANGLE TAB.1 TOP/SIDE PANEL HOOK FOR FILTER © Munters AB, 2019... -
Page 6: Package Content
Chapter1 Spare part list SELF TAPPING SCREW (ROUND HEAD) 6.3X19 Package content MODEL LF50 LF36 LF30 LF24 PLASTIC WAVE CIRCLE PLASTIC WAVE TRIANGLE © Munters AB, 2019... - Page 7 Chapter1 Spare part list fig.2 Ref. 5 central spacers for 52/50/36 only. Ref. 8 to fix on top panel EM/ED24HE or distance kit for EC/ED36HE/ED30HE. © Munters AB, 2019...
- Page 8 Chapter1 Spare part list Spare parts Ref. Picture Description Q.ty TOP/SIDE PANEL EMBOSSED ANGLE BRACKET BOTTOM PANEL WITH HOLES PLASTIC WAVE SPACER SELF TAPPING SCREW (ROUND HEAD) 6.3X13 SELF TAPPING SCREW (FLAT HEAD) 6.3X16 HOOK © Munters AB, 2019...
- Page 9 Chapter1 Spare part list SELF TAPPING SCREW (ROUND HEAD) 6.3X19 Package content MODEL LFD52 LFD50 LFD36 LFD30 LFD24 WAVE SPACER © Munters AB, 2019...
- Page 10 Chapter1 Spare part list LFD - MWI fig.3 © Munters AB, 2019...
- Page 11 Spare parts Ref. Picture Description Q.ty TOP PANEL ANGLE BRACKET TOP/BOTTOM SELF TAPPING SCREW 4.2X19 SELF TAPPING SCREW (ROUND HEAD) 6.3X13 ANGLE BRACKET SIDE SELF TAPPING SCREW (FLAT HEAD) 6.3X16 EMBOSSED ANGLE BRACKET BOTTOM PANEL WITH HOLES © Munters AB, 2019...
- Page 12 Chapter1 Spare part list SPACER PLASTIC WAVE SIDE PANEL © Munters AB, 2019...
- Page 13 Assembling tools Ref. Picture Description Q.ty PNEUMATIC SCREWDRIVER PHILLIPS SCREW HEAD ADAPTOR © Munters AB, 2019...
- Page 14 (round head - 6.3x13), qty. 2 angle brackets and qty. 8 self tapping screws (flat head 6.3x16). is recommended using pneumatic screwdriver applying a torque of 16 © Munters AB, 2019...
- Page 15 Start to mount the plastic waves: first tthe wave then the spacers. Fix other spacers on top of the wave. Insert another wave and follow the procedure in order to complete the filter. End the assembly with the last wave. © Munters AB, 2019...
- Page 16 Chapter3 Assembling guidelines LF WAVES ASSEMBLING Divide the ‘triangle’ waves from the ‘circle’ ones. Start with a ‘circle’ wave. Proceed with a ‘triangle’ wave. Continue to alternate ‘triangle’ and ‘circle’ waves to complete the light filter. © Munters AB, 2019...
- Page 17 16 Nm. Remove the protection mesh from the back side of the fan and place the hooks on the fan by means of qty. 2 self tapping screws (round head - 6.3x19). © Munters AB, 2019...
- Page 18 Turn the filter 90° to gain the operating position, with the waves upright. Hook the filter to the fan. Please note that on some specific fans it may be requested an additional Spacer Kit. WARNING For further information, please contact the Customer Service. © Munters AB, 2019...
- Page 19 Phone +90 262 7513 750, info@muntersform.com, Phone +1 517 676 7070, aghort.info@munters.com, Export & Other countries Phone +39 0183 5211, info@munters.it Munters reserves the right to make alterations to specifications, quantities, etc., for production or other reasons, subsequent to publication. © Munters AB, 2019...
