- Page 1 MSI-4260M Port-A-Weigh Crane Scale Technical Manual January 14, 2020 PN 196858...
- Page 2 All information contained within this publication is, to the best of our knowledge, complete and accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make changes to the technology, features, specifications and design of the equipment without notice.
-
Page 3: Table Of Contents
4.10 Battery Life ..................16 Technical training seminars are available through Rice Lake Weighing Systems. - Page 4 8.0 Specifications ............... . . 32 Rice Lake continually offers web-based video training on a growing selection of product-related topics at no cost.
-
Page 5: Introduction
Do not use improperly rated or sized shackles. Use only Rice Lake Weighing Systems recommended shackles. Do not remove or obscure warning labels. For guidelines on the safe rigging and loading of overhead scales, read the Rice Lake Weighing Systems Crane Scale Safety and Periodic Maintenance Manual (available at www.ricelake.com). -
Page 6: Installation
Installation This section provides an overview of MSI-4260M Port-A-Weigh crane scale installation instructions. The MSI-4260M features a heavy duty, IP66 cast aluminum enclosure. The MSI-4260M installs easily by hanging it on a crane using properly sized shackles. Refer to the Crane Scale Safety and Periodic Maintenance Manual (PN 153105) for safe loading and rigging WARNING guidelines when installing the MSI-4260M. -
Page 7: Batteries
Installation Batteries The MSI-4260M is powered by six (6) D cell 1.5 V alkaline batteries. The operating battery life is up to 1000 hours depending on the following factors: • The brightness of the LCD display backlight • The amount of RF activity •... -
Page 8: Communications Port
The MSI-4260M has a single Communications Port allowing access to the embedded ScaleCore through the terminal access mode or Rice Lake software. The terminal access mode is used for updating scale firmware while Rice Lake software can be used for calibration and configuration, backup and adjusting scale settings.This Communications Port is not intended for output use. -
Page 9: Radio Compliance
All radio options meet FCC and international radio compliance per the certification information listed in this section. These modules may have additional international certifications that are not listed in this section. Please contact Rice Lake Weighing Systems if you require operation in a jurisdiction that is not listed. -
Page 10: Antenna
Servicing The Rice Lake dealer network provides both on-site and depot servicing of the MSI-4260M. Please contact a local dealer or Rice Lake Weighing Systems to obtain a return material authorization (RMA). Due to the weight and size of many of the product, it is not always necessary to return the whole scale. -
Page 11: Operation
Operation Operation This section provides an overview of MSI-4260M Port-A-Weigh Crane Scale operation instructions. Display The keys and display of the MSI-4260M front panel are shown and described below: Sealed Calibration Switch Section 5.1 on page 17 RS-232 Serial Port Section 6.0 on page 25... -
Page 12: Power
(taring) a package or pallet weights. The scale digits display 0 (or 0.0 or 0.00, etc). Note The backup memory in the MSI-4260M stores the zero reading and retains it even if the power fails. Rules for Use • Works in GROSS or NET mode •... -
Page 13: User
• If a wrong value is entered, press to step back one digit and press to change the digit If a function key does not work, the MSI-4260M is not set up to support the key. Note For example, if is set to Total, the Total mode must also be set up in the Setup Menu. -
Page 14: Setup
MSI-4260M Port-A-Weigh Crane Scale Setup This section provides an overview of MSI-4260M Port-A-Weigh crane scale setup menu and instructions. Setup Menu To enter into the MSI-4260M setup menu, press simultaneously. Figure 4-1. Setup Menu Parameter Setting Description Test Display – See Section 4.2.2 on page 11... -
Page 15: Function User Keys
Set Function Key The MSI-4260M has one user definable key on the front panel, that can be programmed to one of several functions. The additional function key is available on the optional RF Rugged Remote Control or RF remote display. -
Page 16: Total
MSI-4260M Port-A-Weigh Crane Scale 4.2.3 Total Set the total parameter to for the MSI-4260M or for the F2 key on a connected RF Rugged Remote Control or RF remote display. The total mode must be programmed from the Setup Menu before will function (Section 4.8 on page... -
Page 17: Sleep
The display brightness changes when each setting displays. Note 5. Press when the desired setting displays. displays. 6. Press to exit setup and store the settings. Press at any time to cancel the procedure. Note © Rice Lake Weighing Systems ● All Rights Reserved... -
Page 18: Setpoints
Setpoint 2 is Green Setpoint 3 is Red Figure 4-2. Setpoint LEDs The MSI-4260M has an audible output option that is triggered by Setpoint 1. Contact Rice Lake Weighing Systems for other setpoint output options. To set the setpoint: Setpoint... -
Page 19: Total
5. With choice displayed, press to select. displays. 6. Press to save and exit to weighing mode or press to continue to another setup menu item. © Rice Lake Weighing Systems ● All Rights Reserved... -
Page 20: Filter
If the reading is not stable, it can often be improved by increasing the filter setting. Settling time is longer as the filter setting is increased. However, the MSI-4260M employs algorithms that speed up large weight changes while still controlling vibration even with high filter settings. -
Page 21: Calibration
This section provides an overview of MSI-4260M Port-A-Weigh Crane Scale calibration instructions. The MSI-4260M is calibrated using the certified test weights. It is required that the weight used is at least 10% of full capacity in order to achieve rated accuracy. For example, use at least a 500 lb test weight to calibrate a 5000 lb capacity scale. Although a single span point is usually adequate for rated accuracy, the MSI-4260M supports Multi-Point calibration with up to four span points plus zero. -
Page 22: Calibration Menu
Standard Calibration See the following information for standard calibration procedure. Use the following steps to calibrate the MSI-4260M using the standard calibration procedure. 1. Remove the hex seal screw from the MSI-4260M using the steps from Section 5.1 on page 17 and ... -
Page 23: Auto Zero Maintenance
This occurs when minor variations of weight occur while picking up scale attachments and the variations fall within the AZM capture window. The AZM capture window (usually 1 ‘d’) and capture time (usually 8 seconds) can be adjusted by Rice Lake Weighing Systems to meet custom requirements. -
Page 24: Zero Power Up
If the reading is not stable, it can often be improved by increasing the filter setting. Settling time will be longer as the filter setting is increased. The MSI-4260M employs algorithms that speed up large weight changes while still controlling vibration even with high filter settings. Selections are , and . -
Page 25: Initial Calibration
Table 5-2. Initial Calibration Menu Parameters Use the following steps to calibrate the MSI-4260M using the initial calibration procedure. 1. Turn the MSI-4260M off. 2. Remove the hex seal screw from the MSI-4260M using the steps from Section 5.1 on page 17 and ... -
Page 26: Guidelines For Capacity And Resolution
The other is to increase the d (reduce resolution). The third way is to increase the Motion Window. The MSI-4260M defaults to ±1 d as a motion window. It can be changed at Rice Lake Weighing Systems to a higher value if desired. Often ±3 d is chosen for bridge cranes as these tend to have a lot of bounce to them. -
Page 27: C-Cal Calibration
C-Cal Calibration When adequate test weights are not available, the MSI-4260M can be calibrated using a programmed constant calibration which is referred to as C-Cal. To use C-Cal, a C-Cal number must be known from a previous calibration. When a calibration is performed with test weights, a new C-Cal is generated. -
Page 28: Calibration Setup Menu
Description Industrial (indu5) This is the most common setting for the MSI-4260M; With the Industrial standard, you have full range zero, access to units switching, filters, and peak hold Handbook 44 (Hb-44) Sets the scale to enable only approved features per the NTEP HB-44 rules and regulations; Access is denied to Peak Hold, and the zero range may be limited;... -
Page 29: Communications Setup
For all devices that must interconnect, the RF Channel and Network ID must match. The ScaleCore ID must be unique. The MSI-4260M or other RF equipment that is a weight data source should be set to a ScaleCore ID of 0. If other devices are added, they can be added in sequence. -
Page 30: Printer And Serial Output Setup
The RS-232 communications port is capable of outputting load data. All of the RF linked weight device weight modes are available in user formatted form. The communications port settings reside only in the MSI-4260M and are independent of any print settings in connected RF Rugged Remote Control or RF remote display. -
Page 31: Standard Print Strings
Communications Setup Control Mode () The control mode program is what controls the MSI-4260M to print. To access the control mode parameter, see the following information: 1. To access the Communications menu, press at the same time. displays. 2. Press to enter . -
Page 32: Rf Network Menu Setup
. 3. Press to edit the parameters. The MSI-4260M uses 802.15.4 transceivers to communicate with an compatible RF remote control or RF remote display. The MSI-4260M uses three numbers to establish a network. Table 6-6 lists out the three elements used in setting up a network. - Page 33 Communications Setup 802.15.4 RF Network Setup The MSI-4260M uses three numbers to connect to an 802.15.4 piconet: For printer and serial output setup, see the following information: To enter the menu: 1. Press at the same time. displays (Figure 6-1 on page 25).
-
Page 34: Troubleshooting/Maintenance
‘d’; It is also possible to increase the motion window; Contact Rice Lake Weighing Systems if you have a problem getting the MSI-4260M to zero, tare, or total due to stability issues... -
Page 35: Service Counters
Troubleshooting/Maintenance Service Counters Only a Rice Lake Weighing Systems technician can reset the service counters, as these are an important safety WARNING warning feature. A thorough load train inspection is necessary to ensure product safety. The MSI-4260M maintains two service counters for safety. -
Page 36: Specifications
MSI-4260M Port-A-Weigh Crane Scale Specifications Accuracy Auto-Off Mode ± (0.1% +1 d) of applied load Powers off after the scale is not used for the set time (in minutes); 15, 30, 45, 60 or OFF selectable Resolution Auto Sleep Mode... - Page 38 Specifications subject to change without notice. Rice Lake Weighing Systems is an ISO 9001 registered company. 230 W. Coleman St. • Rice Lake, WI 54868 • USA U.S. 800-472-6703 • Canada/Mexico 800-321-6703 • International 715-234-9171 • Europe +31 (0)26 472 1319...
