Toshiba Satellite Pro P205-S6247 Specification Sheet

Satellite P205-S6247 Detailed Product Specification
Model Name
: P205-S6247
C1 2
Operating System
• Genuine Windows Vista™ Home Premium(32-bit version)
Processor and Chipset
• Intel® Pentium® dual-core processor T2080
o 1.73GHz, 1MB L2, 533MHz FSB
• Mobile Intel® 943GML Express Chipset
4
Memory
• Configured with 1024MB PC2-5300 DDR2 SDRAM (both memory
slots may be occupied). Maximum capacity 2048MB
5
Hard Disk Drive
• 120GB (5400RPM); Serial ATA hard disk drive; 9.5mm height; user
removable
Fixed Optical Disk Drive
• DVD SuperMulti (+/-R double layer) with Labelflash™ drive
supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (16x), DVD-ROM (8x), DVD-R (Single Layer, (8x)),
DVD-R (Double Layer, (4x)), DVD-RW (6x), DVD+R (Single
Layer, (8x)), DVD+R (Double Layer, (4x)), DVD+RW (8x), DVD-
RAM (5x)
o Supports Labelflash™ media to burn high quality labels directly
on the disk.
7
Display
• 17.0" diagonal widescreen TruBrite™ TFT LCD display at 1440x900
native resolution (WXGA+)
o Native support for 720p content
8
Graphics
• Intel® Graphics Media Accelerator 950 with 8MB-256MB dynamically
allocated shared graphics memory
Sound
• Built-in stereo speakers
• Sound Volume Control Dial
• Built-in microphone
Input Devices
• 104 key US with 10-key
• TouchPad™ pointing device
• TouchPad™ Enable/Disable
• Control Buttons:
o Internet button to launch default browser
o CD/DVD control buttons (Skip to Previous/Next Track, Play, Stop)
Communications
• Webcam and microphone built into LCD bezel
• Modem
9
• 10/100 Ethernet
• Atheros® 802.11b/g wireless-LAN
Expandability
• 2 main memory slots. Both slots may be occupied.
• ExpressCard™ slot (ExpressCard/34 and ExpressCard/54)
• 5-in-1 Bridge Media Adapter
o Secure Digital, Memory Stick™, Memory Stick PRO™, Multi
Media Card, xD Picture Card [shared slots]
Ports
• Video
o RGB (monitor) output port
o S-Video output port
• Audio
o Microphone input port
o Headphone output port
• Data
o i.LINK(tm) IEEE-1394
Part Number:
3
6
© Copyright 2006 – 2007 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
P205-S6247 Rev. 1.10 2007-09-12 {DM} T20070214 CB1.00
This product specification is variable and subject to change prior to product launch.
1
PSPB0U-01300W
o USB v2.0 – 4 ports
Physical Description
• Dimensions (WxDxH Front/H Rear): 15.7" x 11.3" x 1.42" /1.83"
without feet
• Weight: From 7.2 lbs to 8.1lbs depending upon configuration
• LCD Cover Color: Onyx Blue Metallic
Power
• 75W (19V 3.95A) 100-240V AC Adapter.
o Dimensions (WxDxH): 5.04" x 1.20" x 2.01"
o Weight: starting at 0.77 lbs
11
Battery
• 4000mAh Lithium Ion battery pack
o Dimensions (WxDxH): 8.19" x 2.91" x 0.83"
o Weight: starting at 0.77 lbs
C1 12
Software
• Toshiba Software and Utilities
o TOSHIBA Value Added Package
o Electronic User's Guide
o Bluetooth Stack for Windows by Toshiba
o TOSHIBA ConfigFree®
o TOSHIBA Management Console
o TOSHIBA Assist
o TOSHIBA Security Assist
o TOSHIBA Disc Creator
o TOSHIBA Extended Tiles for Windows Mobility Center
o TOSHIBA Speech System
• Third-party Software
o TOSHIBA Game Console
o Microsoft Works Version 8.5
o Sun® Java™ 2 Runtime Environment
o Adobe® Acrobat® Reader 7.0
o Microsoft® Windows Media Player 11
o Google™ Desktop
o Google™ Toolbar
o Yahoo! Music™ Jukebox
o Protector Suite™ QL by UPEK®
o Ulead® DVD MovieFactory® for TOSHIBA
• Trial Software
o Microsoft Office Trial Home and Student 2007 Edition (60-day
trial)
o McAfee® Internet Security Suite (30-day trial)
• Special Offers
o EarthLink® Internet Service
o PeoplePC® Internet Service
o Toshiba Compare and Search for Broadband
o Microsoft Office Live
o Microsoft Money Essentials
Environmental Specifications
13
Temperature
Thermal Gradient
Relative Humidity
(non-condensing)
Altitude
(relative to sea level)
Shock
Vibration
• This product is RoHS
SATELLITE – 1 YEAR STANDARD LIMITED
15
WARRANTY
UPC:
032017833371
32
Operating Non-operating
5° to 35° C -20° to 65° C
(41° to 95° F) (-4° to 149° F)
15° C per hour (max) 20° C per hour (max)
20% to 80% 10% to 95%
-30 to 10,000 feet -30 to 40,000 feet
10G 60G
0.5G 1.0G
14
compatible
10
Page 2 of 5
