Toshiba Qosmio X305-Q701 Specifications

Qosmio X305 Detailed Product Specification
Model Name X305-Q701
:
C1 2
Operating System
• Genuine Windows Vista ®
Home Premium (SP1, 64-bit version)
• Genuine Windows Vista
®
Home Premium (SP1, 32-bit version)
Processor and Chipset
• Intel
®
Core™ 2 Duo Processor P7350
o 2.0GHz, 3MB L2 Cache, 1066MHz FSB
• Mobile Intel
®
PM45 Express Chipset
4
Memory
• Configured with 4096MB PC3-8500 DDR3 1066MHz SDRAM (both
memory slots may be occupied). Maximum capacity 4096MB
5
Hard Disk Drive
• 200GB (7200 RPM) Serial ATA hard disk drives
Fixed Optical Disk Drive
• DVD SuperMulti (+/- double layer) drive with Labelflash™ supporting 11
formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (16x), DVD-ROM (8x), DVD-R (Single Layer, (8x)),
DVD-R (Double Layer, (6x)), DVD-RW (6x), DVD+R (Single
Layer, (8x)), DVD+R (Double Layer, (6x)), DVD+RW (8x), DVD-
RAM (5x)
o Supports Labelflash™ media to burn high quality labels directly
7
Display
• 17.0" diagonal widescreen TruBrite
1440x900 native resolution (WXGA+)
8
Graphics
• PCI-Express™ x16 graphics subsystem, featuring:
® ®
o NVIDIA GeForce 9700M GTS, 512MB GDDR3 discrete
graphics memory, plus up to 1791MB dynamically allocated
shared graphics memory using NVIDIA
technology.
o Total Available Graphics memory 2303MB (64-bit version)
Sound
• 4 built-in harman/kardon
®
speakers including 1 sub-woofer
• Sound volume control dial
• Built-in microphone
Input Devices
• 104 key US keyboard
• TouchPad™ pointing device
• Control Buttons:
o Mute button
o Media button
o CD/DVD control buttons (Play/Pause, Stop, Previous Track, Next
Track)
o Panel lights
o Camera
o Dolby settings
Communications
• Webcam and microphone built into LCD bezel
• Modem 9
• Bluetooth ®
version 2.1 plus Enhanced Data Rate (EDR)
• 10/100/1000 Ethernet
• Integrated Wi-Fi
®
compliant wireless:
®
o Atheros 802.11 b/g/n wireless-LAN
Expandability
• 2 main memory slots. Both slots may be occupied.
• ExpressCard™ slot (ExpressCard/34 and ExpressCard/54)
• 5-in-1 Bridge Media Adapter
o Secure Digital, Memory Stick™, Memory Stick PRO™, MultiMedia
Card, xD Picture Card [shared slots]
Part Number: PQX32U-01Q017
3
6
®
TFT active-matrix LCD display at
®
TurboCache™
10
11
© Copyright 2007 – 2008 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
This product specification is variable and subject to change prior to product launch.
1
Ports
• Video
o RGB (monitor) output port
o REGZA LINK™ (HDMI-CEC)
• Audio
o S/P DIF output port (shared with headphone port)
o Microphone input port
o Headphone output port
• Data
o i.LINK™ IEEE-1394
o USB v2.0 – 4 ports with sleep and charge
o RJ-45 LAN port
o RJ-11 modem port
Physical Description
• LCD Cover Color: Rogue™
• Dimensions (WxDxH Front/H Rear): 16.2" x12.0" x 1.7" /2.5" with feet
• Weight: Starting at 8.99 lbs, depending upon configuration
Power
• 180W (19V x 9.5A) Auto sensing ,100-240V/50-60Hz AC Adapter
o Dimensions (WxDxH): 6.73" x 3.39" x 1.63"
o Weight: starting at 1.94 lbs
14
Battery
• 4000 mAh Lithium Ion battery pack
C1
Software
• Toshiba Software and Utilities
o TOSHIBA Value Added Package
o Electronic User's Guide
o Bluetooth Stack for Windows by Toshiba
o TOSHIBA ConfigFree
o TOSHIBA Disc Creator
o TOSHIBA DVD Player
o TOSHIBA Extended Tiles for Windows Mobility Center
o TOSHIBA Speech System
o TOSHIBA Face Recognition
o TOSHIBA Recovery Disc Creator
o Hard disc (HDD) recovery
• Third-party Software
o TOSHIBA Games Console, designed by WildTangent
®
o Sun Java™ 2 Runtime Environment
o Adobe
o Ulead
o Computrace
o PowerCinema for Toshiba
o memeo AutoBackup
• Trial Software
o Microsoft
60-day trial edition Microsoft
o Norton™ 360™ All-In-One Security
• Special Offers
o Microsoft
o Shutterfly
o Skype™
o PhotoWorks
®
o Intuit
o NetZero
Environmental Specifications
16
Temperature
Qosmio X305-Q701 1.1
UPC: 883974117642
o 1080p support
o 3 x USB v2.0
o 1 x eSATA/USB combo port
15
®
® ®
Acrobat Reader
® ®
DVD MovieFactory 5 for TOSHIBA
® ®
LoJack for Laptops
®
Office Ready with Microsoft Office Professional 2007
®
Office Live
®
digital photo print provider
®
digital photo print provider
®
Quickbooks Financial Center
®
Internet Service
Operating
5° to 35° C
(41° to 95° F)
12
13
®
Non-operating
-20° to 65° C
(-4° to 149° F)
