Soft Serve Ice-Cream Machines
How To Clean, Lubricate and Reassemble Your
Gravity Fed Machine
Please follow these start-up instructions every time you clean your machine
For Spaceman Ice Cream Machines already in use, please follow the
"How To Clean and Lubricate Your Gravity Fed Machine"
instructions shown in a separate powerpoint.
CREATED by CELCO INC
1
Advertisement
Related Manuals for Spaceman Gravity Fed Machine
Summary of Contents for Spaceman Gravity Fed Machine
- Page 1 Gravity Fed Machine Please follow these start-up instructions every time you clean your machine For Spaceman Ice Cream Machines already in use, please follow the “How To Clean and Lubricate Your Gravity Fed Machine” instructions shown in a separate powerpoint.
- Page 2 You must have 6” of clearance on all sides of the machine The unit requires this spacing to prevent hot air from recirculating into the machine and causing poor freezer operation. Twice A Week - Minimum CREATED by CELCO INC...
- Page 3 Please Note – Spaceman Lubricant and Stera Sheen Sanitizer (Milkstone Remover) are both approved for lubricating and sanitizing your Spaceman machine. If you wish to use another product, please call Celco or Spaceman for approval as not all products are compatible with Spaceman machines.
- Page 4 For cleaning and sanitizing your machine you will require: A Container or Bucket To Hold All Parts A Food Grade Bucket for Mixing A Whisk Disposable Gloves Brush Kit Lubricant (1 tube comes with the machine) Ice Cream Machine Sanitizer CREATED by CELCO INC...
- Page 5 Drain Product From The Machine If the unit was in overnight/standby mode removal of the product is easier as the cylinder product is not frozen, only chilled. If the unit has product in it, press With a bucket under the dispensing RESET assembly, pull down the draw handles then wash.
- Page 6 Cleaning The Hopper On The Gravity Fed Unit Pour clean cold Using the brush Use a smaller water into the kit, swish the brush to clean the hopper to rinse water around to tube leading from out the product. remove the the hopper to the Press RESET then Allow the water to...
- Page 7 With the wash Once the water Add another Use the brushes mode still on, place slows down to a bucket of cold to clean the inside a clean bucket trickle, press clean water to the of the hopper under the RESET to stop hopper to clean it discharge assembly...
- Page 8 Press RESET and You are now With the wash Once the water then WASH and washing the mode still on, place slows down to a let it run for 5 machine a clean bucket trickle, press minutes under the RESET to stop discharge assembly the wash cycle.
- Page 9 Remove the Move the Wipe out and dry the hopper agitator hopper agitators hoppers from the hopper to the container for washing CREATED by CELCO INC...
- Page 10 You Are Now Ready To Take The Door Assembly Apart 1, 3, or 5 draw handles – 1, 2, or 3 hoppers. All units are cleaned and sanitized the same way. Machines with multiple handles and hoppers will have more parts to clean. In this powerpoint we are cleaning a 3 draw handle unit.
- Page 11 Disassembling The Dispensing Door Unscrew the end of the retention pin (can be done at the left or right end) Pull the retention pin from the other end that still has the screw on and remove each of the handles one by one Put the handles and retention pin and screws aside for washing CREATED by CELCO INC...
- Page 12 Unscrew the 4 hand screws on the 4 corners of the door. If your machine has screws of different lengths, the 2 long are the top and 2 short are at the bottom. Place into your container for cleaning. CREATED by CELCO INC...
- Page 13 Using the O-Ring Remove dispensing door assembly from the cylinders. remover that comes Slide the beater guide from the beater rod in the machine, (also known as the trombone) remove the gaskets from the door. 1 Hopper – 1 Beater Rod These could be black 2 Hoppers –...
- Page 14 Remove the star Remove the draw valves and prime plugs by pushing from caps from the base one end until they pop out. of the door assembly. Place the parts into the container for washing. Place in the container for The O-Rings need to be removed for washing.
- Page 15 Disassemble Beater Assembly and Drive Shaft Remove the Remove the scraper blades Remove the beater assembly from the beater (also known beater shoes from the as the auger). Separate the (2 per beater). cylinder. scraper blade clips from the scraper blades. Place all the above items into the container for washing CREATED by CELCO INC...
- Page 16 Reach inside the cylinder and remove the draft shaft. Separate the gasket from the drive shaft and place all parts into the container for washing. If the gasket is not attached to the drive shaft when you take it out, reach back inside and retrieve it CREATED by CELCO INC...
- Page 17 Wash the cylinder with a wet cloth. You can use the brushes also to get inside to the back. Wipe dry with a cloth. CREATED by CELCO INC...
- Page 18 Remove the drip tray from the front of the machine. Wash, dry and place back onto the screws. NOTE: Leaving this to the end allows any dripping of product or water from cleaning the machine to be caught and not spill onto the floor. CREATED by CELCO INC...
- Page 19 Wash all the parts in food safe soap and water, rinse well and dry all parts before assembling the machine. Remove and wash O-Rings and put back onto each part as you go. This helps prevent loss of O-Rings and mixing up the O-Rings CREATED by CELCO INC Celco Inc.
- Page 20 You are now ready to reassemble your machine CREATED by CELCO INC...
- Page 21 Reassemble Drive Shaft and Beater Assembly Put a small Place the gasket The key is Insert the drive amount of back onto the the smallest shaft into the lubricant inside drive shaft and end. Do not machine key the draft shaft snap into place.
- Page 22 Attach the beater shoes to the end of the beater. The beater shoes when Right Right properly placed do not overhang the edges and the indent wraps around the beater bars and are not sticking up at the end. Wrong Wrong CREATED by CELCO INC...
- Page 23 Attach the scraper Attach the scraper blade clips to the blades to the beater scrapers and hold in place while inserting into the cylinder. Engage with the drive shaft at the back. CREATED by CELCO INC...
- Page 24 Snap the star caps onto Lubricate the Place the prime plugs the base of the door O-Rings on the back into the door assembly prime plugs assembly CREATED by CELCO INC...
- Page 25 Lubricate the O-Rings on the draw valves. Insert the draw valves from the top of the door assembly, making sure the H-Ring middle draw valve is in the middle position (in positions 2 and 4 of a 5 handle). The H-Ring valve always goes where the twisted ice-cream will be served from.
- Page 26 Right Wrong Attach 1st nut to the end of the retention pin. Starting at one end, thread the retention pin through the door assembly, inserting the handles (placed in screw side down) into the holes on the draw valves and threading the retention pin through each handle until all handles are installed.
- Page 27 The door gasket has a flat side and a ridged side. Place a small amount of lubricant on the ridged side and rub around the entire gasket. Place over the beater guide ridged side down and press into place. Put another small amount of lubricant onto the flat side of the gasket and spread evenly around the gasket.
- Page 28 Insert the beater rods Make sure the door Place the beater guides into the cylinders and assembly is sitting onto onto the beater rods slide into place. all 4 screws CREATED by CELCO INC...
- Page 29 Attach the hand screws 1 at a time diagonally: top left – bottom right top right – bottom left 2 long at the top 2 short at the bottom CREATED by CELCO INC...
- Page 30 Remove the air tube cap. Wash and dry both parts. Put a small amount Lubricate the O-Ring on the cap and place back onto the of lubricant on the tube at the end without the hole. inside of the hopper agitator and Do not put the air tube back into the unit until after the put it back into the unit has been sanitized, has product in it and it has been...
- Page 31 You are now ready to sanitize your machine prior to adding any product to the machine. Do not add product to the machine if it has not been sanitized first. If you are not ready to add product, wait and do it when you are ready. Once you sanitize the machine you must put product into it within 60 minutes or you will have to sanitize...
- Page 32 For further information please refer to your user manual. Videos can be found on our website at www.celco.ca You can also call us Monday to Friday at Celco (905) 364-5200 1-866-772-3526 CREATED by CELCO INC...
