Toshiba Tecra M7-ST4013 Detailed Product Specification

Tecra M7-ST4013 Series Detailed Product Specification
Model Name Description
M7-ST4013 Genuine Windows® XP Tablet Edition 2005, Intel® Core™ Duo Processor T2300E,
512MB DDR2, 40GB 5400rpm (S-ATA), CD-RW/DVD-ROM Drive, 14.1" WXGA+ Wide
Viewing Angle, NVIDIA Quadro NVS 110M with128MB, Intel® PRO/Wireless 3945ABG
(802.11a/b/g), 1Gbps LAN, 5-in-1 Bridge Media Adapter, 1-year standard limited
warranty.
Section 1.01 Operating System
• Genuine Windows® XP Tablet Edition 2005
• Windows Vista™ Capable
Section 1.02 Processor and Chipset
Intel® Centrino® Duo Mobile Technology featuring:
• Choice of Processor
o Intel® Core™ Duo Processor T2300E
1.66GHz, 2MB L2, 667MHz FSB
o Intel® Core™ Duo Processor T2400
1.83GHz, 2MB L2, 667MHz FSB
o Intel® Core™ Duo Processor T2500
2.00GHz, 2MB L2, 667MHz FSB
o Intel® Core™ Duo Processor T2600
2.16GHz, 2MB L2, 667MHz FSB
o Intel® Core™ Duo Processor T2700
2.33GHz, 2MB L2, 667MHz FSB
o Intel® Core™ 2 Duo Processor T5600
1.83GHz, 2MB L2, 667MHz FSB with
64-bit
o Intel® Core™ 2 Duo Processor 7200
2.00GHz, 4MB L2, 667MHz FSB with
64-bit
o Intel® Core™ 2 Duo Processor T7400
2.16GHz, 4MB L2, 667MHz FSB with
64-bit
o Intel® Core™ 2 Duo Processor T7600
2.33GHz, 4MB L2, 667MHz FSB with
64-bit
• Chipset
o Mobile Intel® 945PM Express Chipset
• Integrated Wi-Fi® compliant wireless LAN
o Intel® PRO/Wireless 3945ABG (802.11a/b/g)
Section 1.03 Memory
• Configured with 512MB PC4200 DDR2 SDRAM (1 memory slot
occupied, 1 available)
• 512MB (Min)/4096MB (Max), with 256MB, 512MB, 1024MB or
2048MB PC4200 or PC5300 DDR2 memory modules.
Section 1.04 Choice of Hard Disk Drive
• 40GB, 60GB, 80GB, 100GB, 120GB (5400RPM) or 100GB
(7200RPM) Serial-ATA (SATA) hard disk drive; 9.5mm height;
user removable
Section 1.05 Choice of Fixed Optical Disk Drive
• CD-RW/DVD-ROM
o Maximum speed and compatibility: CD-ROM (24x), CD-R
(24x), CD-RW (10x), DVD-ROM (8x)
• DVD SuperMulti (+/-R double layer) drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R
(24x), CD-RW (10x), DVD-ROM (8x), DVD-R (Single
Layer, (8x)), DVD-R (Double Layer, (2x)), DVD-RW (4x),
2
3
4
CPU_64
CPU_64
CPU_64
CPU_64
5
6
© Copyright 2005 – 2006 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Tecra M7-ST4013 BTO Rev. 1.04 2006-12-07 SK T20060428 CB1.00
1
Section 1.06 Display
• 14.1" diagonal widescreen TFT active-matrix High Brightness LCD
display at 1440x900 native resolution (WXGA+) with Wide
Viewing Angle
Section 1.07 Graphics
• PCI-Express™ x16 graphics subsystem, featuring:
Section 1.08 Sound
• Built-in stereo speakers
• Sound Volume Control Dial
• Built-in microphone
Section 1.09 Input Devices
• Keyboard
• TouchPad™ pointing device
• TouchPad™ Enable/Disable
• Control Buttons:
Section 1.10 Communications
• Toshiba V.92 software modem
• Intel® PRO/1000 VE Network Connection - 10/100/1000 Base-TX
Ethernet
• Choice of Integrated Wireless-LAN
• Optional Bluetooth® version 2.0 plus Enhanced Data Rate (EDR)
with Toshiba Bluetooth driver software
Section 1.11 Expandability
• 2 main memory slots. Both slots may be occupied.
• One PCMCIA – Type II/Type I Card Slot
• 5-in-1 Bridge Media Adapter
7
Section 1.12 Ports
• Video
• Audio
Part Number
PTM71U-0EG015
DVD+R (Single Layer, (8x)), DVD+R (Double Layer,
(2.4x)), DVD+RW (4x), DVD-RAM (5x)
8
9
o NVIDIA Quadro NVS 110M with TurboCache™ and
128MB of dedicated graphics memory
o 84 key US keyboard
o Hot Key Functions (Fn)
o Windows Key Function
o Application Key Function
o Toshiba Assist button to launch Toshiba Assist control
panel
o Presentation button to quickly connect to projectors
11
12
o Intel® PRO/Wireless Network Connection 3945ABG
(802.11a/b/g)
o Atheros® 802.11a/b/g wireless-LAN
o Secure Digital, Memory Stick™, Memory Stick PRO™,
Multi Media Card, xD Picture Card [shared slots]
o Secure Digital slot supports SDIO
o RGB (monitor) output port
o S-Video output port
UPC
032017638013
10
:
