- Page 1 IN-CEILING SPEAKERS FYNE ADVICE ESSENTIAL INFORMATION GUIDE...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction Safety Unpacking Positioning Installation Grille Painting Warranty Specifications... -
Page 4: Introduction
FA502iC - 1 x 8” IsoFlare™ loudspeaker, 1 x round grille, 1 x square grille, 1 x mounting template • FA502iC LCR - 1 x 8” IsoFlare™ loudspeaker, 1 x round grille, 1 x mounting template NOTE: Optional square grilles can be supplied for the FA301iC & FA302iC models (please contact your Fyne Audio distributor). -
Page 5: Positioning
Below is an example of a typical 2 channel set up in (Fig 1) and a 5.1 channel set up in (Fig 2). • FA301iC & FA302iC - The Coaxial tweeter should be angled to point towards the centre of the primary listening area. To do this, press down on the silver trim edge of the tweeter firmly, to achieve the desired angle. •... -
Page 6: Installation
5 INSTALLATION Ensure there are no joists behind the intended Always use a good quality loudspeaker cable, allowing location using a stud location tool. sufficient length for the loudspeaker to be easily installed or removed. Connect to the two spring Place the supplied self-adhesive mounting template terminals, being careful to observe polarity, positive to on the ceiling, prior to cutting with a keyhole saw or positive and negative to negative. -
Page 7: Grille Painting
If you suspect a problem with a Fyne Audio Limited product, in the first instance, discuss it with your Fyne Audio Limited dealer. If you require further assistance, then we ask that you deal directly with your local Fyne Audio Limited distributor. If you cannot locate your distributor please contact Fyne Audio Limited Customer Services, via our website listed above or at the e-mail enquiries@fyneaudio.com... -
Page 8: Specifications
8 SPECIFICATIONS Model FA301iC FA302iC System type 2 way co-axial loudspeaker 2 way co-axial loudspeaker for in ceiling or in wall for in ceiling or in wall application, steerable HF unit application, steerable HF unit Recommended amplifier 25- 100 25- 120... - Page 9 Model FA501iC FA502iC FA502iC LCR System type 2 way IsoFlare loudspeaker 2 way IsoFlare loudspeaker 2 way IsoFlare loudspeaker for in ceiling or in wall application for in ceiling or in wall application for in ceiling or in wall application angled dispersion for LCR applications Recommended amplifier 30- 125...
- Page 10 ENJOY.
- Page 12 Thank you for choosing Fyne Audio loudspeakers, proudly designed by our experienced team of engineers in Scotland, and constructed to the highest standards. WWW.FYNEAUDIO.COM FYNEAUDIO @FyneAudio F6480 0007 | 19 June 2019...
