1936
HOT WATER GENERATOR HEALTH TO
BUILD A HOUSE OPEN AND NATURAL
DRAFT (type B)
TX160
TX220
TX300
TX400
TX600
TX800
ENG - Manual installation, use and
maintenance.
Original instructions.
Read and follow these instructions before installing the unit.
Always keep on hand this manual during the maintenance phase.
This manual is also available in electronic format and can be downloaded from the website
www.atimariani.it
210-0197_Libretto_TX_ATI_2020-02_ATI-eng
1
ed. 2020-02
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ATI Technologies TX220
Summary of Contents for ATI Technologies TX220
- Page 1 1936 HOT WATER GENERATOR HEALTH TO BUILD A HOUSE OPEN AND NATURAL DRAFT (type B) TX160 TX220 TX300 TX400 TX600 TX800 ENG - Manual installation, use and maintenance. Original instructions. Read and follow these instructions before installing the unit. Always keep on hand this manual during the maintenance phase.
-
Page 2: Table Of Contents
GENERAL INFORMATION AND FEATURES SUMMARY 1. SYMBOLS IN THE MANUAL ....................3 2. GENERAL WARNINGS ......................3 3. TRANSPORTATION, STORAGE AND RECYCLING..............3 CONTENT, WEIGHT AND DIMENSIONS OF PACKAGE ............4 DEVICE CATEGORY ........................ 4 TECHNICAL DATA........................4 DIMENSIONS AND EQUIPMENT ..................... 5 DESTINATION COUNTRIES AND GAS CATEGORIES ............ -
Page 3: Symbols In The Manual
GENERAL INFORMATION AND FEATURES 1. SYMBOLS IN THE MANUAL In reading this book, particular attention should be given to the parts marked with symbols represented: DANGER! NOTE! WARNING! serious danger to the life and limb Tips for users Possible dangerous situation for the product and the environment 2. -
Page 4: Content, Weight And Dimensions Of Package
Make sure that both parts (1 and 2) are present and that they are not damaged during transport TX160 cm 58 x 58 x 185 cm 46 x 46 x 23 131 kg 5 kg TX220 cm 78 x 78 x 141 cm 68 x 68 x 25 184 kg 6 kg TX300... -
Page 5: Dimensions And Equipment
* T accumulation 70 ° C - 10 ° C cold T 6 DIMENSIONS AND EQUIPMENT TX160 2038 ¾ " 1743 Recirculation ¾ " ½ " Cold ¾ " Dimensions in millimeters: mm TX220 TX300 TX400 TX600 TX800 1600 1960 2310 1919 2269 1 "1/4 1330... -
Page 6: Destination Countries And Gas Categories
GENERAL INFORMATION AND FEATURES 7 DESTINATION COUNTRIES AND GAS CATEGORIES Country (EN ISO 3166- Category: gas / pressure type (EN 437): I2H, II 2H3P appliance G20 - 20 mbar I2E +, II2E 3P + G20 - 20 mbar; G31 - 37 mbar I2H, II 2H3P appliance G20 - 20 mbar;... -
Page 7: Equipment Components
GENERAL INFORMATION AND FEATURES B. RED LIGHT BLOCK Report device lock, to unlock, hold down the button for 3 seconds. C. SWITCH It allows switching on and off. D. LIGHT GREEN POWER Report proper burner ignition. Comes into operation when the combustion chamber is fed. E. -
Page 8: Wiring
GENERAL INFORMATION AND FEATURES 10 WIRING L: Line N: Neutral THE: Switch SB: red lock lamp RESET: reset button T: Control thermostat SA: Power indicator VG1: valve GAS TS: Water Safety thermostat TF: Flue safety thermostat ACC: Ignition electrode ION: Detection electrode F1: Fuse 4 A fast type 250 F2: Fuse 2 A quick type 250 V... -
Page 9: Local Regulations, And Installation Of Safety
INSTALLATION INSTRUCTIONS 11 LOCAL REGULATIONS, AND INSTALLATION OF SAFETY LOCAL REGULATIONS In the installation the local regulations must be observed regarding: Fire fighters Gas Company power Company Office hygiene and health SAFETY RULES Do not perform any cleaning or maintenance work without turning off the water heater and interrupting power supply. -
Page 10: Installation
INSTALLATION INSTRUCTIONS 12 INSTALLATION TO AVOID DAMAGE THE TRANSACTION MUST BE CARRIED OUT BY A QUALIFIED Before installing the appliance, ensure that the nominal supply voltage is 230 V - 50 Hz. Make sure that the electrical system is adapted to deliver, in addition to the operating current required by the unit, also the necessary current for powering appliances and equipment already in use. -
Page 11: Break Wind Installation Draw
INSTALLATION INSTRUCTIONS IMPORTANT: follow the provisions laid down by national installation regulations. 14 INSTALLATION DEVICE BREAK-DRAFT DEFLECTOR The device break-wind hood A is supplied not assembled. It should be fixed using the screws provided in the upper part (B) of the device during installation. For it is then connected to the conduit for the evacuation of exhaust fumes, which must be of a diameter not less than the break-wind hood device (Ø... -
Page 12: Hydraulic Connections
INSTALLATION INSTRUCTIONS 16 HYDRAULIC CONNECTIONS The appliance will last longer if they are met, as provided by D. LGS. February 2, 2001, 31 (implementation of Directive 98/83 / EC on the quality of water intended for human consumption), the following parameters: 1. -
Page 13: Trunk Gas
ADJUSTING GAS: the device is already calibrated in the factory to the pressure of the feed gas for which it was prepared (shown in the label serial number and packaging). G20 gas (H-gas or methane) TX160 TX220 TX300 TX400 TX600... - Page 14 INSTALLATION INSTRUCTIONS Model 160 Turn off the machine, close the gas shut-off valve and remove the power supply Remove the burner door (A) and the insulating material (B) POWER CONVERSION TO PROPANE GAS G31 TRANSFORMATION POWER GAS NATURAL GAS Unscrew the 4 screws (C), place the mask (D) in Unscrew the 4 screws (C), removing the mask (D) in front of the burner and tighten the screws (C) front of the burner and tighten the screws (C)
-
Page 15: Electrical Connections
INSTALLATION INSTRUCTIONS 10) Adjust the pressure to the burner, according to the specified value, through the REG screw on the gas valve. To check the value you can use the outlet pressure of P.OUT 11) Replace the burner door (A) in position originaliee tighten the fixing screws. 12) Stick the label contained in the kit to indicate the new type of gas supply. -
Page 16: Recommendations For You
INSTRUCTIONS FOR THE USER 21 RECOMMENDATIONS FOR YOU • Keep this booklet for future reference. The booklet should be kept near the stove. • For free verify the correct installation of the device, the end user can directly contact one of the closest authorized service centers. -
Page 17: Shutdown
INSTRUCTIONS FOR THE USER wait about one minute, reset it by pressing the red illuminated button6: Restart a new ignition cycle. Repeat until the residual air has been purged and the ignition is regular. e) After the ignition of the burner, indicated by the green light 5, Begins the phase of heating water. The burner will operate until the water temperature set on the thermostat. -
Page 18: Validation Of The Warranty
INSTRUCTIONS FOR THE USER It has occurred, during an intermittent operation cycle, one of the cases of the previous point. The generator runs for short intermittent periods, even if the thermostat is working properly and is in heat demand position. - Page 19 INSTRUCTIONS FOR THE USER 210-0197_Libretto_TX_ATI_2020-02_ATI-eng ed. 2020-02...
- Page 20 ATI DI MARIANI SRL Via E. Mattei, 461 Zona Ind. No. 4 Torre del Moro 47522 Cesena (FC) - ITALY Tel. 0547 609711 www.atimariani.it info@atimariani.it 210-0197_Libretto_TX_ATI_2020-02_ATI-eng ed. 2020-02...
