INCLUDED IN THE BOX:
Galaxy II video light
USB charging cable
Li ion battery pack (3*18650-A battery pack)
YS clip, ball base
Padded case
WARNING: Read these instructions before use. Keep in a safe location for future reference.
STOP: If for any reason your light fails or malfunctions, please review the trouble shooting guide at www.tovatec.com.
CHANGING BETWEEN MODES
Power Off: Hold switch-A for 1 second. The flashlight will power off and the battery indicator will go off.
SOS & 10HZ strobe: in OFF status, hold the switch-A for 1 second, when the battery indicator lights up, hold switch-A
and switch-B for 5 seconds at the same time, only the spotlight source enters the SOS mode. Switch to 10HZ strobe
mode by pressing Switch B for less than 1 second. It will switch back to the SOS when you press Switch-B again. To turn
off the SOS or 10HZ by holding switch-A for 1 second.
POWER LEVELS and BURN TIME CHART
Light Mode
Red Light
Video Mode
Spot Mode
UV light
O-RING CARE
Inspect O-rings to be sure they are clean and free of dust, debris, hair, sand, etc. before using underwater. Lightly
lubricate O-rings with silicone grease prior to use and maintain lubrication at all times.
RECHEARGEABLE BATTERIES
The burn-time of rechargeable batteries varies. (See chart above for burn times).
Galaxy II Video Light
Power On: hold switch-A for 1 second. When the torch switches on, the power
indicator light will come on.
Switch-A: press switch-A to select the light mode. In the startup state: red light
(100%)-Warm floodlight (100%)- White spotlight (100%)--UV light (100%).
Press repeatedly to get to your desired light mode. PLEASE NOTE THAT THE
FLOODLIGHT MODE "POWERS UP" FROM THE LOWER POWER RED
LIGHT TO HIGH POWER OVER APPROXIMATELY 1 SECOND. THIS
OPERATION PROTECTS THE LED.
Switch-B: press switch-B to select the brightness of each light :100%-50%-25%.
(Note: the UV light is only 100% brightness).
Lumens/Beam
200/120 degrees
3000/115 degrees
800 / 25 degrees
10/120 degrees
Power Levels
100% - 50% - 25%
100% - 50% - 25%
100% - 50% - 25% - SOS – 10Hz
100%
Burn time
7-22 hours
2-4 hours
4-10 hours
4.5 hours
Advertisement
Table of Contents
Summary of Contents for Tovatec Galaxy II
- Page 1 Padded case WARNING: Read these instructions before use. Keep in a safe location for future reference. STOP: If for any reason your light fails or malfunctions, please review the trouble shooting guide at www.tovatec.com. CHANGING BETWEEN MODES Power On: hold switch-A for 1 second. When the torch switches on, the power indicator light will come on.
- Page 2 • Charging takes approximately 3-4 hours for full charge with a standard 5V2.1A cell phone adapter. WARNING: When using rechargeable lithium ion batteries use only the Tovatec battery pack created for this light. BATTERY DISPOSAL Rechargeable lithium ion batteries as well as alkaline and rechargeable alkaline batteries must all be disposed of or recycled in compliance with all applicable laws.
