Quick Start for Hardware
Installation:
Avaya G250 Media Gateway
03-300433
Issue 5
November 2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G250 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Avaya G250

Summary of Contents for Avaya G250

  • Page 1 Quick Start for Hardware Installation: Avaya G250 Media Gateway 03-300433 Issue 5 November 2009...
  • Page 2 Avaya support Avaya provides a telephone number for you to use to report problems or to ask questions about your product. The support telephone number is 1-800-242-2121 in the United States. For additional support telephone...

  • Page 3: Table Of Contents

    Attaching Mounting Brackets ......Mounting the G250....... . .
  • Page 4 Next steps ........Using Avaya IW and GIW ......

  • Page 5: Chapter 1: Before You Start

    Chapter 1: Before you Start Before you install your Avaya G250 Media Gateway, prepare all the information, resources, and tools that you need during the installation process. Good preparation ensures a smooth installation with the least amount of interruption. Note:...

  • Page 6: Preparing Contacts You Might Need

    Activation (RFA) User Guide, 03-300149. Preparing the G250 Serial Number In order to create the license file, you need the serial number of the G250. The serial number is printed on a sticker on the back of the G250 chassis.

  • Page 7: Preparing The Gateway Authentication File

    The INADS IP address is required in order to configure the S8300 modem for alarming. If you are preparing a G250 with an S8300 for a remote install, you must first obtain an INADS IP address. You use the Automatic Registration Tool (ART) to obtain an IP address for an INADS alarming modem.

  • Page 8: Preparing Needed Hardware

    Preparing Needed Hardware Laptop To configure the Avaya G250 Media Gateway, you need to prepare a laptop with a serial port. The laptop must have Internet Explorer installed. If you install a G250 without an S8300, you must prepare the laptop with the following software: Windows 2000 or Windows XP operating system ●...

  • Page 9: Choosing The Installation Site

    5% to 95%, non-condensing Minimum clearance for 2.5 in. (6.4 cm) ventilation Weight support 22 lb. (10 kg) See Appendix A of Installing and Upgrading the Avaya G250 Media Gateway, 03-300434, for additional information on environmental requirements. Issue 5 November 2009...
  • Page 10 Before you Start 10 Quick Start for Hardware Installation Avaya G250 Media Gateway...

  • Page 11: Chapter 2: Unpack The Device

    Avaya G250 Media Gateway. Connect the strap to an approved ground, such as an unpainted metal surface. Equipment Open the box that contains the Avaya G250 Media Gateway, and ensure that it contains the following components and accessories: One Avaya G250 Media Gateway chassis, with blanking plates over empty module slots.
  • Page 12 Unpack the Device One RJ45 to DB9F Adapter One DB25M Adapter One Grounding Cable Assembly Four (4) Rubber Standoffs 12 Quick Start for Hardware Installation Avaya G250 Media Gateway...
  • Page 13 Equipment Two (2) 19" Rackmount Brackets One Cable Management riveting Assembly Nine (9) 5/16" (8 mm) Flat-Head Screws One Bridge for NVRAM init Issue 5 November 2009...

  • Page 14: Other Components

    Other Components Media modules to connect voice and data devices, and outside lines are packaged and shipped in separate boxes. The Avaya Partner Contact Closure adjunct box, if ordered, is also packaged separately. 14 Quick Start for Hardware Installation Avaya G250 Media Gateway...

  • Page 15: Chapter 3: Mount The Device

    Chapter 3: Mount the Device You can position the Avaya G250 Media Gateway on a suitable table, or mount it in a rack or on the wall. Positioning on a Table To install the Avaya G250 Media Gateway as a tabletop unit: 1.

  • Page 16: Front Mounting Bracket Placement

    Mounting Bracket Placement on page 16). Mounting bracket with cable guide Attach a mounting bracket with cable guides on one side of the G250, near the front (refer to Figure 2: Attaching a mounting bracket with cable guides on page 17).

  • Page 17: Attaching Mounting Brackets

    Mounting the G250 Follow these steps to mount the G250: 1. Position the G250 in the rack. Ensure that there is adequate ventilation. 2. Verify that the screw holes are aligned with the rack hole positions. 3. Insert two mounting screws on each side.

  • Page 18: Mounting On The Wall

    To mount the G250 on a wall, use the two mounting brackets without cable guides. If the wall is flat, you can screw the G250 directly to the wall. If the wall is not flat, screw a 48 in. x 48 in. (1.2 m x 1.2 m) plywood board (US: 3/4 inch plywood), 0.75 in (20 mm) thick, to the wall with wood...

  • Page 19: Chapter 4: Install Media Modules

    S8300 Server. Tip: If the product is staged, then the media modules are already installed. Tip: Figure 4: The G250 front panel ports and slots 10 11 Figure 5: The G250-BRI front panel ports and slots 10 11 Issue 5 November 2009...

  • Page 20: Installing An S8300 Server

    17. T1/E1 ports (G250-DS1 only) Installing an S8300 Server Note: The S8300A is not compatible with the G250. See Identifying the S8300 Note: page 21 for information on identifying the S8300 version. 20 Quick Start for Hardware Installation Avaya G250 Media Gateway...

  • Page 21: Identifying The S8300

    The S8300A faceplate is white; the faceplate of the S8300B/C/D is grey. ● Figure 8: The S8300 Media Server Module Note: You can only insert the S8300 in slot V1 on the left side of the Avaya G250 Media Note: Gateway. To install an S8300 Media Server Module: 1.

  • Page 22: Installing Other Media Modules

    Install Media Modules Installing other Media Modules Supported Modules The G250 does not support all Media Modules. Before you insert other Media Modules, review the following list for combination limitations. The Avaya G250 Media Gateway supports the following modules only: S8300 Media Gateway in slot V1 ●...

  • Page 23: Chapter 5: Power Up

    You must use two safety grounds to ensure safe operation of the Avaya G250 Media Gateway: the ground conductor that is part of the AC power cord.

  • Page 24: Connecting Ground Conductors

    2. Attach the remaining end of the Supplementary Ground Conductor to a terminal in the ground block. 3. Cut this ground wire to the length needed to reach the approved ground. Do not coil this wire. 24 Quick Start for Hardware Installation Avaya G250 Media Gateway...

  • Page 25: Connecting Power

    2. Connect the other end of the power cable into a mains socket. LED Sequence When you turn on the G250, the following LED sequence occurs: 1. The PWR and ALM LEDs on the front panel light. 2. The CPU LED lights up after approximately 15 seconds if the firmware is running.
  • Page 26 Power Up 26 Quick Start for Hardware Installation Avaya G250 Media Gateway...

  • Page 27: Chapter 6: Prepare For Configuration

    Chapter 6: Prepare for Configuration Before you prepare the G250 for configuration, ensure that you load the completed Electronic Pre-Installation Worksheet onto the laptop. You should also load any CM license and authentication files and any firmware files that you have prepared onto the laptop.

  • Page 28: Configuring The G250 And S8300 Using The Avaya Iw

    Installation Wizard (IW) opening screen appears. Configuring the G250 and S8300 using the Avaya IW Step through the screens of the Avaya IW to configure the S8300 and the G250. Take note of the following items: 1. On the initial IW screen, you can upgrade the wizard if you have a more current version of the AIW.rpm wizard file.
  • Page 29 14. On the IP Addresses screen, click to configure the following information for the G250: a. To specify the details of the Primary Management Interface of the G250, use the PMI screen. b. To specify SNMP community strings and trap destinations, use the SNMP screens.

  • Page 30: Preparing A G250 Without An S8300 Server

    Preparing a G250 without an S8300 server You can use the Gateway Installation Wizard (GIW) to configure the Avaya G250 Media Gateway without an S8300. You can perform the configuration on site, or prepare the G250 for a remote configuration.

  • Page 31: Preparing For A Remote Configuration Of The G250

    Click to configure the following information for the media gateway: a. To specify the details of the Primary Management Interface of the G250, use the PMI screen. b. To specify SNMP community strings and trap destinations, use the SNMP screens.

  • Page 32: Preparing For A Remote Configuration Of The G250 Via A Modem

    CLI. Preparing for a remote configuration of the G250 via a modem If you need to prepare the G250 for a remote configuration via a modem, you must attach a modem and enable it using the GIW.

  • Page 33: Next Steps

    5. Connect the modem that you specified in Step 2 and plug in a loop start dial tone line into it . 6. Dial in to the modem to ensure that it is set up correctly. 7. A remote technician can now dial in to the G250 and complete the configuration using the CLI interface.
  • Page 34 Prepare for Configuration 34 Quick Start for Hardware Installation Avaya G250 Media Gateway...
