OPERATOR MANUAL
IMPORTANT INFORMATION, KEEP FOR OPERATOR
1055 Mendell Davis Drive, Jackson, MS 39272
888-994-7636, fax 888-864-7636
unifiedbrands.net
THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ,
UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS
CONTAINED IN THIS MANUAL.
FOR YOUR SAFETY Instructions to be followed in the event user smells
gas. This information shall be obtained by consulting your local gas
supplier. As a minimum, turn off the gas and call your gas company and
your authorized service agent. Evacuate all personnel from the area.
WARNING Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or death. Read the
installation, operating and maintenance instructions thoroughly before
installing or servicing this equipment.
NOTIFY CARRIER OF DAMAGE AT ONCE It is the responsibility of the
consignee to inspect the container upon receipt of same and to determine
the possibility of any damage, including concealed damage. Unified
Brands suggests that if you are suspicious of damage to make a notation
on the delivery receipt. It will be the responsibility of the consignee to file
a claim with the carrier. We recommend that you do so at once.
Manufacture Service/Questions 888-994-7636.

EQUIPMENT DESCRIPTION

The Groen DHS is a floor-mounted, tilting, steam jacketed kettle with an electroni-
cally controlled, self-contained, gas-heated steam source and appropriate con-
trols, mounted on a sturdy base. The Model DHS is currently only available in a 40
gallon capacity.
The body of the DHS Kettle is constructed of stainless steel, welded into one solid
piece. The kettle is furnished with a reinforced rim and a butterfly shaped pouring
lip. It has a steam jacket which is ASME shop inspected and registered with the
national board for working pressures up to 50 PSI. Kettle finish is 180 emery grit
on the inside and bright high buff polish on the outside.
The kettle is tilted with a hand crank to pour out its contents. Stainless steel pan-
els enclose the controls and the base. A u-shaped frame with four stainless steel
tubular legs support the unit. Bullet feet on each of the legs can be adjusted to
level the kettle. Models with a "T" suffix are supplied with a two-inch tangent
draw-off valve.
The self-contained steam source is heated by propane or natural gas. Electronic
spark to pilot ignition is standard for all units.
This manual provides information for:
LOW HEIGHT STEAM JACKETED
KETTLE WITH STANDARD
ELECTRONIC IGNITION
MODELS DHS(/T)-40(C,A,C2T™)
REFERENCES
CSA INTERNATIONAL
8501 East Pleasant Valley Road
Cleveland, Ohio 44131
NSF INTERNATIONAL
798 N. Dixboro Rd.
P.O. Box 130140
Ann Arbor, Michigan 48113-0140
UNDERWRITERS LABORATORIES, INC.
333 Pfingsten Road
Northbrook, Illinois 60062
KLENZADE SALES CENTER ECOLAB, Inc.
370 Wabasha
St. Paul, Minnesota 55102
The kettle is filled at the factory with water which contains rust inhibitors. The
steam source provides kettle temperatures of 150º to approximately 295ºF (65
to 150ºC). Unit controls include a temperature controller, pressure gauge, safety
valve, pressure limit control, low water cut-off, power switch and gas regulator
valve. The gas burner shuts off automatically when the kettle is tilted.
The unit must be specified for use with natural or propane gas. Service connec-
tions for gas and electricity are required. Standard power supply is 120 VAC.
Options available include:
1. Two inch tangent drawoff*
2. Strainers, solid disk (P/N 013783), 1/4" (P/N 009044) or 1/8" perforations
(P/N 013875)
3. No. 31 lift-off cover(P/N 004282)
4. No. 51 counterbalanced cover w/actuator* (P/N 148287)
5. Basket Inserts (Tri-BC) (P/N 140527)
6. Water fill faucets with swing spout
7. Kettle Brush Kit (P/N 104278)
8. Gallon or Liter etch marks (factory installed)
9. Automatic, metered water filler
Information contained in this document is known to be current and accurate at the time of printing/creation. Unified Brands
recommends referencing our product line websites, unifiedbrands.net, for the most updated product information and
specifications. © 2019 Unified Brands. All Rights Reserved. Unified Brands is a wholly-owned subsidiary of Dover Corporation.
PART NUMBER 174846, REV. E (04/19)
NATIONAL FIRE PROTECTION ASSOCIATION
60 Battery March Park
Quincy, Massachusetts 02269
ZEP MANUFACTURING COMPANY
1310-T Seaboard Industrial Boulevard
Atlanta, Georgia 30318
AMERICAN NATIONAL STANDARDS INST., INC.
1430 Broadway
New York, New York 10018
ICC – INTERNATIONAL CODE COUNCIL
500 New Jersey Avenue, NW
6th Floor, Washington, DC 2000
