Summary of Contents for Ruhle MGR 400
- Page 1 Lebensmitteltechnik Translation of the original instructions - Miknetum Type: MGR 400 Rühle GmbH, Beim Signauer Schachen 10, D-79865 Grafenhausen Tel.: +49 7748-523-11, Fax: +49 7748-523-8511 www.original-ruehle.de...
-
Page 2: Table Of Contents
Miknetum MGR 400 Table of Contents Safety Instructions ................3 Safety instructions ..............3 Remaining risk of accidents ..........6 Intended Use ................6 Installation instructions ..............7 Machine transport and setup ..........7 Workplace description ............. 8 Connecting the machine ............8 Operating instructions .............. -
Page 3: Safety Instructions
Miknetum MGR 400 1 Safety Instructions !!! Observe the safety instructions during the installation, operation, cleaning and maintenance of the Rühle Miknetum! Hazard potentially causing irreversible injuries if disregarded. Warning, potentially causing serious injuries if disregarded. Note Work on electrical equipment of the machine may only... - Page 4 Miknetum MGR 400 decommissioning, care / maintenance as well as dismantling / disposal! c) Make sure that the qualified workers have completely read and understood the respective work instructions according to section 1.1b! d) Proper functioning of the protective devices must be checked at least once a year by a Rühle service technician!
- Page 5 Miknetum MGR 400 a) Visual check for changes or damages on all machine sides and accessible machine parts, e.g. steel cables and chain. The machine must be shut down in the event of any damages or changes! b) Check the safety switches as follows: –...
-
Page 6: Remaining Risk Of Accidents
Miknetum MGR 400 1.2 Remaining risk of accidents !!! All life cycles phases Error messages of the operating system must be heeded! Non-compliance is strictly prohibited! There is a risk of crushing between motor protection and machine base cover. Staying in the swivel range of the... -
Page 7: Installation Instructions
Miknetum MGR 400 Claims of any type because of damages due to non- intended use are ruled out! Misuse: Any use other than the one listed above is strictly prohibited and is considered misuse! Operating the machine in explosion hazard areas is prohibited! ... -
Page 8: Workplace Description
Miknetum MGR 400 Make sure the machine is stable! Ensure that the max. filling quantity of 400 kg per standard trolley is not exceeded! 2.2 Workplace description Lid swivel range Swivel range of Swivel range of standard trolley standard trolley... -
Page 9: Operating Instructions
Miknetum MGR 400 In such a case, an electrician must change the direction of rotation inside the mains plug. The power supply to the machine must be fuse- protected with 32 A secured with an AC/DC sensitive ground-fault circuit interrupter (type B). - Page 10 Miknetum MGR 400 Installation and removal of protective gearbox cover Transport of machine and machine parts Maintenance work inside the drum Depending on the user programs, temperatures down to - 10 ℃ may be generated in the drum. Take the corresponding precautions.
-
Page 11: Cleaning Instructions
Miknetum MGR 400 vacuum). If this is the case, the gasket has been mounted correctly. Otherwise check the gasket. The lid cannot be opened when there is a vacuum in the machine or if it has not yet been fully aerated. - Page 12 Miknetum MGR 400 Cleaning products and disinfectants approved for the food product area and suitable against contamination (e.g. protein, limescale, ...) must be used! The cleaning agents and disinfectants must be prepared to a solution as described in the product data sheet of the manufacturer! ...
-
Page 13: Cleaning Agents And Disinfectants
Miknetum MGR 400 4.2 Cleaning agents and disinfectants The following cleaning agents and disinfectants must be used: Cleaning agents: Alkaline cleaning: P3 – topax 12, P3 – topax 19, P3 – topax 66 Acidic cleaning: P3 – topax 56 Disinfectants: P3 –... -
Page 14: Service: Care, Maintenance, Repair
Miknetum MGR 400 5 Service: Care, maintenance, repair Any work related in any way with service may be carried out only by Rühle service technicians and by persons authorised by Rühle in writing. In this regard, a distinction is made between regular care and maintenance and repair. -
Page 15: Regular Maintenance
Miknetum MGR 400 Care schedule: a) Disassemble the machine according to the cleaning instructions. Check for any parts moving with difficulty, material abrasion or other signs of wear and tear. b) Check hygienic condition and function of drum lid seal! -
Page 16: Repair And Spare Parts
Miknetum MGR 400 h) Check radial shaft seals for leak tightness; replace otherwise! Read the error memory (frequency converter)! 5.3 Repair and spare parts As a damaged part on a machine is usually damaged due to causes unrelated to the part, always carry out a fault diagnosis. -
Page 17: Technical Documentation
Miknetum MGR 400 7 Technical documentation 7.1 Technical data Connection voltage: 400 V 50/60 Hz 3-phase AC / N / PE Power consumption: 8.9 kW Full-load current: 17.5 A Back-up fuse max.: 32 A Protection class: IP54 Ambient temperature: +2 to 40 °C... -
Page 18: Electrical Circuit Diagram
Miknetum MGR 400 7.2 Electrical circuit diagram The electrical circuit diagram of your machine is located in the electrical control cabinet and must be supplied when reselling the machine! -
Page 19: Ec Declaration Of Conformity According To Directive 2006/42/Ec
Miknetum MGR 400 8 EC Declaration of Conformity according to Directive 2006/42/EC The manufacturer herewith declares that the following product Name: Rühle GmbH Type: MGR 400 Legal form: Lebensmitteltechnik Address: Beim Signauer Schachen 10 Designation: Miknetum D – 79865 Grafenhausen From series no.:...
