Entone 95-810500-00 Quick Reference Manual

COPYRIGHT © © © © 2007 ENTONE, INC. ALL RIGHTS RESERVED
.
Hydra Quick Reference Guide
1. Welcome!
Thank you for using Entone's Hydra Multi-Television Video Gateway. This quick reference gives quick
instruction for setting up and using Hydra. For detailed setup and usage instruction, please refer to the
Hydra User's Guide and the URC Plus User's Guide in http://www.entone.com.
2. Before You Begin
Check that the video output connector of the Hydra is properly connected to the input connector of the
TV(s).
In your TV, select the input source that the Hydra is used.
"MATV OUTPUT" by default uses CATV channel ID 10, 12 and 23 for decoder 1, 2 and 3 respectively.
"TV OUT" for decoder 1 by default uses CATV channel ID 10.
Check that you have connected Hydra to the network either using ETHERNET or ADSL. For details of
connecting Hydra to the network, please refer to your service provider.
Software upgrade is required when you power up Hydra for the first time. Software upgrade may take 5
minutes. Do not power off during software upgrade.
3. Install Remote Control Batteries
Install the two AA batteries (provided) into the remote control.
Important!! Use only new AA Alkaline batteries to insure consistent operation.
4. Understanding the Remote Control
This 3 mode Universal Remote Control can be programmed to control your Hydra and up to two other
devices. The remotes can be set up by following these simple instructions.
5. Connect Antenna
Connect the small antenna (provided) to the "Remote Antenna" connector on the back panel of the
Hydra.
Hydra Quick Reference (P/N 95-810500-00) 1
