EPOX ADE-9040 User Manual

Intel core 2 duo desktop q965 atx mother board
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ADE-9040
®
Intel
Core™ 2 Duo Desktop
Q965 ATX Mother Board
User's Manual
Rev. 1.0
2007/03/27
P/N: 600C002904010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADE-9040 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EPOX ADE-9040

Summary of Contents for EPOX ADE-9040

  • Page 1 ADE-9040 ® Intel Core™ 2 Duo Desktop Q965 ATX Mother Board User’s Manual Rev. 1.0 2007/03/27 P/N: 600C002904010...
  • Page 2 ADE-9040 User’s Manual Copyright All rights reserved. The information contained in this guide has been validated and reviewed for accuracy. No patent liability is assumed with respect to the use of the information contained herein. While every precaution has been taken in the preparation of this guide, the Manufacturer assumes no responsibility for errors or omissions.
  • Page 3 This manual is written for the system integrator, PC technician and knowledgeable PC end user. It describes how to configure your ADE-9040 to meet various operating requirements. The user’s manual is divided into four chapters, with each chapter addressing a basic concept and operation of the server board.

  • Page 4: Table Of Contents

    ADE-9040 User’s Manual Table of Content Introduction.........................8 Description......................8 Packing Check List....................9 Specifications ....................10 System Architecture..................12 Dimensions ......................13 Hardware Configuration Setting................15 Board Layout .....................15 Jumpers & Connectors ..................16 Jumpers/Connectors Setting................17 2.3.1 RTC Clear CMOS (JP1) ................17 2.3.2 BIOS Write Protect (JP2)................17 2.3.3...
  • Page 5 ADE-9040 User’s Manual System Installation ....................22 ® Intel µFC-LGA775 Processor................22 ® ® ® 3.1.1 Installing Intel Core™ 2 Duo / Pentium 4 / Celeron D CPU ......22 3.1.2 Installing Intel µFC-LGA 775 CPU Fan, and Heat Sink ........23 3.1.3 Removing CPU.....................23 Main Memory......................24...
  • Page 6 ADE-9040 User’s Manual Revision History Revision Date Comment Rev.1.0 Mar. 2007 Initial released 6 / 55...
  • Page 7 ADE-9040 User’s Manual CHAPTER 1 7 / 55...

  • Page 8: Introduction

    ATX power function. Besides, a feature of CPU overheat protection will provide user more security and stability. Built with these impressed functions, ADE-9040 ATX Mother Board are those ideal solutions for DVR, KIOSK, medical equipment, industrial automation, financial automation, process control, semiconductor equipment, and network security markets.

  • Page 9: Packing Check List

    ADE-9040 User’s Manual Packing Check List The ADE-9040 package includes the following basic items accompany with this manual. One ADE-9040 ATX Mother Board One Quick Installation Guide for ADE-9040 One 40-pin IDE cable Two Serial ATA cable One Serial port cable for COM2 or COM3 One Serial port cable for COM4 One USB 2.0 cable...

  • Page 10: Specifications

    ADE-9040 User’s Manual Specifications System ® ® ® ® Intel Core™ 2 Duo Desktop / Pentium D / Pentium 4 / Celeron processor in the LGA775 package (E6000, 900, 800, 600, 500, 300 sequences) 1066/800/533 MHz BIOS AMI BIOS with 8 Mb Flash EEPROM ®...
  • Page 11 ADE-9040 User’s Manual Audio HDAC Realteck ALC883 7.1 + 2CH audio codec Audio Interface Mic in, Line in, CD Audio in, Line out, Rear out and Center/Subwoofer out Ethernet Chipset Dual Marvell® 88E8053 PCI Express™ Gigabit Ethernet controllers Ethernet Interface IEEE 802.3 10BASE-T/100BASE-TX/1000BASE-T...

  • Page 12: System Architecture

    ADE-9040 User’s Manual System Architecture All of details operating relations are shown in ADE-9040 system block diagram. 12 / 55...

  • Page 13: Dimensions

    ADE-9040 User’s Manual Dimensions Unit: mm 13 / 55...
  • Page 14 ADE-9040 User’s Manual CHAPTER 2 14 / 55...

  • Page 15: Hardware Configuration Setting

    Hardware Configuration Setting This chapter gives the definitions and shows the positions of jumpers, headers and connectors. All of the configuration jumpers on ADE-9040 are in the proper position. The default settings shipped from factory are marked with an asterisk ( ).

  • Page 16: Jumpers & Connectors

    ADE-9040 User’s Manual Jumpers & Connectors JUMPERS FUNCTION REMARK RTC CMOS clear select 1 x 3 header BIOS write protect 1 x 3 header AT/ATX power select 1 x 2 header DVI select 2 x 12 header PATA select 1 x 2 header...

  • Page 17: Jumpers/Connectors Setting

    ADE-9040 User’s Manual Jumpers/Connectors Setting 2.3.1 RTC Clear CMOS (JP1) 2.3.2 BIOS Write Protect (JP2) PIN No. Description PIN No. Description Normal operation BIOS write disabled Clear CMOS BIOS write enabled 2.3.3 AT/ATX Power Select (JP3) 2.3.4 DVI Select (JP4) PIN No.

  • Page 18: Audio Connector (Cn15)

    ADE-9040 User’s Manual 2.3.12 Audio Connector (CN15) 2.3.13 PS/2 Keyboard & Mouse Connector (CN17) PIN No. Description PIN No. Description PIN No. Description PIN No. Description 1(Orange) Central out 4(Blue) Line-in Keyboard Data Mouse Data 2(Black) Surround out 5(Green) Line-out...

  • Page 19: 4-Pin Atx Power Connector (Cn25)

    ADE-9040 User’s Manual 2.3.19 4-pin ATX Power Connector (CN25) 2.3.20 24-pin ATX Power Connector (CN26) Description PIN No. PIN No. Description PIN No. Description +3.3V +3.3V -12V +3.3V Ground Ground +12V PS_ON +12V Ground Ground Ground Ground Ground PW_OK 5VSB...

  • Page 20: Dvi Connector (Cn31)

    ADE-9040 User’s Manual 2.3.22 DVI Connector (CN31) Description PIN No. PIN No. Description HPDET Ground Ground DVIDATA TDC0# DVICLK TDC0 Ground Ground TLC# TDC1# TDC1 Ground Ground Ground TDC2# Ground TDC2 Signal Type Description DVI Data Channel 0 Output: These pins provide the DVI differential TDC0,TDC0# output for data channel 0 (Blue).
  • Page 21 ADE-9040 User’s Manual CHAPTER 3 21 / 55...

  • Page 22: System Installation

    ADE-9040 User’s Manual System Installation This chapter provides you with instructions on how to setup your system. The additional information shows you how to install CPU/ FAN and memory. ® Intel µFC-LGA775 Processor ® ® ® 3.1.1 Installing Intel Core™ 2 Duo / Pentium...

  • Page 23: 3.1.2 Installing Intel Μfc-Lga 775 Cpu Fan, And Heat Sink

    ADE-9040 User’s Manual 3.1.2 Installing Intel µFC-LGA 775 CPU Fan, and Heat Sink • The Intel µFC-LGA 775 CPU heat sink and fan assembly comes in a push-pin design and requires no tool to install. • Place the fan with heat sink right above the CPU and make sure four pins matching the holes of the board.

  • Page 24: Main Memory

    ADE-9040 User’s Manual Main Memory ADE-9040 provides 2 DIMMs (240-pin Dual In-line Memory Module) to support 1.8V DDRAM (Synchronized DRAM) as on-board main memory. The maximum memory size is 256 MB ~ 4 GB with using 256MB/512MB/1GB technology. Supports up to 2 double sided DIMMs at DDR2 533/667/800MHz.

  • Page 25: Installing The Atx Mother Board

    ADE-9040 User’s Manual Installing the ATX Mother Board To install your ADE-9040 into standard chassis or proprietary environment, you need to perform the following steps: 1. Check all jumpers setting on proper position 2. Install and configure CPU and memory module on right position 3.
  • Page 26 ADE-9040 User’s Manual CHAPTER 4 26 / 55...

  • Page 27: Bios Setup

    ADE-9040 User’s Manual BIOS Setup Entering Setup AMI BIOS has a built-in setup program that allows users to modify the basic system configuration. This information is stored in CMOS RAM whose power is supplied by a battery so that it can retain the setup information even when the power is turned off. Press Delete when you Power on or Reboot the computer system.

  • Page 28: Advanced Setting

    ADE-9040 User’s Manual 4.1.2 Advanced Setting 28 / 55...
  • Page 29 ADE-9040 User’s Manual 4.1.2.1 CPU Configuration The CPU Configuration setup screen varies depending on the installed processor. 4.1.2.1.1 Max CPUID Value Limit The Intel® Processor Identification Utility requires the 'Max CPUID Value Limit' in the system BIOS to be disabled for proper processor identification. Once processor identification has taken place, the option can be re-enabled if desired.
  • Page 30 ADE-9040 User’s Manual 4.1.2.2 IDE Configuration 4.1.2.2.1 SATA#1 Configuration Option: [Disabled], [Enhanced]. 4.1.2.2.2 Configure SATA#1 as Option: [IDE], [RAID] 4.1.2.2.3 Primary/Secondary IDE Master/Slave Select one of the hard disk drives to configure it. Press <Enter> to access its the sub menu.
  • Page 31 ADE-9040 User’s Manual 4.1.2.2.6 ATA(PI) 80Pin Cable Detection Set this option to select the method used to detect the ATA (PI) 80 pin cable. The Optimal and Fail-Safe setting is Host & Device. Item Description Set this value to use both the motherboard onboard IDE controller and IDE disk drive to detect the Host &...
  • Page 32 ADE-9040 User’s Manual 4.1.2.3 Super IO Configuration 32 / 55...
  • Page 33 ADE-9040 User’s Manual 4.1.2.3.1 Serial Port1/2 Address This option specifies the base I/O port address and Interrupt Request address of serial port 1/2. The Optimal setting is 3F8/IRQ4. The Fail-Safe default setting is Disabled. Item Description Set this value to prevent the serial port from accessing any system resources. When Disabled this option is set to Disabled, the serial port physically becomes unavailable.
  • Page 34 ADE-9040 User’s Manual 4.1.2.4 Hardware Health Configuration 4.1.2.4.1 H/W Health Function Enables Hardware Health Monitoring Device. 4.1.2.4.2 FAN 1 Mode Setting This item allows you to set fan speed control mode. Option: [Full On mode], [Automatic mode]. 4.1.2.4.3 Temperature 1 Limit of Start Fan spins in a start PWM value when temp exceeds a start limit Min=0℃, Max=127℃, Please input Dec number:...
  • Page 35 ADE-9040 User’s Manual 4.1.2.4.8 Fan 2 Start PWM Fan start PWM value. Min=0, Max=127, Please input Dec number:. 4.1.2.4.9 Slope PWM 2 The PWM value is subject to the temperature inputs by linear changing. 35 / 55...
  • Page 36 ADE-9040 User’s Manual 4.1.2.5 ACPI Configuration 4.1.2.5.1 ACPI Aware O/S Set this value to allow the system to utilize the Intel ACPI (Advanced Configuration and Power Interface) specification. Item Description This setting should be set if the operating system in use does not comply with the ACPI (Advanced Configuration and Power Interface) specification.
  • Page 37 ADE-9040 User’s Manual 4.1.2.6 APM Configuration 4.1.2.6.1 Power Management/APM Set this value to allow Power Management/APM support. 4.1.2.6.2 Video Power Down Mode This option specifies the length of time the system waits before it enters suspend mode. The options: Disabled, 1, 5, 10 Min.
  • Page 38 ADE-9040 User’s Manual 4.1.2.6.7 Power Button Mode This option specifies how the externally mounted power button on the front of the computer chassis is used. The options: On/Off, Standby, Suspend. 4.1.2.6.8 Resume On Ring Disable/Enable RI to generate a wake event.
  • Page 39 ADE-9040 User’s Manual 4.1.2.7 MPS Configuration Select MPS Revision. 39 / 55...
  • Page 40 ADE-9040 User’s Manual 4.1.2.8 Remote Access Configuration 4.1.2.8.1 Remote Access You can disable or enable the BIOS remote access feature here. 4.1.2.8.2 Serial Port Number Select serial port for console redirection. Make sure the selected port is enabled. 4.1.2.8.3 Flow Control Select Flow Control for console redirection.
  • Page 41 ADE-9040 User’s Manual 4.1.2.9 USB Configuration 4.1.2.9.1 Legacy USB Support Legacy USB Support refers to the USB mouse and USB keyboard support. Normally if this option is not enabled, any attached USB mouse or USB keyboard will not become available until a USB compatible operating system is fully booted with all USB drivers loaded.
  • Page 42 ADE-9040 User’s Manual 4.1.2.9.5 USB Mass Storage Device Configuration 4.1.2.9.5.1 Emulation Type If Auto, USB devices less than 530MB will be emulated as Floppy and remaining as hard drive. Forced FDD option can be used to force a HDD formatted drive to boot as FDD (Ex.

  • Page 43: Advanced Pci/Pnp Setting

    ADE-9040 User’s Manual 4.1.3 Advanced PCI/PnP Setting 43 / 55...
  • Page 44 ADE-9040 User’s Manual 4.1.3.1 Clear NVRAM Clear NVRAM during System Boot. 4.1.3.2 Plug & Play O/S Set this value to allow the system to modify the settings for Plug and Play operating system support. Item Description The No setting is for operating systems that do not meet the Plug and Play specifications.
  • Page 45 ADE-9040 User’s Manual 4.1.3.9 DMA Channel 0/1/3/5/6/7 Set this value to allow the DMA setting to be modified. Item Description Available This setting allows the specified DMA to be used by PCI/PnP device. Reserved This setting allows the specified DMA to be used by a legacy ISA device.

  • Page 46: Boot Settings

    ADE-9040 User’s Manual 4.1.4 Boot Settings 46 / 55...
  • Page 47 ADE-9040 User’s Manual 4.1.4.1 Boot Settings Configuration 4.1.4.1.1 Quick Boot The Optimal and Fail-Safe default setting is Disabled. Allow to set this value to allow the BIOS to skip certain POST tests to boot faster or disabled to perform all POST tests.
  • Page 48 ADE-9040 User’s Manual 4.1.4.1.5 Wait For ‘F1’ If Error Set this value to allow the Wait for ‘F1’ Error setting to be modified. Item Description This prevents the to wait on an error for user intervention. This setting should be used if there is a known reason for a BIOS error to appear.

  • Page 49: Security Settings

    ADE-9040 User’s Manual 4.1.5 Security Settings 4.1.5.1 Change Supervisor Password Indicates whether a supervisor password has been set. If the password has been installed, Installed displays. If not, Not Installed displays. 4.1.5.2 Change User Password Indicates whether a user password has been set. If the password has been installed, Installed displays.

  • Page 50: Advanced Chipset Settings

    ADE-9040 User’s Manual 4.1.6 Advanced Chipset Settings 50 / 55...
  • Page 51 ADE-9040 User’s Manual 4.1.6.1 North Bridge Configuration You can use this screen to select options for the North Bridge Configuration. Use the up and down <Arrow> keys to select an item. Use the <Plus> and <Minus> keys to change the value of the selected option.
  • Page 52 ADE-9040 User’s Manual 4.1.6.1.6 PEG Port This item allows you to control the PEG or on-chip VGA. The choice: [Auto], [Disabled]. 52 / 55...
  • Page 53 ADE-9040 User’s Manual 4.1.6.2 South Bridge Configuration You can use this screen to select options for the South Bridge Configuration. South Bridge is a chipset on the motherboard that controls the basic I/O functions, USB ports, audio functions, modem functions, IDE channels, and PCI slots. Use the up and down <Arrow>...
  • Page 54 ADE-9040 User’s Manual 4.1.6.2.4 Onboard Giga LAN 1/2 Select “Enabled” if your system has a LAN device installed on the system board and you wish to use it. The choice: Enabled, Disabled 4.1.6.2.5 SLP_S4# Min. Assertion Width The item allows you to select the assertion width of SLP_S4#.

  • Page 55: Exit Options

    ADE-9040 User’s Manual 4.1.7 Exit Options 4.1.7.1 Save Changes and Exit When you have completed the system configuration changes, select this option to leave Setup and reboot the computer so the new system configuration parameters can take effect. 4.1.7.2 Discard Changes and Exit Select this option to quit Setup without making any permanent changes to the system configuration.
