Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with instructions
contained in this manual, may cause harmful interference to radio and
television communications. However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
-
REORIENT OR RELOCATE THE RECEIVING ANTENNA
-
INCREASE THE SEPARATION BETWEEN THE EQUIPMENT AND THE RECEIVER
-
CONNECT THE EQUIPMENT INTO AN OUTLET ON A CIRCUIT DIFFERENT FROM
THAT OF THE RECEIVER
-
CONSULT THE DEALER OR AN EXPERIENCED AUDIO/TELEVISION TECHNICIAN
NOTE: Connecting this device to peripheral devices that do not comply with
Class B requirements, or using an unshielded peripheral data cable,
could also result in harmful interference to radio or television reception.
The user is cautioned that any changes or modifications not expressly
approved by the party responsible for compliance could void the user's
authority to operate this equipment.
To ensure that the use of this product does not contribute to interference,
it is necessary to use shielded I/O cables.
Copyright
This manual is copyrighted with all rights reserved. No portion of this manual may be
copied or reproduced by any means.
While every precaution has been taken in the preparation of this manual, no responsibility
for errors or omissions is assumed. Neither is any liability assumed for damages resulting
from the use of the information contained herein.
Trademarks
All brand names, logos and registered trademarks mentioned are property of their
respective owners.
Electronic Emission Notices
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PC Partner 35891900 Series
Summary of Contents for PC Partner 35891900 Series
- Page 1 Electronic Emission Notices Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 2: Table Of Contents
Table of Contents HARDWARE CONFIGURATION ..............3 Key Features ....................3 Motherboard Layout (Model Code No. - 35891900XX) ....... 5 Jumper Settings ..................6 CPU Speed Selection ................6 JP1, JP2 - System Bus Frequency ............6 JP7 - Ratio of Processor Core to System Bus Frequency ....7 JP3 - CMOS Clear .................. -
Page 3: Hardware Configuration
HARDWARE CONFIGURATION The motherboard is based on the VIA® Apollo Pro 133 Chipset. The chipset is a highly integrated solution enabling a high performance motherboard and desktop design for the Pentium® II/III processor. The main board supports standard DIMM module, 66/100/133MHz DIMM module or Registered DIMM module. - Page 4 • Transfer rate up to 33MB/sec or 66MB/sec to cover PIO mode 4, Multi-word DMA mode 2 drives and UltraDMA33/66 interface. • One ECP/EPP parallel port. • Two 16550 Compatible UART serial ports. • One floppy port, supports two FDD of 360KB, 720KB, 1.2MB , 1.44MB and 2.88MB capacity.
-
Page 5: Motherboard Layout (Model Code No. - 35891900Xx)
Motherboard Layout (Model Code No. - 35891900XX) The following diagrams show the relative positions of the jumpers, connectors, major components and memory banks on the motherboard. Warning: All connectors on board are labeled Pin “1” at one conner. Ribbon cables should always be connected with the red stripe on the Pin “1”... -
Page 6: Jumper Settings
Jumper Settings This chapter explains how to configure the motherboard’s hardware. Before using your computer, make sure all jumpers and DRAM modules are set correctly. Refer to this chapter whenever in doubt. CN41 CPU Speed Selection When JP7 is installed on this motherboard, jumper is required to be set for different type of CPU installed. -
Page 7: Jp7 - Ratio Of Processor Core To System Bus Frequency
JP7 - Ratio of Processor Core to System Bus Frequency Ratio of System Ratio of System JP3 - CMOS Clear Selection (1-2)* Normal operation* (2-3) CMOS Clear JP8 - BIOS Voltage Selection Voltage Selection (2-3)* +5V * ATMEL/SST/Winbond (2MB) (1-2) +12V MX(2MB) JP8 is pre-installed in the factory. -
Page 8: Cn41 - Pc Speaker Beep To Outer Speaker Setting
CN41 - PC Speaker Beep to Outer Speaker Setting CN41 PC Speaker Beep to Outer Speaker Setting (Close) Enable PC speaker beep to outer speaker (Open)* Disable PC speaker beep to outer speaker* Warning: Before handling the motherboard from its original package, please ensure that there is no static electricity on your body. -
Page 9: Memory Configuration
Memory Configuration You can install DIMM memory in the motherboard DIMM sockets. The board has DIMM sockets arranged as banks 1, and 2. You can install DIMMs in any of the two banks, and use different size DIMMs in different banks. The BIOS detects the size and type of installed memory. -
Page 10: To Install Dimms
To install DIMMs 1. Turn off all peripheral devices connected to the computer. Turn off the computer. 2. Remove the computer cover and locate the DIMM sockets. 3. Holding the DIMM by the edges, remove it from its antistatic package. 4. -
Page 11: Bios Setup
BIOS SETUP This chapter discusses Award’s Setup Program built into the ROM BIOS. The Setup Program allows users to modify the basic system configuration. This special information is then stored in battery-backed RAM, which retains the setup information when the power is turned off. Starting Setup The Award BIOS is immediately activated when you turn on the computer. - Page 12 ROM PCI/ISA BIOS CMOS SETUP UTILITY AWARD SOFTWARE. INC. STANDARD CMOS SETUP CPU SPEED SETTING BIOS FEATURES SETUP INTEGRATED PERIPHERALS CHIPSET FEATURES SETUP SUPERVISOR PASSWORD POWER MANAGEMENT SETUP USER PASSWORD PNP/PCI CONFIGURATION SETUP IDE HDD AUTO DETECTION LOAD BIOS DEFAULTS SAVE &...
-
Page 13: Standard Cmos Features
Integrated This section page includes all the items of IDE hard drive Peripherals and Programmed Input / Output features. Supervisor / Changes, sets, or disables password. It allows you to limit User Password access to the system and the Setup Program. Setting IDE HDD Auto Automatically detects and configures the hard disk parameters. -
Page 14: Advanced Bios Features
Primary These categories identify the types of the two channels that Master/Primary have been installed in the computer. There are 45 predefined Slave/Secondary types and one user definable types in BIOS. Type 1 to Type Master/Secondary 45 are predefined. Type “user” is user-definable. Slave Press PgUp or PgDn to select a numbered hard disk type or type the number and press <Enter>. -
Page 15: Advanced Chipset Features
Advanced Chipset Features The Chipset Features Setup option is used to change the values of the chipset registers. These registers control most of the system options in the computer. This section allows you to configure the system based on the specific features of the installed chipset. -
Page 16: Flash Update Procedure
PASSWORD DISABLED. Once the password is disabled, the system will reset and you can enter the Setup Program freely. When a password is enabled, you will be prompted to enter it every time you try to enter setup. This prevents an unauthorized person from changing any setting of your system configuration.
