Summary of Contents for Mercury Racing VesselView

  • Page 2 Safety Alerts and Notices Throughout this publication, dangers, warnings, cautions, and notices, accompanied by the international HAZARD symbol , are used to alert the technician to special instructions concerning a particular service or operation that may be hazardous if performed incorrectly or carelessly. These safety alerts follow ANSI standard Z535.6‑2006 for product safety information in product manuals, instructions, and other collateral materials.
  • Page 3 Mercury, Mercury Marine, MerCruiser, Mercury MerCruiser, Mercury Racing, Mercury Precision Parts, Mercury Propellers, Mariner, Verado, Vazer, #1 On The Water, Alpha, Bravo, Pro Max, OptiMax, Sport‑Jet, K‑Planes, MerCathode, SmartCraft, VesselView, Quicksilver, Zero Effort, M with Waves logo, Mercury with Waves logo, and SmartCraft logo are all registered trademarks of Brunswick Corporation.

  • Page 4: Table Of Contents

    Propulsion, Vessel, and Environment Buttons..5 Using Brightness/Alarm Button......12 Brightness and Alarm Button......5 Using the "Clock/Light" Menu Option....12 Menu Button............5 Status Bar..............13 Turning the VesselView Unit On or Off....5 Fault Icons............14 Restarting VesselView..........5 Fuel Alarms..........15 Cleanliness and Care of Product......5 Saving Settings............16 Using the Menu Panel..........6...
  • Page 5 Manual Method Procedure....... 77 Pages On/Off..........107 Configuration..........79 Alarms..............109 Factory Reset..........81 Alarms Menu Options........109 Reset Settings..........81 VesselView Warning Horn Strategy....109 Adding or Removing Sensors to the Active Alarms..........110 Vessel............81 Fault Icons..........111 Save Configuration........82 Viewing Active Alarms......112 Load Configuration........85 Viewing Alarm Details.......113...
  • Page 6 Cutting the Instrument Panel.......148 MerCruiser and Outboard Applications ‑ Dual Preparing the Mounting Location....148 Engine.............156 Cutting the Panel..........148 MerCruiser and Outboard Applications ‑ Triple Securing VesselView to the Instrument Engine.............160 Panel............149 MerCruiser and Outboard Applications ‑ Quad VesselView Bezel Removal......149 Engine.............164 DTS Wiring Guidelines........150...
  • Page 7 Page iv 90-8M8022154 APRIL 2008...

  • Page 8: Section 1 - Getting Started

    Brightness and Alarm Button ......5 Using the "Clock/Light" Menu Option ... 12 Menu Button ........... 5 Status Bar............13 Turning the VesselView Unit On or Off....5 Fault Icons ............ 14 Restarting VesselView.......... 5 Fuel Alarms ..........15 Cleanliness and Care of Product......5 Saving Settings...........

  • Page 9: Vesselview Specifications

    79‑898277K16 VesselView Race Edition Kit Components Harness/Kit/Component Part Number Vessel Harness Assembly 84‑898273T01 VesselView Adapter Harness (Not required if a Mercury Racing Sterndrive Rigging Kit is 84‑889278T01 installed on vessel.) GPS Antenna 879172T64 VesselView NEMA 0183 Adapter Harness Assembly 84‑899751T01 CAN P GPS Harness 84‑879171T23...
  • Page 10 Section 1 - Getting Started The VesselView unit is equipped with a USB port that enables configuration settings to be saved to, or imported from, a USB memory stick. 32711 VesselView Race Edition display screens are grouped into three categories:...

  • Page 11: Keypad Functions

    Section 1 - Getting Started Keypad Functions Mounted on the VesselView unit are seven buttons and an arrow trackpad for easy navigation through screens and pages. 25354 X button Vessel button Environment and navigation button Check button Brightness and alarm button...

  • Page 12: Propulsion, Vessel, And Environment Buttons

    At any time you can restart VesselView without the loss of any information or configuration changes. To restart VesselView, press and hold the X button and the check button at the same time until the system restarts. VesselView will display the last active screen after it completes the boot up cycle.

  • Page 13: Using The Menu Panel

    To see the available propulsion screens, press the propulsion button and then the menu button. The "Propulsion" menu panel appears. IMPORTANT: The available VesselView menu options may display differently than those listed in the pictures; menu options depend on the engine type, if tabs are a part of the vessel configuration, and if screens have been manually turned on or off.
  • Page 14 Section 1 - Getting Started To see the available environment and navigation screens, press the environment and navigation button and then the menu button. The "Env/Nav" menu panel appears. Env Nav Depth Trip Log Fuel To Wpt Navigation 32710 Environment/Navigation Menu Panel 90-8M8022154 APRIL 2008 Page 7...

  • Page 15: Navigating Through The Screens

    To see the available main screens, with the menu panel open in any of the categories, press the menu button. The "Main" menu panel appears. When the menu button is pressed again VesselView toggles back to the category menu. Main...

  • Page 16: Using Dialog Boxes And Pop-Up Windows

    Pop‑up windows will appear on any screen in VesselView as a pop‑up window and will remain open for a short duration of time or, as is the case of the "ALARMS DETAILS"...

  • Page 17: Trim/Tab Pop-Up Window Settings

    Section 1 - Getting Started If no is selected the faults/warnings will not appear as a pop‑up on the screen but the status bar will still display the current faults/warnings. Refer to Section 1 - Status Bar for further information. 33075 TRIM/TAB POP-UP WINDOW SETTINGS The trim/tab pop‑up window can be modified to be "On"...

  • Page 18: Page/Screen Organization

    Depending on the vessel configuration, the pop‑up will only display components connected to the VesselView unit. If both trim and tabs exist on the vessel, and are connected to the VesselView unit, the "TRIM/TAB" pop‑up will display both the trim chart and the tab chart.

  • Page 19: Screen Brightness

    The screen brightness can be adjusted using the brightness/alarm button while in any VesselView display screen as long as there is not an active fault in the system. If an active fault exists, the brightness/alarm button will first go to the "Active Alarms"...

  • Page 20: Status Bar

    ALL engines off. Status Bar VesselView displays important information in the status bar at the top of each screen. The status bar displays up to four different icons and messages. Notices of conditions that may need attention (such as warnings, fuel level alerts, and faults) appear as an icon on the left side of the status bar with a short description of the fault.

  • Page 21: Fault Icons

    Depth Fault Icons VesselView displays fault icons to alert the operator of any faults or warnings with an icon on the left side of the status bar. A description of the fault or warning will appear over the other status bar fields. If all systems are operating normally a green icon with the word "OK"...

  • Page 22: Fuel Alarms

    IMPORTANT: A fuel fault alarm will only occur if all fuel tanks on the vessel, connected to VesselView, are sending a low fuel condition fault. If only one of many is sending a low fuel condition fault, the VesselView will not identify the fault. The system looks at all tanks defined as fuel and adds them all together into a single sum.

  • Page 23: Saving Settings

    VesselView operates in sessions. Configuration changes can be made to a session but when the VesselView unit is shutdown before saving it will lose those changes and go back to its default settings (or last saved configuration settings). When changes are made to any of the VesselView settings, whether for calibrating settings or for customization, those changes need to be saved.

  • Page 24: Section 2 - Initial Setup And Calibration

    Section 2 - Initial Setup and Calibration Section 2 - Initial Setup and Calibration Table of Contents Setup Wizard Overview........18 Device Setup ..........23 Setup Wizard............18 Tank Setup and Calibration ......24 Import Configuration (optional) ..... 19 Tab Setup and Calibration ......36 Engine Setup ..........

  • Page 25: Setup Wizard Overview

    VesselView's are installed on the vessel. • Tank setup and calibration—This is used to define the tanks purpose, size, and location on the vessel. Tanks will need to be calibrated so that the data displayed in VesselView is accurate. •...

  • Page 26: Import Configuration (Optional)

    The VesselView unit will not recognize memory sticks that are only version 2.0 compatible. IMPORTANT: Configuration settings saved to a USB memory stick are compiled into one data file. Only one file can exist in the root of the USB memory stick. VesselView will not recognize multiple import files.
  • Page 27 Section 2 - Initial Setup and Calibration 2. Insert a USB memory stick into the USB port on the back of the VesselView unit. 27329 Ethernet port (for future option) USB port USB memory stick IMPORTANT: Do not remove the USB memory stick until the import process is complete.

  • Page 28: Engine Setup

    Section 4 - Calibrate Menu Options Engine Setup VesselView automatically detects the vessel's power package. On the "ENGINE SETUP" screen, VesselView enables you to change the type and number of engines. The available power packages are: • "2 Stroke Gas Outboard"...

  • Page 29: Display Setup

    "ENGINE TYPE" field (this could take several seconds). If an engine type does not appear, check that all engine ignition keys are in the "RUN" position and that the VesselView unit is properly connected. For installation information, refer to Section 8 ‑ Installation and Wiring.

  • Page 30: Device Setup

    IMPORTANT: Do not choose the same Unique VesselView ID for multiple VesselView installations. 1. If there is only one VesselView unit installed on the vessel, proceed to step 5; otherwise, press the check button to access the "UNIQUE VESSELVIEW ID" field.

  • Page 31: Tank Setup And Calibration

    3. Press the down arrow on the arrow trackpad to proceed to the "HELM ID" field. NOTE: Use "HELM ID 1" for single helm vessels. If a vessel has multiple VesselView units installed on different helms (up to four maximum) the "HELM ID" needs to represent the helm where each VesselView is installed (lowest to highest helm is recommended).
  • Page 32 Section 2 - Initial Setup and Calibration NOTE: The "TANK SETUP" screen shown is for a triple engine configuration that contains center tank positions. Quad applications will show additional positions for starboard center and port center tanks. 1. Press the check button to enter tank setup. 2.
  • Page 33 Section 2 - Initial Setup and Calibration NOTE: The default unit for measuring tank capacity is U.S. gallons. To choose a different unit of measurement, refer to Section 4 - Units 2 . 32782 7. Press the down arrow to proceed to the next tank. 8.
  • Page 34 Section 2 - Initial Setup and Calibration 13. Confirm your selections by pressing the check button. The next screen that will appear shows the tank setup table complete with all data entered for each tank. 32784 NOTE: Tank locations have now been confirmed. 14.
  • Page 35 Section 2 - Initial Setup and Calibration • Choose "FILL TANK" (go to step c) for irregularly shaped tanks. The "FILL TANK" method must be initiated with an empty tank and filled in intervals. As you step through the "FILL TANK" procedure the current sender value is placed into the "MANUAL"...
  • Page 36 Section 2 - Initial Setup and Calibration ii. On the "TANK CALIBRATION" screen, press the up or down arrow on the arrow trackpad to highlight the "DEFAULT" calibration method and press the check button. Empty will be 0%, 1/4 tank will be 25%, 1/2 tank will be 50%, etc. 32213 iii.
  • Page 37 33–240 Ohms. A resistance value of approximately 33 Ohms represents a full tank. A resistance value of approximately 240 Ohms represents an empty tank. VesselView allows for sender calibration to correct for sensors that are slightly outside this range. The senders used in irregularly shaped tanks need to be calibrated to the tank as substance is added in the "FILL TANK"...
  • Page 38 Section 2 - Initial Setup and Calibration i. Press the check button to select the tank to be calibrated. 32784 ii. On the "TANK CALIBRATION" screen, press the up or down arrow on the arrow trackpad to highlight the "MANUAL" calibration method and press the check button.
  • Page 39 IMPORTANT: It is not necessary to perform the procedure using quarters of a tank, although this will establish a more accurate tank calibration. It is most important that, at minimum, empty (0%) and full (100%) are calibrated. VesselView will calculate the quarter percentages using the empty and full data.
  • Page 40 Once all tanks have been calibrated (identified as blue text), end the calibration process by selecting the X button. NOTE: Upon completing any change/customization to VesselView a blue pop‑up message will appear as a reminder to save your session. Refer to Section 1 - Saving Settings . To save time, it is recommended that all session changes be saved before holding X button while keying ALL engines off.
  • Page 41 Section 2 - Initial Setup and Calibration i. Press the check button to select the tank to be calibrated. 32784 ii. On the "TANK CALIBRATION" screen, press the up or down arrow on the arrow trackpad to highlight the "FILL TANK" calibration method and press the check button.
  • Page 42 Section 2 - Initial Setup and Calibration vii.Following the direction on the screen, fill the tank to 100% of its capacity. Press the check button to confirm or the X button to go back one step. After the check button is pressed a blue pop‑up message will appear acknowledging that the system is "Working"...

  • Page 43: Tab Setup And Calibration

    "TAB SETUP" screen. Tab Setup and Calibration For vessels equipped with a tab or tabs, VesselView will need to be calibrated to the tab sensor. VesselView does not display the tab chart for power packages without tabs. Refer to Section 4 - Trim/Tab Pop-Up (Settings).
  • Page 44 Section 2 - Initial Setup and Calibration 1. Press the check button to enter tab setup. 32786 2. Press the left or right arrow on the arrow trackpad to identify how many tabs are installed on the vessel. If there are no tabs installed, press the X button to go back one step to the "TAB SETUP"...
  • Page 45 Section 2 - Initial Setup and Calibration 8. Press the left or right arrow on the arrow trackpad to select the tab to be calibrated. 32764 9. Press the check button to begin calibrating the selected tab. 10. Lower the respective tab into its down position. 11.
  • Page 46 21. Once all tabs have been calibrated, end the calibration process by selecting the X button. NOTE: Upon completing any change/customization to VesselView a blue pop‑up message will appear as a reminder to save your session. Refer to Section 1 - Saving Settings . To save time, it is recommended that all session changes be saved before holding X button while keying ALL engines off.

  • Page 47: Complete

    32250 When you are sure that your changes are correct, press the check button to save your session and restart the VesselView unit. VesselView displays a saving settings message, then restarts. The restart process may take a few minutes. NOTE: If you want to change the vessel configuration after exiting the setup wizard, you may either restart the wizard by choosing Reset Settings Directory on the "FACTORY...

  • Page 48: Section 3 - Vesselview Race Edition Screen Overview

    Section 3 - VesselView Race Edition Screen Overview Section 3 - VesselView Race Edition Screen Overview Table of Contents Available VesselView Race Edition Display Screens VesselView Race Edition Setup Screens... 52 ................42 Calibrate ............52 MerCruiser Display Screens ......42 Settings ............

  • Page 49: Available Vesselview Race Edition Display Screens

    Section 3 - VesselView Race Edition Screen Overview Available VesselView Race Edition Display Screens The following charts show the available screens for MerCruiser, Race Sterndrive, Outboard, Race Outboard, and Jet Drive engines. MerCruiser Display Screens Diesel Diesel Screen Diesel Diesel...

  • Page 50: Outboard And Jet Drive Display Screens

    Navigation VesselView Race Edition Display Screens NOTE: The screens listed in the following charts may vary depending on vessel setup, engine type, and number of engines. Refer to Section 3 - Available VesselView Race Edition Display Screens 90-8M8022154 APRIL 2008...

  • Page 51: Propulsion

    Section 3 - VesselView Race Edition Screen Overview Propulsion Propulsion Engine Status Fuel Status Inches/Rev Oil Press Oil Temp Trim/Tabs Delta Press Peak Perf Trim/Tabs 2 32631 Screen Display Description Screen Name Displays engine RPM, speed, and various engine data Engine Status depending on the engine type.
  • Page 52 Section 3 - VesselView Race Edition Screen Overview Screen Display Description Screen Name Displays engine RPM, speed, coolant pressure, coolant Oil Pressure temperature, and oil pressure. 33007 Displays engine RPM, speed, coolant pressure, oil Oil Temperature temperature, and oil pressure.
  • Page 53 Section 3 - VesselView Race Edition Screen Overview Screen Display Description Screen Name Displays engine RPM, speed, and trim and tab positions in a Trim/Tabs 2 graphical form. 33012 Page 46 90-8M8022154 APRIL 2008...
  • Page 54 Section 3 - VesselView Race Edition Screen Overview Notes: 90-8M8022154 APRIL 2008 Page 47...

  • Page 55: Vessel

    Section 3 - VesselView Race Edition Screen Overview Vessel Vessel Perf & Fuel Vessel Status Tank Status Steer Position Speed Generator 32632 Screen Display Description Screen Name Displays engine RPM, speed, fuel tank levels, total fuel used, and estimated fuel range.
  • Page 56 Section 3 - VesselView Race Edition Screen Overview Screen Display Description Screen Name Displays steering position, depth or wind speed with the source identified, and vessel speed with the source identified. Steer Position NOTE: Pressing the check button while viewing this screen enables you to edit this screen.

  • Page 57: Environment And Navigation

    Section 3 - VesselView Race Edition Screen Overview Environment and Navigation Env Nav Depth Trip Log Fuel To Wpt Navigation 32710 Screen Display Description Screen Name Displays water depth and enables the operator to change the depth alarm limits. NOTE: Pressing the check button while viewing this screen Depth enables you to edit the alarm specifications.
  • Page 58 Section 3 - VesselView Race Edition Screen Overview Screen Display Description Screen Name NAVIGATION 20 20.328 S Displays the exact location of the vessel. Navigation NOTE: This screen will not have any data shown if there is no 157 44.502 W global positioning device connected to the VesselView unit.

  • Page 59: Vesselview Race Edition Setup Screens

    Section 3 - VesselView Race Edition Screen Overview VesselView Race Edition Setup Screens Main Calibrate Settings Settings 2 Alarms System Info Tech Settings Settings 2 Alarms Calibrate System Info Tech Screen Options Tabs Active Alarms Tank Software Info RPM Bands...
  • Page 60 Trim 33016 Assigns VesselView location, number of engines, and the data Configuration display location. 27125 Resets all VesselView settings to factory default. Can also reset Factory Reset just the engine sensor detection to factory default. 27124 SAVE CONFIGURATION EXPORT TANK CONFIG...

  • Page 61: Settings

    Section 3 - VesselView Race Edition Screen Overview Settings Menu Option Description Screen Screen Options > Sets the status bar info at the top of every display screen. Status Bar 27121 Sets the clock time settings and the brightness of the Clock/Light VesselView display.

  • Page 62: Settings 2

    Section 3 - VesselView Race Edition Screen Overview Menu Option Description Screen Sets unit of speed, depth, distance, temperature, and pressure. Units 27223 Sets units of volume and fuel flow. Units 2 27224 Sets offset for depth, tank, sea temperature, and steering offset Offsets if applicable.
  • Page 63 Section 3 - VesselView Race Edition Screen Overview Menu Option Description Screen Toggles the pop‑up on or off, the type of pop‑up (standard or high resolution), and enables the adjustments to the trim and tab pop‑up time and delta percent settings.

  • Page 64: Alarms

    Section 3 - VesselView Race Edition Screen Overview Alarms Menu Option Description Screen STBD STBD Displays active alarms. Active Alarms STBD STBD 34515 STBD STBD STBD Displays alarms in the history. Alarm History STBD STBD 34516 System Info Menu Option...

  • Page 65: Tech

    Section 3 - VesselView Race Edition Screen Overview Tech Menu Option Description Screen Displays the starboard or port engine run history RPM Bands 33337 Page 58 90-8M8022154 APRIL 2008...

  • Page 66: Section 4 - Main Menu

    Pages On/Off..........107 Theory ............ 71 Alarms............... 109 Procedure ..........72 Alarms Menu Options........109 Trim Calibration Theory.........74 VesselView Warning Horn Strategy....109 Default Method Theory ......75 Active Alarms..........110 Default Method Procedure ....75 Fault Icons ..........111 Manual Method Theory ......77 Viewing Active Alarms ......

  • Page 67: Calibrate (Without Use Of Wizard)

    The third screen asks for a location label for each tank. This label is an identifier on the VesselView screen where the tank physically resides on the vessel. 1. Press the check button to enter tank setup.
  • Page 68 Section 4 - Main Menu • "WASTE" 32781 3. Press the down arrow to proceed to the next tank. 4. Perform steps 2 and 3 for all remaining tanks on the vessel. 5. Confirm your selections by pressing the check button. The next screen will appear asking for the known capacities of each tank.
  • Page 69 Section 4 - Main Menu • "S1" (starboard 1), "S2" (starboard 2), "S3" (starboard 3), "SF" (starboard forward), or "SA" (starboard aft) • "P1" (port 1), "P2" (port 2), "P3" (port 3), "PF" (port forward), or "PA" (port aft) • "C1"...

  • Page 70: Tank Calibration Theory

    Section 4 - Main Menu TANK CALIBRATION THEORY There are three tank calibration methods. Choose "DEFAULT" for uniformly shaped tanks where each quarter of the tank holds a quarter of its total capacity. Choose "MANUAL" or "FILL TANK" for irregularly shaped tanks. The "MANUAL" method is used to fine tune the tank calibrations when you have a known amount in the tank.
  • Page 71 Section 4 - Main Menu 2. On the "TANK CALIBRATION" screen, press the up or down arrow on the arrow trackpad to highlight the "DEFAULT" calibration method and press the check button. Empty will be 0%, 1/4 tank will be 25%, 1/2 tank will be 50%, etc. 32213 3.

  • Page 72: Tank Calibration Using Manual Method

    A normal level sensor would have a resistance reading between 33–240 Ohms. A resistance value of approximately 33 Ohms represents a full tank. A resistance value of approximately 240 Ohms represents an empty tank. VesselView allows for sender calibration to correct for sensors that are slightly outside this range.

  • Page 73: Manual Method Procedure

    Section 4 - Main Menu MANUAL METHOD PROCEDURE 1. Press the check button to select the tank to be calibrated. 32784 2. On the "TANK CALIBRATION" screen, press the up or down arrow on the arrow trackpad to highlight the "MANUAL" calibration method and press the check button. 32217 IMPORTANT: Ensure the tank is empty or it is known what its contents measures.
  • Page 74 IMPORTANT: It is not necessary to perform the procedure using quarters of a tank, although this will establish a more accurate tank calibration. It is most important that, at minimum, empty (0%) and full (100%) are calibrated. VesselView will calculate the quarter percentages using the empty and full data.

  • Page 75: Tank Calibration Using Fill Tank Method

    11. Once all tanks have been calibrated (identified as blue text), end the calibration process by selecting the X button. NOTE: Upon completing any change/customization to VesselView a blue pop‑up message will appear as a reminder to save your session. Refer to Section 1 - Saving Settings . To save time, it is recommended that all session changes be saved before holding X button while keying ALL engines off.
  • Page 76 Section 4 - Main Menu 2. On the "TANK CALIBRATION" screen, press the up or down arrow on the arrow trackpad to highlight the "FILL TANK" calibration method and press the check button. 32218 IMPORTANT: Ensure the tank is empty. 3.
  • Page 77 Section 4 - Main Menu 7. Following the direction on the screen, fill the tank to 100% of its capacity. Press the check button to confirm or the X button to go back one step. After the check button is pressed a blue pop‑up message will appear acknowledging that the system is "Working"...

  • Page 78: Tab Calibration

    This tab calibration procedure utilizes the same tab calibration screens used in the setup wizard. NOTE: Tab calibration does not need to be performed if VesselView was configured using the setup wizard. The "Tabs" menu option located in the "Settings 2" menu enables adjustment to the existing configuration and offers a quick review of the current settings.

  • Page 79: Procedure

    Section 4 - Main Menu PROCEDURE 1. If the tabs were not configured using the setup wizard the first screen to appear will ask if you want to configure the tabs. Press the check button to configure the tabs. If the tabs have already been configured, proceed to step 8.
  • Page 80 Section 4 - Main Menu 8. If the tabs have already been configured, the first screen to appear will ask which tab you would like to calibrate. Press the left or right arrow on the arrow trackpad to select the tab to be calibrated. 32764 9.

  • Page 81: Trim Calibration Theory

    21. Once all tabs have been calibrated, end the calibration process by selecting the X button. NOTE: Upon completing any change/customization to VesselView a blue pop‑up message will appear as a reminder to save your session. Refer to Section 1 - Saving Settings . To save time, it is recommended that all session changes be saved before holding X button while keying ALL engines off.

  • Page 82: Default Method Theory

    Section 4 - Main Menu There are two trim calibration methods. The "DEFAULT" method quickly calibrates the trim to the down position, up position, and maximum trailer position. The "MANUAL" method enables quick adjustments to the calibration settings and compensate for sensor errors. NOTE: Trim calibration does not set the maximum propulsion unit trim and trailer limits.
  • Page 83 27207 7. Press the check button to confirm that you have trimmed all engines or drives to the trailer position or press the X button to go back one step. VesselView will show that it is "Working". NOTE: Upon completing any change/customization to VesselView a blue pop‑up message will appear as a reminder to save your session.

  • Page 84: Manual Method Theory

    Section 4 - Main Menu MANUAL METHOD THEORY To compensate for differences in trim position sensors, select the positions (0 = Down, 10 = Up, and 25 = Max Trailer) and adjust the actual % value to match the current actual % for that known trim position.
  • Page 85 Section 4 - Main Menu 5. Press the down or up arrow on the arrow trackpad to highlight the "ACTUAL DOWN" field. 32749 6. Press the left or right arrow on the arrow trackpad to adjust the "ACTUAL DOWN" trim percentage to match the "CURRENT ACTUAL %".

  • Page 86: Configuration

    12. Press the left or right arrow on the arrow trackpad to adjust the "ACTUAL MAX TRAILER" trim percentage to match the "CURRENT ACTUAL %". 13. Press the check button to go back to the main trim calibration screen. VesselView will show that it is "Working".
  • Page 87 27128 Power package name "HELM ID" ‑ Identifies the helm location of the VesselView "DEVICE ID" ‑ Unique identifier for the VesselView unit "NUM ENGINES" ‑ Number of engines "RIGHT SCREEN" ‑ Engine data displayed on the right side of the screen "LEFT SCREEN"...

  • Page 88: Factory Reset

    12. VesselView will display the "SAVING SETTINGS" screen and restart. Factory Reset The factory reset option is used to reset all VesselView settings to factory default or to perform a sensor detection. To perform a factory reset function, press the menu button until the "Main"...

  • Page 89: Save Configuration

    The VesselView unit will not recognize memory sticks that are only version 2.0 compatible. IMPORTANT: Configuration settings saved to a USB memory stick are compiled into one data file. Only one file can exist in the root of the USB memory stick. VesselView will not recognize multiple import files.
  • Page 90 UNITS/APP PREF 27230 2. Insert a USB memory stick into the USB port on the back of the VesselView unit. Refer to Section 2 - Setup Wizard for an illustration showing the USB port. IMPORTANT: Do not remove the USB memory stick until the export process is complete.
  • Page 91 Section 4 - Main Menu IMPORTANT: If you attempt to load a configuration setting that was not saved to the USB memory stick, the import of the data file will not be successful; a yellow pop‑up message will appear stating "IMPORT UNSUCCESSFUL". To avoid this error, it is practical to save all configuration settings to the USB memory stick (leave all fields read "EXPORT").

  • Page 92: Load Configuration

    The VesselView unit will not recognize memory sticks that are only version 2.0 compatible. IMPORTANT: Configuration settings saved to a USB memory stick are compiled into one data file. Only one file can exist in the root of the USB memory stick. VesselView will not recognize multiple import files.
  • Page 93 Section 4 - Main Menu IMPORTANT: If you attempt to load a configuration setting that was not saved to the USB memory stick, the import of the data file will not be successful; a yellow pop‑up message will appear stating "IMPORT UNSUCCESSFUL". If you can recall the configuration setting that was not saved, select "SKIP"...

  • Page 94: Settings

    X button while keying ALL engines off. Screen Options VesselView displays important information in the status bar at the top of each screen. This section enables you to choose how to populate each field (b, c, and d) with customized data.
  • Page 95 Section 4 - Main Menu The status bar displays information such as time, speed, air temperature, and fuel consumption for example (a total of 16 data fields to choose from) can appear in either of three data fields. 27077 Fault icon location Left data field Center data field Right data field...

  • Page 96: Status Bar

    Section 4 - Main Menu STATUS BAR The status bar is located at the top of the screen and is separated in three different data fields. Changes to the status bar are made in the "STATUS BAR" screen. Menu path: "Main"...

  • Page 97: Steering

    Section 4 - Main Menu NOTE: Upon completing any change/customization to VesselView a blue pop‑up message will appear as a reminder to save your session. Refer to Section 1 - Saving Settings . To save time, it is recommended that all session changes be saved before holding X button while keying ALL engines off.

  • Page 98: Clock/Light

    9. Once you have selected the preferred clock settings, press the check button to save the session. NOTE: Upon completing any change/customization to VesselView a blue pop‑up message will appear as a reminder to save your session. Refer to Section 1 - Saving Settings . To save time, it is recommended that all session changes be saved before holding X button while keying ALL engines off.

  • Page 99: Preferences

    This setting relates to the refresh rate when using a controller area network (CAN) based GPS. 7. Once you have finished selecting your preference settings, press the check button to save the session. IMPORTANT: VesselView may restart in order to establish communications changes with the GPS. Page 92 90-8M8022154 APRIL 2008...

  • Page 100: Sensors

    7. Press the down arrow on the arrow trackpad to proceed to the "TRANSITION SPD" field. 8. Transition speed is the vessel speed at which VesselView stops looking at the paddle wheel and starts looking at the pitot or GPS, if so equipped. The default setting is 25.0 MPH and can be set as low as 3.1 MPH.

  • Page 101: Warnings

    IMPORTANT: A fuel fault alarm will only occur if all fuel tanks on the vessel, connected to VesselView, are sending a low fuel condition fault. If only one of many is sending a low fuel condition fault, the VesselView will not identify the fault. The system looks at all tanks defined as fuel and adds them all together into a single sum.

  • Page 102: Units

    7. Once you have finished adjusting your warnings, press the check button to save the session. NOTE: Upon completing any change/customization to VesselView a blue pop‑up message will appear as a reminder to save your session. Refer to Section 1 - Saving Settings . To save time, it is recommended that all session changes be saved before holding X button while keying ALL engines off.

  • Page 103: Units 2

    11. Once you have finished selecting your units of measure, press the check button to save the session. NOTE: Upon completing any change/customization to VesselView a blue pop‑up message will appear as a reminder to save your session. Refer to Section 1 - Saving Settings . To save time, it is recommended that all session changes be saved before holding X button while keying ALL engines off.

  • Page 104: Offsets

    Section 4 - Main Menu Offsets The "OFFSETS" screen enables you to change the offsets in order to compensate for inaccuracies in depth, tank, and sea temperature. Menu path: "Main" > "Settings" > "Offsets". Press the check button to open the "OFFSETS" screen. 27318 Depth offset Tank offset...

  • Page 105: Settings 2

    X button while keying ALL engines off. Settings 2 Settings 2 Menu Options The "Settings 2" menu enables you to personally customize VesselView. The "Settings 2" menu items include the following: Main Calibrate...

  • Page 106: Calibration Or Adjustment

    Section 4 - Main Menu CALIBRATION OR ADJUSTMENT The tab position sensor changes voltage (current actual %) as the tab is raised or lowered. Changing the actual % value calibrates the tab level indicator to the tab position sensor. To compensate for sensitivity of the tab position sensor, select the positions (100 = Down, 50 = Level, and 0 = Up) and adjust the actual % value to match the current actual % for that known tab position.
  • Page 107 Section 4 - Main Menu NOTE: It is not required that you continue through the calibration process if you are removing a tab from the configuration settings. If you are adding a tab, proceed to calibrate that new tab. 32764 9.
  • Page 108 21. Once all tabs have been calibrated, end the calibration process by selecting the X button. NOTE: Upon completing any change/customization to VesselView a blue pop‑up message will appear as a reminder to save your session. Refer to Section 1 - Saving Settings . To save time, it is recommended that all session changes be saved before holding X button while keying ALL engines off.

  • Page 109: Trim/Tab Pop-Up (Settings)

    Section 4 - Main Menu Trim/Tab Pop‑Up (Settings) The trim/tab pop‑up window can be modified to be "On" or "Off", its length of time that the pop‑up remains open as well the quality of the pop‑up detail ("Standard" or "High Resolution").
  • Page 110 10. Once you have finished selecting your trim/tab settings, press the check button to save the session. NOTE: Upon completing any change/customization to VesselView a blue pop‑up message will appear as a reminder to save your session. Refer to Section 1 - Saving Settings . To save time, it is recommended that all session changes be saved before holding X button while keying ALL engines off.

  • Page 111: Hot Keys

    Section 4 - Main Menu Hot Keys The "HOT KEYS" screen enables you to define specific screens to open when the up or down arrow on the arrow trackpad is pressed. Menu path: "Main" > "Settings 2" > "Hot Keys". Press the check button to open the "HOT KEYS" screen. 33114 There are two modes of hot keys;...
  • Page 112 Section 4 - Main Menu • "CHAPTER" — This mode offers two screens to be designated as hot screens for each category. They are assigned to the up arrow and down arrow on the arrow trackpad. You have the flexibility to choose from any of the screens available from the three categories;...
  • Page 113 6. If you are turning off the hot key functionality, press the X button to close the "HOT KEYS" screen. NOTE: Upon completing any change/customization to VesselView a blue pop‑up message will appear as a reminder to save your session. Refer to Section 1 - Saving Settings . To save time, it is recommended that all session changes be saved before holding X button while keying ALL engines off.

  • Page 114: Pages On/Off

    ALL engines off. Pages On/Off VesselView enables a user to specify exactly what screens, in each of the three categories, they want to have visible. Each category; propulsion, vessel, or environment and navigation, have a variety of screens with different information on each.
  • Page 115 IMPORTANT: If all screens are turned off, the following message will appear requiring you to turn screens back on. VesselView will not function until at least one screen is turned on. When the category button is pressed, and no screens are turned on in that category, a similar pop‑up message will appear.

  • Page 116: Alarms

    If the horn is turned on in the "WARNINGS" screen, the engine alarms will also be heard through the VesselView horn. The VesselView horn will sound a solid tone for all faults and the engine warning horn will sound its specific warning tone. Check the engine owners manual for possible warning horns for your engine.

  • Page 117: Active Alarms

    Section 4 - Main Menu Active Alarms The first awareness of a fault or warning will appear in the status bar. VesselView displays fault icons to alert the operator of any faults or warnings with an icon on the left side of the status bar.

  • Page 118: Fault Icons

    Section 4 - Main Menu FAULT ICONS Icon or Message Icon Description Warning Description Blue "OK" inside a green circle. All systems are operating normally. 26889 Yellow "!" on a black Warning ‑ A fault has occurred. background in a yellow triangle. 26890 Alarm ‑...

  • Page 119: Viewing Active Alarms

    Section 4 - Main Menu If more than one fault has occurred, the faults will appear in the sequence they occurred. STBD STBD STBD STBD 34517 Engine identification Arrow cursor Fault short text Fault icon VIEWING ACTIVE ALARMS You can review active alarm information in two ways: 1.

  • Page 120: Viewing Alarm Details

    Section 4 - Main Menu The "ACTIVE ALARMS" screen will display alarms for up to four engines. All alarms will be listed and numbered. Each numbered alarm will list which engine is activating the fault. Each fault will be identified as "STBD", "PORT", "STBDCNTR", or "PORTCNTR" depending on the number of engines.

  • Page 121: Alarm History Details

    Section 4 - Main Menu All faults and alarms will be listed and numbered. Each numbered fault will list which engine activated the alarm. Each alarm will be identified as "STBD", "PORT", "STBDCNTR", or "PORTCNTR" depending on the number of engines. For a chart to identify each engine, refer to Section 4 - Active Alarms.

  • Page 122: Clearing Alarm History

    NOTE: Pressing the X button while turning the engine key switch "OFF", a master reset, or a loss of power to the VesselView will erase all historic alarms. 2. After pressing the check button to clear the history, a pop‑up window will appear asking you to confirm your selection.

  • Page 123: System Information

    Section 4 - Main Menu System Information System Information Menu Options The "System Information" menu enables you to identify your VesselView software version and hardware serial number. The "System Information" menu items include the following: Main Calibrate Settings Settings 2...

  • Page 124: Hardware Info

    The "HARDWARE INFORMATION" screen provides the VesselView Race Edition hardware build, serial numbers, and the necessary internet protocol (IP) addresses in order to establish connectivity to other VesselView units. Menu path: "Main" > "System Info" > "Hardware Info". Press the check button to open the "HARDWARE INFORMATION"...
  • Page 125 Section 4 - Main Menu The run history screens display the total run time of the selected engine, as well as time spent at a certain engine RPM. This information is used to help determine when engine maintenance is required. Menu path: "Main" > "Tech" > "RPM Bands" > "XXXX History". Press the check button to open the appropriate run history screen.

  • Page 126: Section 5 - Propulsion Menu

    Section 5 - Propulsion Menu Section 5 - Propulsion Menu Table of Contents Using Propulsion Screens........ 120 Viewing Oil Temperature ......124 Viewing Engine Status ....... 120 Viewing Trim/Tabs ........125 Viewing Fuel Status ........121 Viewing Delta Pressure ......125 Resetting Fuel Used ......

  • Page 127: Using Propulsion Screens

    For example: VesselView will not show tab information for a vessel without tabs. Different engine types (sterndrive versus an outboard) will have different screens. Refer to the tables in Section 3 - VesselView Race Edition Screen Overview for a list of the engine types and their associated screens.

  • Page 128: Viewing Fuel Status

    Section 5 - Propulsion Menu • The "P", "SC", and "S" bubbles will change in color when the engine key switch is turned to the run position. They also will change in color when the engine's RPM's are synchronized. • RPM is displayed for up to three engines (triple setup).

  • Page 129: Resetting Fuel Used

    Section 5 - Propulsion Menu RESETTING FUEL USED 1. Press the check button while on this screen to access the Reset your Fuel Used dialog box. The dialog box states "Would you like to Reset your Fuel Used?". 33258 2. Press the check button to reset the fuel used or the X button to cancel. Viewing Inches/Rev The inches/rev screen displays the engine RPM and current speed, as well as the inches travelled per revolution of the engine camshaft, trim position, instantaneous fuel economy,...

  • Page 130: Viewing Oil Pressure

    Section 5 - Propulsion Menu • The "P", "SC", and "S" bubbles will change in color when the engine key switch is turned to the run position. They also will change in color when the engine's RPM's are synchronized. • RPM is displayed for all engines.

  • Page 131: Viewing Oil Temperature

    Section 5 - Propulsion Menu • For a triple engine setup, RPM for the center engine will be displayed in the center speed position. • Displays the current coolant pressure and temperature for all engines. • Displays the current oil pressure for all engines. Viewing Oil Temperature The oil temperature screen displays the current speed and RPM, as well as the coolant pressure, oil temperature, and the oil pressure for up to three engines (triple setup...

  • Page 132: Viewing Trim/Tabs

    Section 5 - Propulsion Menu Viewing Trim/Tabs The trim/tabs screen displays the current speed and RPM, as well as the distance per revolution (in this example: Inches/Rev), trim position, and tab position for up to three engines (triple setup maximum) and three tabs (a starboard and port setup or just a center tab setup).
  • Page 133 Section 5 - Propulsion Menu NOTE: This screen will not appear for a vessel setup with either 2‑stroke or 4‑stroke gas engines. It will appear for the gas Verado engine. 33284 Port engine RPM Port engine boost pressure Starboard engine RPM Starboard engine boost pressure Vessel speed (This field will Port engine delta pressure...

  • Page 134: Viewing Peak Performance

    Section 5 - Propulsion Menu Viewing Peak Performance The peak performance screen displays the current speed and RPM, the peak RPM and peak speed, as well as and delta pressures for up to three engines (triple setup maximum). 33285 Port engine RPM Starboard engine RPM Current vessel speed (This field will change to RPM in a triple engine setup) Port engine RPM when peak speed was captured...

  • Page 135: Resetting Peak Values

    Section 5 - Propulsion Menu RESETTING PEAK VALUES 1. Press the check button while on this screen to access the reset your peak values dialog box. The dialog box states "Would you like to Reset your Peak Values?". 33288 2. Press the check button to reset the peak values or the X button to cancel. Viewing Trim/Tabs 2 The trim/tabs 2 screen displays the current speed and RPM, as well as the trim position for up to three engines (triple setup maximum) and tab position for up to two tabs (a...
  • Page 136 Section 5 - Propulsion Menu • For a triple engine setup, RPM for the center engine will be displayed in the center speed position. • Displays the trim position for all engines. • Displays the tab positions. • If no tabs are present or are not calibrated, the trim/tabs pop‑up window will only show the trim chart.
  • Page 137 Section 5 - Propulsion Menu Notes: Page 130 90-8M8022154 APRIL 2008...

  • Page 138: Section 6 - Vessel Menu

    Section 6 - Vessel Menu Section 6 - Vessel Menu Table of Contents Using Vessel Screens........132 Checking Tank Status ........ 135 Viewing Performance and Fuel ....133 Viewing Steering Position ......136 Resetting Total Fuel Used ....134 Viewing Generator Data ......137 Checking Vessel Status ......

  • Page 139: Using Vessel Screens

    For example: VesselView will not show tab information for a vessel without tabs. Different engine types (sterndrive versus an outboard) will have different screens. Refer to the tables in Section 3 - VesselView Race Edition Screen Overview for a list of the engine types and their associated screens.

  • Page 140: Viewing Performance And Fuel

    Section 6 - Vessel Menu Viewing Performance and Fuel The performance and fuel screen displays basic operating information for up to four engines. RPM will only be displayed for a maximum of three engines (triple engine setup). 26885 Port engine RPM Starboard engine RPM Vessel speed Estimated range...

  • Page 141: Resetting Total Fuel Used

    Section 6 - Vessel Menu RESETTING TOTAL FUEL USED 1. Press the check button while on this screen to access the Total Fuel Used dialog box. The dialog box will ask you "Would you like to Reset your Fuel Used?". 27265 Fuel used pop‑up window 2.

  • Page 142: Checking Tank Status

    Section 6 - Vessel Menu • The fuel remaining in each tank is displayed in the fuel tank gauge icon. The fuel tank color will change from green to red if the tank is below the critical level. Checking Tank Status The "TANK STATUS"...

  • Page 143: Viewing Steering Position

    Section 6 - Vessel Menu NOTE: Press the check button to display a dialog box showing the tank colors and tank contents. Press the X button to close the dialog box. 27290 Tank status pop‑up window Viewing Steering Position The "STEERING POSITION" screen displays the current steering position in degrees. The default steering position can be adjusted 60 degrees in either direction by changing the offset.

  • Page 144: Viewing Generator Data

    Section 6 - Vessel Menu Viewing Generator Data VesselView displays operating information for your SmartCraft‑enabled Onan or Kohler generator on the "GENERATOR" screen. To start or stop the generator, press the check button to open the Generator dialog box. 12.4...
  • Page 145 Section 6 - Vessel Menu Notes: Page 138 90-8M8022154 APRIL 2008...

  • Page 146: Section 7 - Environment And Navigation Menu

    Section 7 - Environment and Navigation Menu Section 7 - Environment and Navigation Menu Table of Contents Using Environment and Navigation Screens..140 Resetting Trip Log Amounts ....144 Viewing Depth and Water Temperature ..141 Viewing Fuel to Waypoint Data ....144 Setting Depth Alerts ......

  • Page 147: Using Environment And Navigation Screens

    IMPORTANT: The screens listed in the Env/Nav menu is determined by the vessel setup and other components connected to the VesselView Race Edition unit. For example: VesselView will not display Fuel To Waypoint data if the GPS source attached to VesselView does not have chartplotter capabilities.

  • Page 148: Viewing Depth And Water Temperature

    Section 7 - Environment and Navigation Menu Viewing Depth and Water Temperature The "DEPTH" screen displays the depth, speed, and sea temperature; and enables you to set both deep and shallow depth alarms. 27277 Actual depth Horn alarm activated icon Shallow alarm limit Vessel speed Sea temperature...
  • Page 149 Section 7 - Environment and Navigation Menu 1. From the "DEPTH" screen, press the check button. VesselView displays the depth alerts dialog box. 27278 Alarm type Shallow alarm depth Deep alarm depth 2. Use the left or right arrow on the arrow trackpad to select what type of alert to set. The available options are: •...

  • Page 150: Viewing Trip Log Information

    Average speed Engine run time • Trip time is the amount of time the VesselView has been operated since the last reset. • Fuel economy displays the average fuel use since reset. By default, this is calculated in miles per gallon.

  • Page 151: Resetting Trip Log Amounts

    Section 7 - Environment and Navigation Menu RESETTING TRIP LOG AMOUNTS 1. From the "TRIP LOG" screen, press the check button. VesselView displays the reset dialog box. 27281 Trip log reset pop‑up window 2. Press the check button to reset the trip log. Press the X button to cancel.
  • Page 152 Section 7 - Environment and Navigation Menu IMPORTANT: The range comparison is using the distance to waypoint data from the GPS for the next waypoint in the route (shown above the range). This may not be your final destination depending on your route configuration. Be sure to remember that there may be additional legs in the route that are not being used in the range comparison.

  • Page 153: Viewing Navigation Data

    Section 7 - Environment and Navigation Menu Viewing Navigation Data The "NAVIGATION" screen displays information from a connected GPS unit. NAVIGATION 20 20.328 S 157 44.502 W 10.0 DIST WPT HEADING 27333 Latitude location coordinate Speed over ground Longitude location coordinate GPS heading Distance to waypoint •...
  • Page 154 MerCruiser and Outboard Applications - Dual Preparing the Mounting Location....148 Engine ............156 Cutting the Panel.........148 MerCruiser and Outboard Applications - Triple Securing VesselView to the Instrument Panel Engine ............160 ..............149 MerCruiser and Outboard Applications - Quad VesselView Bezel Removal......149 Engine ............

  • Page 155: Cutting The Instrument Panel

    2. Disconnect the batteries powering the gauges or SmartCraft components. 3. Cut out the template located on the last page of the installation instructions. NOTE: Always check the template cutout to the mounting holes on the VesselView before drilling. 4. Use the template to determine the space required for mounting.

  • Page 156: Securing Vesselview To The Instrument Panel

    Section 8 - Installation and Wiring 4. Remove the template and insert the VesselView into the panel to ensure fit. Do not secure to the instrument panel until all harness connections are completed. Securing VesselView to the Instrument Panel 27059...

  • Page 157: Dts Wiring Guidelines

    Harness Installation Guidelines IMPORTANT: A SystemView harness is NOT compatible with VesselView. VesselView must only be installed using the harness contained in the VesselView kit. Page 150 90-8M8022154 APRIL 2008...

  • Page 158: Vesselview Harness Connection For Smartcraft Version 07 And Up

    NOTE: If installing more than one VesselView, use a separate VesselView harness and VesselView harness adapter for each unit. 1. Connect the the VesselView adapter harness to the starboard junction box. Refer to the Wiring Connections for SmartCraft Version 07 for diagrams.

  • Page 159: Wiring Connections For Smartcraft Version 07

    VesselView harness assembly IMPORTANT: SystemView installation required the use of a 10‑pin Vessel Display Connector on the command module harness. DO NOT connect the VesselView, or the VesselView adapter harness, to this Vessel Display Connector. This 10‑pin connector is only found on DTS command module harnesses for the connection of a SystemView or a System Speedometer.
  • Page 160 Section 8 - Installation and Wiring Notes: 90-8M8022154 APRIL 2008 Page 153...

  • Page 161: Mercruiser And Outboard Applications - Single Engine

    Section 8 - Installation and Wiring MerCruiser and Outboard Applications ‑ Single Engine VesselView SmartCraft VesselView SmartCraft 34820 Page 154 90-8M8022154 APRIL 2008...
  • Page 162 VesselView Adapter Harness (Not Required if a Mercury Racing Sterndrive Rigging Kit is installed on vessel.) 1. Refer to Section 1 - VesselView Race Edition Components and Part Numbers for individual kit component part numbers. 90-8M8022154 APRIL 2008 Page 155...

  • Page 163: Mercruiser And Outboard Applications - Dual Engine

    Section 8 - Installation and Wiring MerCruiser and Outboard Applications ‑ Dual Engine VesselView SmartCraft VesselView SmartCraft 34821 Page 156 90-8M8022154 APRIL 2008...
  • Page 164 VesselView will power up using another ignition source (port, starboard inner, or port inner batteries) but will not save any memory settings when the VesselView is turned off. The VesselView will not operate if the starboard ground (pin B) is unavailable at the starboard junction box.
  • Page 165 (Not Required if a Mercury Racing Sterndrive Rigging Kit is installed on vessel.) Multi‑Ignition Harness For Dual‑Engine Applications 84‑889279T02 2. Refer to Section 1 - VesselView Race Edition Components and Part Numbers for individual kit component part numbers. Page 158 90-8M8022154 APRIL 2008...
  • Page 166 Section 8 - Installation and Wiring Notes: 90-8M8022154 APRIL 2008 Page 159...

  • Page 167: Mercruiser And Outboard Applications - Triple Engine

    Section 8 - Installation and Wiring MerCruiser and Outboard Applications ‑ Triple Engine VesselView SmartCraft VesselView SmartCraft 34822 Page 160 90-8M8022154 APRIL 2008...
  • Page 168 VesselView will power up using another ignition source (port, starboard inner, or port inner batteries) but will not save any memory settings when the VesselView is turned off. The VesselView will not operate if the starboard ground (pin B) is unavailable at the starboard junction box.
  • Page 169 (Not Required if a Mercury Racing Sterndrive Rigging Kit is installed on vessel.) Multi‑Ignition Harness For Triple/Quad‑Engine 84‑889279T04 Applications 3. Refer to Section 1 - VesselView Race Edition Components and Part Numbers for individual kit component part numbers. Page 162 90-8M8022154 APRIL 2008...
  • Page 170 Section 8 - Installation and Wiring Notes: 90-8M8022154 APRIL 2008 Page 163...

  • Page 171: Mercruiser And Outboard Applications - Quad Engine

    Section 8 - Installation and Wiring MerCruiser and Outboard Applications ‑ Quad Engine VesselView SmartCraft VesselView SmartCraft 34823 Page 164 90-8M8022154 APRIL 2008...
  • Page 172 VesselView will power up using another ignition source (port, starboard inner, or port inner batteries) but will not save any memory settings when the VesselView is turned off. The VesselView will not operate if the starboard ground (pin B) is unavailable at the starboard junction box.
  • Page 173 (Not Required if a Mercury Racing Sterndrive Rigging Kit is installed on vessel.) Multi‑Ignition Harness For Triple/Quad‑Engine 84‑889279T04 Applications 4. Refer to Section 1 - VesselView Race Edition Components and Part Numbers for individual kit component part numbers. Page 166 90-8M8022154 APRIL 2008...

  • Page 174: Mercury Racing Sterndrive Applications

    IMPORTANT: Applications using the Mercury Racing Sterndrive hull harness do not require the multi‑ignition harness connectors to be connected. The power source that allows the VesselView to turn on when either key switch is turned on comes through the 10‑pin connector on the hull harness.

  • Page 175: Installing The Ambient Air Temperature Sensor

    4. Thread the sensor into the mounting adapter. 5. Connect the temperature sensor to the connector on the VesselView harness. 5. Refer to Section 1 - VesselView Race Edition Components and Part Numbers for individual kit component part numbers. Page 168...

  • Page 176: Installing The Nmea 0183 Adapter Harness

    VesselView harness 1. Connect the 5‑pin NMEA connector on the adapter harness to the 5‑pin NMEA 0183 connector on the VesselView harness as shown in the diagram. 2. Connect your GPS unit or other NMEA‑compatible device to the adapter harness.

  • Page 177: Nmea 0183 Connector

    Section 8 - Installation and Wiring NMEA 0183 Connector NOTE: The connector image shown is the wire side of the plug. 24202 NMEA out (+) NMEA out (–) NMEA in (+) NMEA in (–) DC ground Page 170 90-8M8022154 APRIL 2008...
  • Page 178 Section 8 - Installation and Wiring Notes: 90-8M8022154 APRIL 2008 Page 171...

  • Page 179: Calibration Logs

    Section 8 - Installation and Wiring Calibration Logs Tank Calibration Reference Sample Log Volume In Tank Measurable Sensor Reading Sensor Reading Sensor Reading Units = Capacity Position 1 Position 2 Positition 3 16 (refer to step 6) Empty tank = 0.0 gallons enter 3.0% in the calibration point for Empty tank 14.0 24.0...
  • Page 180 These 42 gallons, if used in the calculations, would cause significant errors in the calculated volume remaining. In this example the tank capacity entered into VesselView should be approximately 158 gallons to ensure the most accurate reading. If you left the tank capacity at 200 gallons and you properly calibrated full to be 93.0%, when the sender...

  • Page 181: Tank Calibration Reference Log

    Section 8 - Installation and Wiring Tank Calibration Reference Log Tank Calibration Reference Log Volume In Tank Measurable Sensor Reading Sensor Reading Sensor Reading Units = Capacity Position 1 Position 2 Position 3 Page 174 90-8M8022154 APRIL 2008...

  • Page 182: Manual Tank Calibration Screen Log

    Space is provided for up to four tanks. 34961 VesselView Template Cutout NOTE: Due to printing variances, the size of the template may vary. Measure for accuracy before drilling any holes. Refer to Section 8 - Cutting the Instrument Panel for installation instructions.
  • Page 183 Section 8 - Installation and Wiring Notes: Page 176 90-8M8022154 APRIL 2008...
  • Page 184 Section 8 - Installation and Wiring 132.5 mm (5.2 in.) 112.0 mm (4.4 in.) 114.0 mm 25960 (4.5 in.) 90-8M8022154 APRIL 2008 Page 177...
  • Page 185 Section 8 - Installation and Wiring Notes: Page 178 90-8M8022154 APRIL 2008...

  • Page 186: Section 9 - Glossary Of Terms And Service Contact Information

    Section 9 - Glossary of Terms and Service Contact Information Section 9 - Glossary of Terms and Service Contact Information Table of Contents VesselView Systems Terminology....180 Mercury Marine Service Offices......182 90-8M8022154 APRIL 2008 Page 179...

  • Page 187: Vesselview Systems Terminology

    Difference between fuel pressure and manifold absolute pressure. DELTA PRESSURE TPI% / TPS%; On DTS models this is ERC demand %. DEMAND % Number to identify a VesselView at a station. DEVICE ID Distance to waypoint DIST WPT Digital Throttle and Shift...
  • Page 188 Section 9 - Glossary of Terms and Service Contact Information Term Definition Number to identify the station the VesselView is being installed on. HELM ID Empirical gallons Kilometers Kilometers per hour Unit of measurement for speed. KNOTS Kilopascal Kilometers per liter...

  • Page 189: Mercury Marine Service Offices

    Term Definition Trim sender data TRIM Memory device used to save and load VesselView configuration data. USB MEMORY STICK Wide Open Throttle Mercury Marine Service Offices For assistance, call, fax, or write. Please include your daytime telephone number with mail and fax correspondence.
  • Page 190 ©2008, Mercury Marine. All rights reserved. 90-8M8022154 APRIL 2008...
