Therefore, Philips reserves the rights to revise this user guide or withdraw it at any time without prior notice. Philips provides this user guide «as is» and does not accept, except as required by applicable law, liability for any error, omission or discrepancy between this user guide and the product described.
Quickly return to idle Press and hold when browsing menus Lock/unlock the Press and hold keypad in idle mode. View the last call made Press Change the Press and hold language used language and press Access a function Press in the menu select a function, then press to enter the sub-menu.
1. Getting started ... 6 Insert the SIM card ... 6 Switch on the phone ... 7 Set date and time ... 7 Copy the SIM phonebook ... 7 Charge the battery ... 7 2. Main features ... 9 Access and consult the phonebook ... 9 Make a call ...
6. Mix music ... 22 How to..22 Getting started ... 22 Activate tracks ... 22 Change track melodies and instruments 23 Change the tempo ... 23 Record a mix ... 23 Start recording ... 23 Manage the recording ... 24 Create your own style and mix ...
Network ... 41 GPRS attach ... 41 Register again ... 41 Preferred list ... 41 Access settings ... 41 Time and date ... 43 Clock display ... 43 Set date ... 43 Date format ... 43 Time zone ... 43 Daylight saving ...
Answer a second call ... 83 Answer a third call ... 83 Conference call ... 83 Explicit call transfer ... 84 Troubleshooting ... 85 Icons & symbols ... 88 Precautions ... 89 Philips authentic accessories Limited warranty ... 94 ... 93...
1 • Getting started Read the safety instructions in the «Precautions» section before use. To use your phone, you must insert a valid SIM card supplied by your GSM operator or retailer. The SIM card contains your subscription, your mobile number, and memory in which you can store phone numbers and messages (see “Contacts”...
Switch on the phone To switch on the phone, long press the key. When you switch on the phone, you may be prompted to enter the PIN code, which is the 4 to 8-digit secret code of your SIM card to protect it from unauthorised use.
Once the battery and battery cover are clipped on the phone, plug the connector of the charger (supplied with the phone, in the box) into the LEFT hand socket at the base of the phone on one end, then plug it into a main AC power socket with easy access on the other end.
2 • Main features Access and consult the phonebook In idle mode, press the selected phonebook (in SIM or in Contacts phone), the content that appears on the screen may vary: see “Contacts” page 26 for details on this subject. To consult the phonebook during a call, press select List, press...
Lock / unlock the keypad You can lock the keypad to protect the keys from being pressed accidentally Keypad lock (e.g., when the phone is in your pocket). To lock the keypad, press and hold screen. To unlock the keypad, press and hold again.
Fotocall: see and hear who’s calling This feature is available only when selecting the phonebook in the phone (not the one in the SIM card). This feature allows you to link one or several names to a group. When a name in that group calls, it will appear along with the corresponding picture, and the melody defined for that group will ring.
Record a conversation most countries, recording is subject to law regulation. Record dialogue We advise you to notify the caller if you intend to record the conversation you have with them and only record if they agree. You should also keep any recording private.
3 • Menu tree The table below describe the complete menu tree (first to third levels) of your mobile phone, as well as the page reference you should refer to for more information concerning each feature or setting. Settings p33 Sounds p33 Silent / Ringer volume / Ringer / Messages Ringer / Equaliser / Key tones /...
E-Mail p49 For each available mail box Settings / Open mailbox / Send mail Broadcast Message p57 Reception / Topics / District codes Instant message p57 MMS p58 Create an MMS / Receive an MMS / Manage folders / Settings Multimedia p65 Picture album p65 List of available pictures...
Call information p72 Call settings p72 Call forward / Mailboxes / Auto redial / Any key answer / Call waiting / Caller ID Call list p73 Call list / Reset Call counters p74 GSM counters / GPRS counters Contacts p26 View names list Settings Delete all / Contacts select / Groups setting /...
4 • Text or number entry Text can be entered in editing screens in two different ways: by using T9 ® predictive Text Input, or basic text input. Two other modes for numbers and punctuation marks, are also available. Icons appearing on the screen show the active text mode.
Basic text input If you wish to access the basic text input, select «Abc» basic text input using key. This method requires multiple key presses to reach the desired character: the letter «h» is the second letter on the must press it twice to enter «h». Using this mode requires you press a key as many times as is equal to the order of the letter.
5 • Taking pictures Your mobile phone features a digital camera that allows you to take pictures, store them in your phone, use them as wallpaper or send them to your friends and relatives. How to... Activate /deactivate Long press the camera press deactivate.
Camera mode Two modes are available: Normal According to ambiant light level, press between modes, which are reflected by the icons in the bottom of the screen (sun & moon). Picture resolution The default picture size of the standard format is 128.
Beep alarms can be customized via the camera settings. At any time, press to stop the timer and go back to preview mode or press to just stop the timer. Once the picture is shot, follow the instructions starting at point 2 of the previous section. Number of pictures The number of pictures you can save in the phone will vary according to the settings you have configured:...
Rejecting the call will also quit any action linked to the camera, and will bring you back to the preview screen. Make a call To make a call, you must first long press back to the idle screen. Then enter the number or select a name of your phonebook, press and press to hang up.
6 • Mix music With BeDJ, you can create your own sound by using a predefined BeDJ style (as explained below), or any SP-MIDI or MIDI ring tones present in your phone, or that you downloaded via WAP, E-mail, etc. (refer to relevant chapters in the present user manual for complete information).
Up to 16 tracks are available: press and hold keys to open the track selection list. Key is always dedicated to the voice track. The activated track appears in orange, and the above table displays the name of the relevant melody and instrument.
Press to stop recording. The recording will stop automatically when the mix reaches 50 KB (approximately 2 min.). Capacity depends on the memory available in your phone: select Multimedia > Memory Status for memory information. Manage the recording As soon as you stop recording your mix, a window automatically opens and displays the following options for you to choose from: Allows you to record a new mix by...
Press and hold : the list of all the MIDI files present in your phone appears on the screen. Select one of them and press A new list appears, showing all tracks of the selected MIDI file (max.16). Move select one of them, then press Repeat these two steps to apply tracks of your choice to keys When ready, record your mix (see page 23).
7 • Contacts All operations described in this chapter require the relevant phonebook, whether in the SIM or in the phone to be selected. Your mobile phone has two phonebooks. The SIM phonebook is located on the SIM card and the number of entries depends on the card capacity.
Phone’s phonebook Your mobile phone only manages one phonebook at a time and will ignore the information relative to the other one: e.g., if «Smith» is present in both phonebooks and if you delete it in the phone, it remains unchanged in the SIM. The default selected phonebook is the one located in your phone.
Add a record in the phone’s phonebook Add a name field Press to enter the phonebook, select <New>, and then press Enter the last name of your contact and confirm by pressing , then enter their first name and confirm by pressing One of the two name fields can be empty, but not both.
To use Fotocall, you need to be using the phonebook in the phone; if you are not already doing so, see “Copy the SIM phonebook” page 7. In Settings, select Groups setting, press select the group of your choice. Rename the group to be identified («Friends», «Kids», etc.) and select the to be associated to this group.
back to the previous menu, or a long press to go back to the idle mode. Numbers or text will appear in order of creation date. The first fax or phone number you enter becomes the default number. As such, it appears in first position in the list.
always updated when switching phonebooks or when using another phone. To copy a number into the SIM card phonebook, repeat steps 1 to 3 of the “Change a field content”paragraph. Then select Copy to SIM Make calls Emergency number The emergency number will call the emergency services number in your SOS Call country.
Use Flash dial In idle mode, press and hold a key between Flash dial associated entry page 35): connection is established. Press hang up. Use Voice dial In idle mode, press and hold pronounce the saved voice tag (see Voice Dial “Voice dial”...
8 • Settings menu allows you to customise your Settings phone and change the settings related to each available option (sounds, time and date, security, etc.). The menu allows you to change several settings at Profiles once (see page 44). Sounds Silent Allows you to set the...
Sounds Alerts Allows you to set alert beeps for the following items: Sounds Alerts - when an Event you programmed in your organiser is due, - when you have missed a call, - when the is low and requires charging, Battery - to manage the duration of your calls, first after 45 seconds, then every minute of an ongoing call...
Then select the Display period timing you have set will be applied between each picture of the slideshow. Animation Allows you to set the animation of the carousel menus Animation this option will also scroll texts, such a message selected in the Deactivating this function increases the autonomy of your phone.
If the selected key is already set, you can reprogram it: select Settings > Hotkeys > a hotkey in the list. Press twice, select Change and press to the list of available functions. To use the hotkeys, simply press and hold the key corresponding to the function you want to launch or to the number you want to dial while in idle mode.
Redials the last number called. Redial last no. Redials the number of the last call received. Reply last no. Dials the emergency call number. SOS call Opens the E-mail the mail boxes. E-mail Displays balance. Show balance Subscription dependent Displays the Total cost calls.
Voice command Instead of entering the various menus and browsing the lists, you can also set a Voice Command voice tag that will activate a feature (e.g., launch the Calculator). You can associate a Voice command to all the functions supported by the Hotkeys (see page 35), except for «Get mail»...
Up to 15 voice tags can be defined and shared between voice dial and voice command. Security Keypad lock Allows you to lock/unlock your keypad by pressing and holding the Keypad lock when in idle mode. The keypad automatically unlocks when receiving a call. You can also choose immediate or delayed lock by selecting Settings >...
a specific call barring password supplied by your service provider. Outgoing calls menu allows you to select Outgoing between calls, International Outgoing calls (the latter allowing Intl. Exc. Home you to call your home country when you are abroad). You can also Deactivate the bar on outgoing calls.
Network This menu allows you to handle the connection between the phone and the network, register manually the available networks and manage your preferred networks. GPRS attach Your mobile integrates features that support GPRS (Global Packet Radio GPRS attach Service), a service allowing you to exchange data with high speed rates and to stay always on-line (i.e.
All options described below are operator and/or subscription dependent.With some operators, you may receive a SMS which contains access parameters that will be stored automatically. Please contact your network operator for detailed information on this subject. Change name Allows you to enter or change the name of the selected profile.
Error messages during connections are mainly due to incorrect parameters: you should contact your operator before first use, in order to have the appropriate settings. With some operators, the access parameters can be set remotely. Please check with your operator. Time and date This menu allows you to set the time and date, time zone, daylight savings, and change the clock display mode.
Set time Allows you to set the time by pressing the appropriate keys or moving Set time to increase or decrease the time minute by minute. Language This menu allows you to select a language for all menu text. Browse the list and press choice.
When connecting an accessory, the settings described in the table below also become available. When disconnecting the accessory, the phone goes back to Personal profile. Accessories CLA or Profiles Headset Charger Vibra alert Ringer volume Medium Key tones Organiser alerts Battery low alert New SMS tone Backlight...
9 • Messages item of the Send SMS menu allows you to: Send SMS • send a standard or customised short text message to someone, • edit the last message sent and send it again, • add an iMelody, pre-defined sounds, an anima- tion or a picture to your message.
Together with an attachment This option allows you to attach a sound, picture or animation to your message and press and attach it to your message. Depending on the type of file you want to attach, select Add graphic a bitmap image or an animation, and/or attach a melody.
the selected message, Delete of the sender if it is attached to Store number the message, if a melody was sent together Store melody with the SMS, Store graphic(s) if one or several graphics and/ or animations were sent together with the message, Extract a number included in the message...
Validity period This feature is subscription dependent. Allows you to select the length of time your message is to be stored in your Validity period SMS centre. This is useful when the recipient is not connected to the network (and thus cannot receive your message immediately).
Your phone might have been pre-configured. In this case, most parameters are already set and you don’t have to change them (except for Login, Password address which are up to you when creating an e-mail account). To enter text and numbers, including specific signs such as @ or %, see the characters table described page 17.
Number: allows you to enter the phone number Phone provided by your ISP and needed to establish a connection. Press to select: ISDN number to enter an ISDN ISP number, to enter an analogic number, Analogue No. then press Contact your ISP to know what type of number you should select.
Press , select > Messages > and press Settings Account name Enter the new name in the edition window that appears and press Advanced The menus described in this section feature advanced settings that may have been pre-configured, so you shouldn’t have to change any of them.
Repeat steps 2 to 4 to add as many recipients as required. Select and press Validate list subject of your e-mail (you can leave this field empty) and press In the next window, enter the text of your e-mail (you can also leave this field empty). Press when you are ready to send your e-mail.
Connect to the server Connection process Press and select Messages depending on the one you wish mail 1 E-mail 2 to use. Select Open mailbox and press Mailboxes 1 and 2 feature the same settings and options. Configuring them differently will allow you to have two different e-mail addresses from your phone.
Get and store attachments If the e-mail you have received contains attachments (JPEG picture, text file or another e-mail), they are characterised by a specific icon: Contains the details of the e-mail header (date and time, sender’s e-mail address, etc.), press to display these details.
Add an e-mail address to the phonebook You must have selected the phonebook in your phone to be able to add an e-mail address; this menu item will NOT appear if you selected the SIM phonebook. You can add the sender’s e-mail address to your phonebook, even when you haven’t yet downloaded his e-mail Add to names...
In both cases (reply to an e-mail or forward it), your phone will disconnect from the server when reaching the network inactivity time out set in the Auto disconnection menu (see “Bearer” page 50). It will reconnect to this server when sending the e-mail. Broadcast Message The Broadcast SMS feature is network-dependent.
10 • MMS Your mobile phone allows you to send receive messages), featuring texts, pictures and sounds, including memos that you have recorded. A multimedia message can be made of one slide (including text, sound and image), or of several: in this case, the message is played in a slide show, whether you send it to an e-mail address or to another mobile phone.
Although the picture preview when creating the MMS is (W)105 x (H)55 pixels, the maximum size of a picture you can send is (W)640 x (H)640 pixels. Warning! The bigger the picture size, the longer it will take to send it. A copyright-protected picture cannot be sent.
Save MMS To save your message as a draft, that as draft you can edit, complete and send later on. MMS saved as drafts are stored in > (see “Manage folders” Drafts page 62). To save your message as a template, Save as that you can use as a basis for other template...
Receive an MMS Download and play an MMS When you receive an MMS, an alert message appears on the screen to inform you. If you activated the Automatic page 64), message downloaded and placed in the Inbox. Select it in >...
Detach picture To detach the picture of the current slide and save it in the Detach sound To detach the sound of the current slide and save it in the Manage folders The MMS menu allows you to manage your messages in 4 different folders.
If the «Memory full» icon is displayed (see page 88), you must delete items to free some memory. Settings Your phone may have been pre-configured to directly access the services offered. If not, you must have received from your operator the information items described in the present section and enter them as given.
Application settings Retrieval mode Messages are stored on the MMS server, Manual and you must connect manually to retrieve them: Press to access the Inbox. Select corresponding to this message and press Select Read and press When the Details are displayed, press the connection and download it.
11 • Multimedia Picture album JPEG pictures must have the correct size and format for your mobile phone to store and display them correctly. Please check “Get and store attachments” page 55 for complete information on this subject. This menu allows you to manage and display the pictures stored in your Picture Album mobile phone.
Select a sound and press to access the following options: it: press Rename Rename and press again. Delete Delete the selected sound. Send by Email To send the selected picture via E-mail (see “E-Mail” page 49 for details). Set as ringer To set the selected sound as Ringer.
Sound recording This menu allows you to record a sound of 1 min. maximum, and up to 20 Sound recording different sounds, depending on the Memory status. Press and select Multimedia > Sound press again. Select to record a new sound. <New>...
12 • Games & Appli. Calculator This menu provides the following functions: Calculator Addition By pressing the Subtraction By pressing the Multiplication By pressing the Division By pressing the Equals By pressing the Enter the figures using the keypad. Calculator accuracy is to 2 decimal places and is rounded up to the higher decimal figure.
menu reminds you of events via Set Reminder alerts triggered at the chosen time. Move set the for this event and press Reminder This menu only applies to Meeting and ToDo events. Note that the reminder depends on the time set and displayed on the screen.
Deleting a repeated event • By selecting a past occurrence: select a past occurrences of an event and press event details appear, press and press to confirm: only the past occur- rences of the selected event are deleted. • By selecting a future occurrence: select a future occurrence of an event and press event details appear, press and press...
This menu gives you access to the brick game. The object of the game is to Brick Game destroy the bricks by hitting them with the ball. When you have destroyed the last brick, you access the next level. Keys used are the following: To move the racket left or right.
13 • Call information Call settings This menu allows you to set all the call options (call forward, waiting, etc.). Call settings Call forward Allows you to divert incoming calls either to your mailbox or to a number Call forward (whether in your phonebook or not) and applies to: Data...
Auto redial Allows you to set the auto redial Off. When and if the person you are Autoredial calling busy, automatically redials this number until a successful connection is made, or until the maximum number of attempts is reached (10). The phone emits one beep at the beginning of each attempt and one special beep if the connection is successful.
Call list From the main carousel, press select > Call Info Call list display the call list. Use Call list to scroll the list and press again to consult the date, time, number, call status of any selected call and to know if it was sent or received.
Info at call end This feature is subscription dependent. Allows you to activate or deactivate the systematic display of the length and/or Info at call end cost of each call when hanging up. Total cost This feature is subscription dependent. Allows you to display the accumulated cost and to set the counter to zero.
14 • WAP Your mobile phone supports services based on the Wireless Application Protocol (WAP). The built-in WAP browser allows you to access services supplied with your network, such as news, sports, weather, etc. Your mobile phone readily supports the WAP function if it is included in your subscription;...
Bookmarks This menu allows you to store your favourite WAP site addresses, rename them if desired and access them quickly from the list. This can also be done while browsing: press access the Options, then select Bookmarks. In this case, the Name and URL fields will be automatically filled in with the information contained in the page you are browsing.
Select Profile This menu allows you to select one of the available profiles, and to then define the connection settings for each of them: scroll to choose the profile of < > your choice, then press to select / deselect it and press to confirm.
Current certificate Allows you to display the currently used security certificate. Press to go back one page. Rename Profile This menu allows you to rename the currently selected profile: enter the new name (an edit screen automatically appears), then press name you entered.
Back Brings you back to the previously browsed page. You must have browsed at least 2 pages for this option to be available. Forward Takes you to the next browsed page (e.g., when you have previously selected Back). Refresh Will reload the currently browsed page from its original server.
15 • Operator services Most items of the Operator Services menu (e.g. Service numbers, Services +) are subscription- dependent and specific to operators: your mobile phone readily supports them if they are included in your subscription. Consequently, the menus shown following may or may not be available.
Pause and wait characters To obtain a pause or wait character, press and hold . The display shows for a wait and The phone always interprets the first pause character as a wait character. When you dial a number containing a wait character, your phone dials the first part (the phone number) and then waits for the call to be connected before sending the rest of the digits as DTMF tones.
Answer a second call You are able to receive another call when already in communication (if this feature is available with your subscription). When you receive a second call the phone emits an alert beep and the screen displays To receive a second call, you must have: - subscribed to this feature, - deactivated the Call forward option for voice calls (see page 72),...
You may have up to five members at the same time and end the conference with calls are disconnected. In order to make consecutive outgoing calls, first initiate a normal call with the first number of the conference. When the first member is on line, initiate a second call as described in “Make a second call”...
Troubleshooting The phone does Remove and reinstall the battery (see page 6). Make sure not switch on you plugged the jack of the charger into connector (see “Charge the battery” page 7). Then charge the phone until the battery icon has stopped scrolling. Finally, unplug from the charger and try to switch the mobile on.
Your phone Press and hold doesn’t return switch off the phone, check that the SIM card and the to the idle battery are installed correctly, screen and switch it on again. This feature is network and Your phone subscription dependent. If the doesn’t display the phone network doesn’t send the...
When Some features are network attempting to dependent. They are only available, therefore, if the use a feature in network or your subscription the menu, the supports them. Contact your mobile displays operator ALLOWED information on this subject. The display Check that the SIM card has shows INSERT been inserted in the right...
Icons & symbols In idle mode, several symbols can be displayed simultaneously. If the network symbol isn’t displayed, the network is not currently available. You may be in a bad reception area: move to a different location. - Your phone will not ring when Silent receiving a call.
Precautions Radio waves Your cellular mobile phone is a low power radio transmitter and receiver. When it is operating, it sends and receives radio waves. The radio waves carry your voice or data signal to a base station that is connected to the telephone network.
standards Radio Telecommunications Terminal Equipment Directive 1999/5/EC. Always switch off your phone Inadequately protected or sensitive electronic equipment may be affected by radio energy. This interference can lead to accidents. Before boarding an aircraft and/or when packing the phone in your luggage: the use of mobile phones in an aircraft may be dangerous for the operation of the aircraft, disrupt the mobile phones network and may be illegal.
Avoid exposure to excessive heat (>60°C or 140°F), moisture or caustic environments. You should only use Philips Authentic Accessories, as the use of any other accessories may damage your phone and will make all guarantees for your Philips phone null and void. • Make sure...
The provided software allows you to send faxes and SMS, download pictures and melodies. To maximise the performance of your Philips phone and not to void the warranty, always purchase Philips Authentic Accessories that are specially designed for use with your phone. Philips Consumer Electronics cannot be held liable for any damage due to use with non authorised accessories.
The limited warranty for original Philips rechargeable battery extends for six (6) months from the date of purchase. 3. What Will Philips Do if The Product is Not Free From Material Defects in Materials and Workmanship During The Limited Warranty...
Normal wear and tear or Force Majeure. 5. How Do You Get Warranty Service? a) Return the Product to an authorized service center of Philips. You may contact the local Philips office for the location of the nearest authorized service center.
OF ANY LIMITED REMEDY. This limited warranty represents the complete and exclusive agreement between the Consumer and Philips with respect to this cellular Product and it supercedes all prior agreements between the parties, oral or written, and all other communications between the parties relating to the subject matter of this limited warranty.
