- Page 1 6/26/2019 ZOLL 731 Easy Set Up Guide Vent Overview Vent Status Indicator Vent parameter buttons Alarm Silence/ Cancel Action Confirmation button Rotary Selection Knob Single Manual Breath Startup Switch...
-
Page 2: Select Mode
6/26/2019 Start-up 2. Self test auto runs; light should turn green 1. Rotate knob to right Select mode Should default to AC (V), if not follow steps below. 1. Push button once to highlight mode 2. Rotate knob to “AC” 3. -
Page 3: Set Volume
6/26/2019 Set Respiratory Rate 1. Push button to highlight 2. Rotate knob to desired rate 3. Press confirm button 4. Press button twice to highlight High alarm 5. Rotate knob to 10 above set 6. Press confirm button 7. Press button three times to highlight Low alarm 8. - Page 4 6/26/2019 Set Pressure Alarms and PEEP 1. Press button once 2. Rotate knob to select high pressure 10-15 higher than outlined number (not > 40) 3. Press confirm button 4. Press button twice 5. Rotate knob to select low pressure 10-15 below outlined number 6.
- Page 5 6/26/2019 Set FiO2 1. Press button once 2. Rotate knob to desired FiO2 3. Press confirm button ABG and Vent Changes • Normal Ranges – pH 7.35-7.45 PaCO2 35-45 HCO3 22-26 PaO2 80-100 • Increase RR or VT to lower PaCO2/ increase pH •...
- Page 6 6/26/2019 Recommended adjunct placement 1. Suction 2. Emma 3. HME 4. MDI 5. Neb...
