Blizzard, PO Box 245038, Milwaukee, WI 53224-9538 • www.blizzardplows.com
Dodge Dakota
Parts List & Installation Instructions
B32221
Undercarriage Kit
CAUTION
Read this document before installing the
snowplow.
CAUTION
See your BLIZZARD
outlet/Web site for
®
specific vehicle application recommendations
before installation. The Undercarriage
Selection Guide has specific vehicle and
snowplow requirements.
A DIVISION OF DOUGLAS DYNAMICS, LLC
April 15, 2014
Lit. No. B64055, Rev. 04
2005 - 11
Advertisement
Table of Contents
Related Manuals for Blizzard B32221
Summary of Contents for Blizzard B32221
- Page 1 Blizzard, PO Box 245038, Milwaukee, WI 53224-9538 • www.blizzardplows.com April 15, 2014 Lit. No. B64055, Rev. 04 B32221 Undercarriage Kit Dodge Dakota 2005 - 11 Parts List & Installation Instructions CAUTION Read this document before installing the snowplow. CAUTION See your BLIZZARD outlet/Web site for ®...
- Page 2 SAFETY SAFETY DEFINITIONS WARNING/CAUTION & INSTRUCTION LABELS WARNING Become familiar with and inform users about the Indicates a potentially hazardous situation warning and instruction labels on the back of the that, if not avoided, could result in death or blade. serious personal injury.
- Page 3 SAFETY SAFETY PRECAUTIONS PERSONAL SAFETY Improper installation and operation could cause • Remove ignition key and put the vehicle in park or personal injury and/or equipment and property damage. in gear to prevent others from starting the vehicle Read and understand labels and the Owner's Manual during installation or service.
- Page 4 SAFETY & TORQUE SPECIFICATIONS NOISE Airborne noise emission during use is below 70 dB(A) for the snowplow operator. VIBRATION Operating snowplow vibration does not exceed 2.5 m/s to the hand‑arm or 0.5 m/s to the whole body. TORQUE CHART CAUTION Read instructions before assembling.
- Page 5 PUSHBEAM PUSHBEAM HEIGHT The recommended pushbeam height for this undercarriage assembly is 10‑1/2" from the center of the pushbeam to level ground. DO NOT exceed 12‑1/2" in height for this undercarriage. 10-1/2" Lit. No. B64055, Rev. 04 April 15, 2014...
- Page 6 UNDERCARRIAGE INSTALLATION 4. Thread the nutplate (Item 8) into the front NOTE: For easier assembly and installation, openings on the frame. vehicle and all snowplow components should be on a smooth, level, hard surface, such as NOTE: The nutplate is designed so you can concrete.
- Page 7 UNDERCARRIAGE PARTS LIST B32221 Undercarriage Kit Item Part Qty Description Item Part Qty Description B32220 Pushbeam B32217 Hanger Plate – PS B63162 Label, Pushbeam B32218 Hanger Plate – DS B61309 Split Ring, 1.25 OD B32216 Nutplate B61000 Compression Spring SS...
- Page 8 Blizzard or the vehicle manufacturer may require or recommend optional equipment for snow removal. Do not exceed vehicle ratings with a snowplow. Blizzard offers a limited warranty for all snowplows and accessories. See separately printed page for this important information. The following are registered ( ) or unregistered (™) trademarks of...
