- Page 1 JPL-Element-X500 User Guide...
- Page 2 • 24 Month repair or replacement warranty IMPORTANT AUTO SET UP NOTICE This headset will auto configure to your desk phone. The compatibility switch should be used in the alternative position, if no dial tone is heard in the headset when active. It will take up to 3 minutes for the phone and headset to establish the optimum call quality with our Auto Setup feature, ensuring the best sound. Simply make a test external call and the headset will configure to the required settings for your phone. Helpful Setup Videos Found Here - https://www.jpltele.com/jpl-tutorials.aspx...
-
Page 3: What's Included
USB Cable Type-A to Mini-B Module Headband Headband Type of lead varies depending on phone model. Please refer to EHS Guide www.jpltele.com/ehs-cables USB Cable Type-A to Microphone JPL-DECT Lifter Electronic Hook Micro USB for optional Boom Arm Switch (EHS) headset charging method... -
Page 4: Attaching The Headband
Attaching the headband To attach the microphone boom arm to the headband, align the triangle shape on the microphone boom arm with the triangle shape on the headband and push to click into place. The microphone boom arm will then rotate to your Align required position. -
Page 5: Positioning The Microphone
Positioning the Microphone The microphone boom arm is flexible, so you can gently bend the boom and position it to suit the curve of your face. The ideal position for the microphone is at the corner of the mouth approximately 30mm (2 finger width) away from the mouth. 30mm Microphone Boom Volume Control Mute / Speaker Volume Hook On/Off Answer / End Down a call Mute... - Page 6 Connecting the Base Unit to your Desk Phone Helpful Setup Videos Found Here - https://www.jpltele.com/jpl-tutorials.aspx Base Unit Handset Port Telephone Port Compatibility DC Jack AUX Port Switch Desk Phone with Headset Port • Plug the supplied telephone cord into the TEL port of the base unit •...
-
Page 7: Operating Instructions
Operating Instructions Please note: Your JPL-Element-X500 is supplied paired to the base unit straight out of the box. However, if after charging the headset, the ‘GREEN’ TEL light doesn’t activate when the headset is removed from the base unit, then you should follow these instructions. Pairing a headset to the base unit: 1) Make sure there is no power to the base unit 2) Take the headset off the base unit 3) Hold the ‘mute button’... - Page 8 Base Unit Microphone Volume Microphone Mute Button Bluetooth PC/TEL Compatibility Pairing Button Selection Switch Bluetooth Button This function works when the Bluetooth module is inserted PC/TEL Selection This function works when the USB cartridge is inserted Microphone Mute Button Press to mute the call Microphone Volume Your headset has automatic audio configuration, (this can take a few minutes to settle) however, if required, you can adjust the volume...
-
Page 9: Visual Indicator
Base Unit Telephone Indicator Microphone Mute Indicator (Green Light) (Red Light) Battery Charge Indicator PC/Bluetooth Indicator (Blue Light) (White Light) Bluetooth Microphone Button Mute Button PC/TEL Selection Visual Indicator Charging Status LED Status Charging Battery Indicator: ‘Flashing’ 1 sec-ON, 1 sec-OFF Fully Charged Battery Indicator: ‘ON’... -
Page 10: Troubleshooting
- Your phone number - Your email address - Phone number - Region - Fault with product - Barcode serial number (found on the bottom of the base unit) - Number of units We will endeavour to respond to you within the next full working day. Helpful Setup Videos Found Here - https://www.jpltele.com/jpl-tutorials.aspx... -
Page 11: Additional Accessories
Additional Accessories X500 Cartridge Module for USB Connection • Softphone interoperability through USB/computer with 3CX, Avaya One-X, Cisco Jabber, Counter Path and Skype with assistance from the JPL Gateway. • JPL Gateway software must be installed and running for remote call control functions to work with supported softphones. www.jpltele.com/gateway • Before inserting your USB cartridge, make sure that the base unit is powered-off. USB Cable Type-A to Mini-B • After inserting the cartridge, connect the power and then connect the USB cable. • To make a USB call, press the “PC/TEL’ button. • When you press the “PC/TEL” button, the “PC/TEL” LED will flash on and off. Microphone Volume... -
Page 12: Bluetooth Connection
• Bluetooth allows the DECT headset to connect wirelessly to Bluetooth enabled smartphones. • This headset allows wireless conversations from any desk phone, softphone and mobile. • Before inserting your Bluetooth cartridge, make sure that the base unit is powered-off. JPL-DECT Lifter • The JPL-DECT Lifter remotely lifts the desk phone handset to make or answer a call. www.jpltele.com/accessories (Refer to the JPL-DECT Lifter installation guide). Electronic Hook Switch (EHS) Adapter •... - Page 13 LIMITED WARRANTY Consequential and incidental damages, including without limitation, loss of property and those arising from breach of any express or implied warranty, are not the responsibility of JPL Telecom and to the extent permitted by law, are excluded. In accordance with its policy of progressive product design, JPL Telecom reserves the right to change product specifications without prior notice.
