- Page 1 4KEX70-RX-PSE 70M HDMI Receiver with PoH User Manual...
- Page 3 AV Access Technology Limited assumes no responsibility for any inaccuracies that may be contained in this document. AV Access Technology Limited also makes no commitment to update or to keep current the information contained in this document.
- Page 4 Important Safety Instructions Do not expose this apparatus to rain, moisture, dripping or splashing. No objects filled with liquids, such as vases, shall be placed on the apparatus. Do not install or place this unit in a bookcase, built-in cabinet, or in another ...
-
Page 5: Table Of Contents
Table of Contents Introduction ......................2 Overview ..........................2 Features ............................ 2 Package Contents ........................3 Panel ............................4 Front Panel........................4 Rear Panel ........................5 Installation Instructions ..................6 Specification ......................8 Trouble shooting ....................10 Steps of Regular Troubleshooting Routine............10 Typical Questions ....................... -
Page 6: Introduction
Introduction Overview The 4KEX70-RX-PSE is an HDMI receiver designed to work with an HDBaseT transmitter, such as the 4KEX70-W, to extend HDMI signals up to 230ft (70m) for 1080P and 131ft (40m) for 4K@60Hz 4:2:0 8bit over a single Cat6a/7 cable. -
Page 7: Package Contents
Supports RS232 ports for firmware upgrade or serial communication Package Contents Before you start the installation of the product, please check the package contents: 4KEX70-RX-PSE x1 Power Supply (DC 12 V 1.5A) x1 Phoenix Male Connector (3.5 mm, 3 pins) x1 ... -
Page 8: Panel
Introduction Panel Front Panel Name Description ON: The receiver is powered on. Power LED OFF: The receiver is powered off. (Red) Blinking: The receiver is working properly. Status LED OFF: The receiver is not working properly. (Green) ON: HDMI signal is HDCP protected. HDCP LED Blinking: HDMI signal is not HDCP protected. -
Page 9: Rear Panel
Introduction Rear Panel Name Description DC 12V Connect to the DC 12V 1.5A power supply HDBT In Connect to the HDBaseT transmitter (4KEX70-W) Connect to the supplied broadband IR receiver. Secure IR In the IR receiver with adhesive. Connect to the supplied IR emitter. Secure the IR IR Out emitter on the IR window of the source/display device. -
Page 10: Installation Instructions
4K resolution. the center of the DVD IR window. 4KEX70-RX-PSE Connect the Connect the Connect the power IR receiver HDMI display Power supply DVD Remote Control the DVD at TV side with DVD remote control (4KEX70-RX-PSE) www.avaccess.com... - Page 11 Connect the Connect the IR emitter Connect the power HDMI display Note: The IR emitter head should be secured over the center of the TV IR window. Power supply Control the TV at DVD side with TV remote control (4KEX70-RX-PSE) www.avaccess.com...
-
Page 12: Specification
Specification Specification Technical Video Signal Type HDMI 1.4, HDCP 2.2 SMPTE: 1280x720P , 1920x1080I 1,2,3,4,5,6,7,8 1920x1080P 1,2,3,4,5,6,7,8 3840x2160 , 4096x2160 2,3,5,6,8 2,3,5,6,8 VESA: 800x600 , 1024x768 , 1280x768 , 1280x800 1280x960 , 1280x1024 , 1360x768 , 1366x768 Output Resolution Support 1400x1050 , 1440x900 , 1600x900... - Page 13 6.83” x 0.71’’ x 3.73” (W x H x D) (173mm x 18mm x 94.8 mm) Product Weight 0.4kg Cable Specifications: Note: AV Access recommends the use of straight-through Category cables wired to T568B standard. Cable Type Range Supported Video HDMI...
-
Page 14: Trouble Shooting
Trouble shooting Trouble shooting Steps of Regular Troubleshooting Routine Power: Please make sure the sources, display and receiver are powered on. Indicator: Please make sure LED indicators of transmitter and receiver are normal according to user manual. Devices: Please make sure picture can be shown normally when connecting source to display devices directly. -
Page 15: Typical Questions
Trouble shooting Typical Questions How to deal with video flash or cut off during the installation? Power indicator should be solid on and status indicator should be blinking. If not, please check if the power adapter is well connected. Link indicator should be solid on. - Page 16 Please make sure the third party device follows our pin definition as below: You can purchase the AV Access universal IR cable that will be compliant with any third party device (Amazon ASIN: "B01MYX46IC"). How to use the RS232 port in the device? The RS232 port provides a channel to pass through protocol commands to control third party devices such as your source or display.
- Page 17 Trouble shooting Control System RS232 Cable HDMI In CatX Cable RS232 Cable HDMI Out Projector www.avaccess.com...
-
Page 18: Warranty
The warranty has expired. The defects are caused by the fact that the product is repaired, dismantled or altered by anyone that is not from an AV Access Technology Limited authorized service partner. The defects are caused by the fact that the product is used or handled improperly, roughly or not as instructed in the applicable User Guide. - Page 20 AV Access Technology Limited V1.0.0...
