Summary of Contents for Burle VidQuad TC8276X
- Page 1 TC8272 Series TC8276 Series ® VidQuad Four Channel Video Processor Installation and Operating Instructions...
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS Read Instructions - All the safety and operating instructions should be read before the unit is operated. 2. Retain Instructions - The safety and operating instructions should be retained for future reference. 3. Heed Warnings - All warnings on the unit and in the operating instructions should be adhered to. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN! CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, OPEN COVERS. SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This label may appear on the bottom of the unit due to space limitations. -
Page 4: Precauciones De Seguridad
SICHERHEITSVORKEHRUNGEN VORSICHT RISIKO EINES ELEKTRISCHEN SCHLAGES NICHT ÖFFNEN! VORSICHT: UM EINEN ELEKTRISCHEN SCHLAG ZU VERMEIDEN, ABDECKUNG NICHT WARTUNGEN ALLER ART QUALIFIZIERTEM PERSONAL ÜBERLASSEN. Aus Platzgründen kann diese Warnung auf der Unterseite des Gerätes angebracht sein. Das Blitzsymbol im gleichseitigen Dreieck soll den Benutzer auf nicht isolierte “Hochspannung”... -
Page 5: Service Centers
If an item appears to have been damaged in shipment, replace it properly in its carton and notify the shipper. If any items are missing, notify your Philips Communication & Security Systems Inc. Sales Representative or Customer Service. The shipping carton is the safest container in which the unit may be transported. -
Page 6: Installation
INSTALLATION Electrical Model No. Rated Voltage TC8272 120 VAC, 50/60 Hz TC8272X 220-240 VAC, 50/60 Hz TC8276 120 VAC, 50/60 Hz TC8276X 220-240 VAC, 50/60 Hz At rated voltage. Power Disconnect. Units with or without ON/OFF switches have power supplied to the unit whenever the power cord is inserted into the power source;... - Page 7 Video Inputs TC8272 Series only: Each of the four camera inputs have a single BNC connector and are 75 ohm terminated. TC8276 Series only: For each of the four camera inputs there are two BNC connectors on the rear panel. One of these connectors is to be used as a camera input while the other connector may be used as a looping output.
-
Page 8: Operation
OPERATION TC8272 Series When power is applied to the unit, the ON LED lights, and the main monitor displays four quadrants on the screen corresponding to the four video inputs. See Front Panel - TC8272 Series and Typical Application - TC8272 Series illustrations. TC8276 Series When power is applied to the unit, both the QUAD VIDEO OUT and the VIDEO OUT monitors will be in the... -
Page 9: Camera
Freeze Mode When any of the FREEZE buttons are pressed, the VIDEO OUT, and QUAD VIDEO OUT monitors will freeze the video image corresponding to the button(s) pressed, and flash the LED above the FREEZE button(s). When a quadrant is frozen, a flashing icon will be displayed in that quadrant on both the VIDEO OUT, and QUAD VIDEO OUT monitors. -
Page 10: Illustrations
When all four cameras are used, all four positions of the S201 should be open (OFF). When three cameras are used, they should be connected to video inputs 1-3, and S201 position 1 should be closed (ON) to defeat the video loss for 1 video input (4). -
Page 11: Table Of Contents
Front Panel - TC8272 Series Camera 1 Camera 2 Camera 3 Camera 4 CAM 1 CAM 2 CAM 3 Typical Application - TC8272 Series SEQUENCE QUAD FULL VIEW Front Panel - TC8276 Series S9404002AE Video 1 Video 2 Video 3 Video 4 Main Monitor QUAD... -
Page 12: Camera
Pinouts - Alarm/Accessory ALL SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE. INFORMATION FURNISHED BY PHILIPS COMMUNICATION & SECURITY SYSTEMS INC. (PCSS) IS BELIEVED TO BE ACCURATE AND RELIABLE. HOWEVER, NO RESPONSIBILITY OR LIABILITY IS ASSUMED BY PCSS FOR ITS USE, NOR FOR ANY INFRINGEMENT OF PATENTS OR OTHER RIGHTS OF THIRD PARTIES WHICH MAY RESULT FROM ITS USE.
