Application
Programming
Interface (API)
NI-SCOPE SFP
NI-SCOPE
Instrument Driver

NI-SCOPE Examples

Examples demonstrate the functionality of the device and serve as programming models and
building blocks for your own applications.
The NI Example Finder is a utility available for some ADEs that organizes examples into
categories and allows you to easily browse and search installed examples. You can see
descriptions and compatible hardware models for each example, or see all the examples
compatible with one particular hardware model.
To locate examples, refer to the following table:
Table 3. PXI/PCI-5154 Programming Options
Location
Available from the start
menu at Start»All
Programs»National
Instruments»NI-SCOPE»
NI-SCOPE Soft Front
Panel.
LabVIEW—Available on
the LabVIEW Functions
palette at Measurement
I/O»NI-SCOPE.
C or LabWindows/CVI—
Available at Program
Files»IVI Foundation»
IVI»Drivers»niScope.
Microsoft Visual C/C++—
Use examples located in the
file directory
Users
\Public\Documents
\National
Instruments\NI–SCOPE
.
\examples
PXI/PCI-5154 Getting Started Guide | © National Instruments | 11
Description
The NI-SCOPE SFP acquires, controls,
analyzes, and presents data, similar to
stand-alone oscilloscopes. The
NI-SCOPE SFP operates on the PC, so
you can view and control waveforms
directly from your computer. You can
also run multiple sessions of the
NI-SCOPE SFP simultaneously.
The NI-SCOPE API configures and
operates the device hardware and
provides customizable acquisition,
control, analysis, and measurement
options using LabVIEW VIs or
LabWindows/CVI functions.
You can modify an NI-SCOPE C
example to create an application with
Microsoft Visual C/C++. Copy an
NI-SCOPE example to copy required
project settings for include paths and
library files. Alternatively, refer to the
Creating an Application with Microsoft
Visual C and C++ topic of the NI High-
Speed Digitizers Help to manually add
all required include and library files to
your project.
