KIT COMPONENTS
• A) Dashcam with monitor • B) Power harness and extension • C)
A
iBEAM Vehicle Safety Systems
®
Universal
rearview camera
Visit
iBeamUSA.com
specific applications
Product Features
•
360 view of the front facing, drivers view and
interior of vehicle with audio recording
•
Rearview camera included
•
4" screen
•
Parking Monitor
•
Collision lock supported
Rearview Camera
B
iBEAMUSA.com
360 degree Dashcam and
for more detailed information about the product and up-to-date vehicle
A
C
© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
TE- DVR360
INSTALLATION INSTRUCTIONS
TABLE OF CONTENTS
Wiring................................................................... ...2
Operation................... .............................................3
Settings Menu.......... ............................................... 4
Other Menu options................................................5
Power Off Options...................................................6
Specifications..........................................................7
TOOLS REQUIRED
• Cutting/stripping tool • Tape
• Pry tool
Attention!
When testing the aftermarket
equipment, ensure that all factory equipment
is connected before cycling the key to
ignition.
REV. 4/16/19 INSTTE-DVR360
Advertisement
Table of Contents
Related Manuals for iBeam TE-DVR360
Summary of Contents for iBeam TE-DVR360
-
Page 1: Table Of Contents
• A) Dashcam with monitor • B) Power harness and extension • C) Rearview Camera Attention! When testing the aftermarket equipment, ensure that all factory equipment is connected before cycling the key to ignition. iBEAM Vehicle Safety Systems iBEAMUSA.com ® REV. 4/16/19 INSTTE-DVR360 © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION... -
Page 2: Wiring
WIRING Dashcam Wiring: 1. Mount the dash camera to the windshield using the provided double sided tape. It is suggested to clean the windshield first with an alcohol wipe. 2. Run the wire and plug in the DC plug to obtain 12 ft power to the dash camera. -
Page 3: Operation
OPERATION Operation call outs: ( Figure B ) 1. MINI USB POWER: 12 foot DC power cable for the dash camera power. It can be hooked up to 12v accessory or 12v constant depending on how the vehicles DC or cigarette sockets are powered. -
Page 4: Settings Menu
SETTINGS MENUS Settings Menus: To enter the settings menus, recording must be stopped by pressing the icon. Press the setting button enter the settings menus. Settings Video: (Figure C) In this menu the user can: • set duration of the loop recording •... -
Page 5: Other Menu Options
OTHER MENU OPTIONS Playback Menu: (Figure F) You can access this menu by hitting the icon in the Menu Layover. (pg. 3 Figured D) • Provides video files from the 360 camera • Provides video files from the rearview camera •... -
Page 6: Power Off Options
POWER OFF OPTIONS Power Off Options: (Figure H) When the vehicle is turned off, the dashcam screen will display an alert. This alert will appear for about 3 seconds. If there is no operation, the unit will be turned off automatically. (Figure H) There are three options in the alert menu. -
Page 7: Specifications
SPECIFICATIONS REV. 4/16/2019 INSTTE-DVR360... - Page 8 Log onto www.installerinstitute.com or call 800-354-6782 for more information and take steps toward a better tomorrow. Metra recommends MECP certified technicians iBEAM Vehicle Safety Systems iBEAMUSA.com ® © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 4/16/19 INSTTE-DVR360...
