Installation and User Instructions
Infrared Thermal Thermometer
Device Model Tytron / Series C-5000
Classification Name: Powered direct-contact temperature measurement device
Common/Usual Name: Computer Aided Paraspinal Thermographic Scanning System
Classification: FDA - Class II (USA)
Model:
TyTron
degree C
Series:
C-5000
Odometer +/- 0.25 CM
Useful Life:
7 years mfg. listing.
Product Description/Intended Use:
The C-5000 is a paraspinal infrared temperature recorder (K974208) indicated for use in
detecting, measuring, recording, and graphing the skin surface temperature on both sides
of the spine of adults and children by chiropractors. It is to be used before and after
therapy is rendered as part of monitoring the patients response to care, similar to a
common thermometer.
The TyTron series of scanners (C-5000 USB replaces the earlier serial connected
instruments) - differed only in the communication mode to the host computer. They
directly enter the patients thermographic information into a computer. A built-in distance
measuring encoder removes any risk of the operator's inability to control a uniform speed
at which the back scan is performed. The scan is initiated at S1 for a full spine graph and
C1 for a cervical graph. The end point of the scan is established by the probe tips
"bumping" into the occipital shelf. All graphs are than precisely aligned from that end
point down, yielding an accurate, repeatable rendering of the thermal "picture" at that
point in time of the patient's paraspinal area.
The system is capable of recording and graphing thermal differentials (right to left
thermal asymmetries) as displayed on the computer's monitor. It also records actual skin
temperature on the right and left sides of the spine.
The sensors are housed in a solid block of aluminum in order to maintain peak efficiency
and thermal stability throughout each scan. The focusing barrels are isolated from the
patient by their plastic contoured tips. Accurate temperature readings can be taken up to
1 inch away from the skin's surface.
C-5000 Owner's Manual
OwnC-C-3000 Manual
CE - Class I – Measuring (Europe)
Specifications: Displayed Temperatures Accuracy+/- 1
Differential 0.1 degree C resolution Distance
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tytron C-5000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Titronics Tytron C-5000 Series

  • Page 1 C-5000 Owner’s Manual OwnC-C-3000 Manual Installation and User Instructions Infrared Thermal Thermometer Device Model Tytron / Series C-5000 Classification Name: Powered direct-contact temperature measurement device Common/Usual Name: Computer Aided Paraspinal Thermographic Scanning System Classification: FDA - Class II (USA) CE - Class I – Measuring (Europe) Model: TyTron Specifications: Displayed Temperatures Accuracy+/- 1...
  • Page 2 Neither Titronics R & D nor any of its affiliates or subsidiaries shall be responsible or liable for misuse of the information that is contained herein. If you have any suggestions for improvements or amendments or have found errors in this publication, please notify us.
  • Page 3 Failure to observe this information can result in injury or equipment damage. Titronics R & D has made every effort to prevent that the labelling, instructions for use, making available, putting into service and advertising of devices uses text, names, trademarks, pictures and figurative or other signs that may mislead the user or the patient with regard to the device's intended purpose, safety and performance.
  • Page 4 The manual is online, customers may call and request previous versions, however in almost all cases the customers take advantage of our automatic software Titronics Customers upgrades allowing the current manual and our tech department to be very efficient and effective in handling questions. Titronics distributors and Agents...

  • Page 5: Table Of Contents

    C-5000 Owner’s Manual OwnC-C-3000 Manual Contents ..PREFACE ......................11 ..Description of the User ..................11 ..Conventions Used in This Manual .................11 ..Explanation of Safety Warnings................11 ..Retaining Instructions ....................12 Obtaining Documentation and Information ............12 1.5.1 Internet ......................12 1.5.2 Ordering Documentation ................12 1.5.3 Other languages ....................12 1.5.4 Documentation Feedback ................13 1.5.5 Support and service ..................13...
  • Page 6 C-5000 Owner’s Manual OwnC-C-3000 Manual ..Patient Management ....................28 3.7.1 Entering a New Patient ...................28 3.7.2 Editing Patient Information ................29 ..3.7.3 Load Patient File ....................33 ..Keyboard Function Keys F1 – F4 ................34 Keyboard Function Keys F5 – F12 ................35 3.10 Scanning .........................38 3.10.1 Performing a Scan ..................39...
  • Page 7 C-5000 Owner’s Manual OwnC-C-3000 Manual 4.2.7 Safety information when using the device in combination with other devices: 4.2.8 Maintenance safety information: ..............58 ..4.2.9 Safe Disposal: ....................58 Graphical Symbols ....................59 ..4.3.1 Explanation of graphical sysmbols ..............59 ..Potential health consequences: ................59 ..
  • Page 8 C-5000 Owner’s Manual OwnC-C-3000 Manual ..Verification of sterilization: ...................69 How to Use the Product ..................69 6.7.1 Treatment of vulnerable people ..............69 6.7.2 Operational environment ................69 6.7.3 Using the device in combination with other devices ........69 6.7.4 The C-5000 does not emit any radiation and complies with emitting hazardous radiation: ....................70 6.7.5 Manual operation....................71 6.7.6 Measuring function ..................71...
  • Page 9 10.12 TYTRON DATA BASE BACKUP PROCEDURES ............96 10.13 I just bought a scanner from another doctor; do I need to contact Titronics? .97 10.14 What keyboard functions do I use in the software to get ??? , view the chart in section 2.11 ........................97...
  • Page 10 APPENDIX I – SUPPLIED ACCESSORIES, CONSUMABLES AND SPARE PARTS 100 11.1 Supplied accessories - ..................100 11.2 Consumables - may be ordered from Titronics Website ........101 11.3 Replacement parts - order from Factory (cathy@titronics.com) ......101 CLINICAL EVALUATION ...................104 RELATED DOCUMENTATION ................106 SAFETY SIGNS ....................107...

  • Page 11: Preface

    Type 2 user - If multiple computers and a server for the data base are involved, it is customary for an office IT person to perform that part of the setup or an internet connection can be made with the Titronics tech team using www.logmein123.com for remote access.

  • Page 12: Retaining Instructions

    (please cover shipping outside of the USA). Documentation, user instructions and technical information can be ordered by calling Titronics R & D at [319 545 7377 EXT 2 or EXT 3]. Documentation can also be downloaded from www.titronics.com. 1.5.3 Other languages This is the English user manual.

  • Page 13: Documentation Feedback

    C-5000 Owner’s Manual OwnC-C-3000 Manual 1.5.4 Documentation Feedback If you are reading Titronics R & D product documentation on the internet, any comments can be submitted on the support website. Comments can also be sent to [ roger@titronics.com and dochoskins@titronics.com ].

  • Page 14: Description Of The Product

    C-5000 Owner’s Manual OwnC-C-3000 Manual 2 Description of the product 2.1 Device Description The TyTron C-5000 is a handheld paraspinal thermographic scanning system. It consists of two focused infrared sensors designed to straddle the spinal column to detect temperatures. With the aid of a computer assisted program, the system is capable of recording and graphing thermal differentials (right to left thermal asymmetries) on a horizontal scale.

  • Page 15: Technical Data

    Conformity can be found in the appendix. The Product is in conformity with the following relevant product safety standards. 2.8 Summary of Safety and Clinical Performance • C-5000 mfg. by Titronics Research & Development UDI-ID 00860447001714 • Device measures skin temperature – there is no contraindications for use on the general public.

  • Page 16: Tytron C-5000 Operating Instructions

    C-5000 Owner’s Manual OwnC-C-3000 Manual 3 Tytron C-5000 Operating Instructions ELEMENT A - Scanner ELEMENT B – C-3000 Software Program The C-5000 has one control – a “trigger” switch that alerts the monitoring computer that a thermal scan is being performed. The “trigger” is depressed during the scan from the lower back to the occiput.

  • Page 17: System Components

    • Perform periodic maintenance on the Tytron. The scanner barrels may accumulate dust and dirt particles over time. For small amounts of debris in the barrels Titronics recommends using canned air (available at most electronics stores). Insert the spray straw approximately 1” into the barrel. Spray for three seconds.

  • Page 18: Tytron C-5000 Fast Setup

    Accept all the defaults. Ignore these warnings as shown below. If they come up – choose Yes or OK. After Titronics Instant Support is loaded you may uncheck the Launch option if you don’t want to connect immediately (you should not need to unless your C-5000 scanner doesn’t connect automatically over the internet).
  • Page 19 C-5000 Owner’s Manual OwnC-C-3000 Manual 134251378 Click OK, go back into Setup > Scanner tab, In the USB Scanner 1 box it should say: (calibration numbers should agree with enclosed calibration report numbers) If Trigger Pulled appears when the trigger is pulled proceed to next step. If you are not seeing Trigger Pulled refer to the instructions for Loading Drivers.

  • Page 20: Using The Tytron Software

    C-5000 Owner’s Manual OwnC-C-3000 Manual Click OK, click in the upper right and perform a scan under your chin. If a scan screen comes up and you are able to perform a graph – you have successfully installed your software and C-5000 scanner! 3.3 Using the Tytron Software The Tytron Software uses several keyboard functions designed to let you work as efficiently as possible.

  • Page 21: The Home Screen

    C-5000 Owner’s Manual OwnC-C-3000 Manual M = NCM mode. (home screen) X = Exports the screen as a jpeg to a folder called images in the C-3000 folder. (at any screen showing a scan, or history) bar graph, X = Export the Patient. (home screen) Q = Quick Scan a patient without saving the scan.

  • Page 22: The Setup Screen

    Unregistered Copy mode and you will not be able to change any of the information in your three lines, nor will you be able to take a scan. If this happens, please contact Titronics R&D at 1-319-545 7377. 3.6.1 The Main Tab Screen...
  • Page 23 C-5000 Owner’s Manual OwnC-C-3000 Manual Password, Default Search Method, Show File Number, Default History View, Recoup Suites, Saving Scans and more. The Check for Updates button will connect over the internet to see if a new version of the software is available. If the AutoCheck box is checked it will check for an update when the program starts.

  • Page 24: The Scans Tabs Screen

    You can also select between 2 alert tones. The Saving Scans section determines how the Tytron software handles saving scans. Titronics recommends to always use one of the Auto-Save options. • Auto-Save with no comment saves all scans without prompting for comments.
  • Page 25 C-5000 Owner’s Manual OwnC-C-3000 Manual The Vertical Delta-T section displays, at the top of the graph, the vertical direct temperature differential for each side calculated as the temperature difference between the lower and upper 2 cm of the graph. An ideal graph would show a gradual increase in temperature from the sacrum to the occiput.

  • Page 26: The Printing Tab Screen

    C-5000 Owner’s Manual OwnC-C-3000 Manual Atlas integration allows the software to be used with Atlas Chiropractic Software. Contact Atlas for information about configuring their software to integrate. Delta DT Hybrid and DT Average Line options allow the display of scans with Delta DT information shown.

  • Page 27: The Scanner Tab Screen

    3.6.4 The Scanner Tab Screen The Calibration Settings should not be changed at any time unless instructed directly by Titronics Technical Support. These values are set at the time of software installation and are unique to each scanner. The Wireless Settings area is available for wireless scanner use onl For older Serial connected Tytron scanner: The List Ports button shows all ports available.

  • Page 28: Patient Management

    C-5000 Owner’s Manual OwnC-C-3000 Manual finding the Tytron. This option is selected during installation. However, if the Tytron is not scanning, it may be registering on a different virtual port than it originally did when you last used it. To fix this problem, go to the device manager and find the port that the scanner is registering under, then make sure it is the same port as in the software.

  • Page 29: Editing Patient Information

    C-5000 Owner’s Manual OwnC-C-3000 Manual To enter a new patient, click the New Patient button or hit the N key at the home screen. The patient’s first and last name must be entered. All other information is optional. To display a patient’s Treatment Frequency and Adjustment Listings, fill in those fields in the Patient Settings section.
  • Page 30 C-5000 Owner’s Manual OwnC-C-3000 Manual The Frequency (how often the doctor wants to see the patient) and the patient’s Listing will appear on the home screen. Symptoms, Diagnosis, Evaluation visits, Doctor, and Technician will appear on printout reports. The Select Back Image button is used to load images of the patient’s actual back that you have previously taken.
  • Page 31 C-5000 Owner’s Manual OwnC-C-3000 Manual 2. On the next screen that appears pull on the corner of the frame around the spine that is super imposed over the patient’s picture to lie on top of the patient’s actual spine. Note that the sacrum and the coccyx bones can be off of the picture if need 3.
  • Page 32 C-5000 Owner’s Manual OwnC-C-3000 Manual 1. Locate the image in the box that came up and click Open. 2. On the next screen that appears pull on the corner of the frame around the spine that is super imposed over the patient’s X-Ray to lie on top of the patient’s actual spine.

  • Page 33: Load Patient File

    C-5000 Owner’s Manual OwnC-C-3000 Manual 3.7.3 Load Patient File To load a patient file from the Home Screen, click the Load Patient button or hit the L key. A Quick Search pop up appears. Click Search, this displays a list of all patients along with a flashing cursor in the patient’s last name field (or in their file number field depending on default settings).

  • Page 34: Keyboard Function Keys F1 - F4

    C-5000 Owner’s Manual OwnC-C-3000 Manual 3.8 Keyboard Function Keys F1 – F4 These function keys are used to review previous scans. F1 Pre: Displays the last pre-adjustment scan performed. F2 Pat + Post: This function serves two purposes. First, a patient’s pattern is displayed with the last post-adjustment scan overlaid, allowing the patient to see results of their last adjustment.

  • Page 35: Keyboard Function Keys F5 - F12

    C-5000 Owner’s Manual OwnC-C-3000 Manual the scan or hitting the Enter key. 2 Any 2 Scans: Displays an overlay of 2 selected scans. Select the scans after hitting this button by clicking on the desired scans or pressing the corresponding letters.
  • Page 36 C-5000 Owner’s Manual OwnC-C-3000 Manual corner along with the last 9 pre-adjustment scans when a post adjustment scan is performed. This allows the ability to evaluate if the pre-adjustment scans match the pattern or if over-adjustments are performed. F9 Pre/Post: Quickly toggles the last scan taken between a Pre and a Post Adjustment. F10 Comment: Displays the comment field for the last scan taken.
  • Page 37 C-5000 Owner’s Manual OwnC-C-3000 Manual Scan: Hitting the S key allows for a simple scan to be taken without a pre-adjustment or pattern overlay. Multiple scans may be performed in this manner, however only the last scan taken will be saved in the patient’s file upon exit. To save multiple scans press the Enter key after taking each scan.

  • Page 38: Scanning

    • For C-5000 units, ensure the computer is powered on (and doesn’t go into hibernate mode after being left idle). If the computer is turned off and on frequently Titronics recommends purchasing a powered USB hub (available at most electronics stores) to maintain power to the scanner.

  • Page 39: Performing A Scan

    C-5000 Owner’s Manual OwnC-C-3000 Manual 3.10.1 Performing a Scan Once a patient is selected the scanning process itself is fully automated. 1. Pick up the scanner by its handle. Do not touch any part of the scanner head. (This is the area above the handle that is separated by a white or black thermal shield).
  • Page 40 C-5000 Owner’s Manual OwnC-C-3000 Manual 3.10.1.1 Segmental Scanning The segmental mode allows performing a lumbar and lower upper neck, while omitting the thoracic region (to avoid clothing). Simply lift the back covering to expose the lumbar and lower the back covering to expose the cervical. To do this, click Scan on the home screen to display a blank scan screen.
  • Page 41 C-5000 Owner’s Manual OwnC-C-3000 Manual 6. Scan upward towards the head with an even cadence while maintaining the left probe tip just off the skin. When the hairline is encountered, gently press the probe down onto the skin to displace the hair. Stop the scan when the occiput is encountered and release the trigger before lifting the scanner off the spine.

  • Page 42: Scan Display Screens

    C-5000 Owner’s Manual OwnC-C-3000 Manual 3.11 Scan Display Screens These 4 scan display screens are used to view the patient’s thermal scans: 3.11.1 Line Graph Screen This is the most accurate thermal interpretation display. The center line represents the Delta-T (or difference) in temperature from each side of the spine. Any lateral deviation of this line is toward the hotter side of the spine.

  • Page 43: Spine Bargraph Screen

    C-5000 Owner’s Manual OwnC-C-3000 Manual 3.11.2 Spine Bargraph Screen At the line graph screen, hit the B key to toggle between the Line graph screen and the Delta-T spine bar graph screen. This screen simplifies the data in a way that makes it easy for patients to understand.

  • Page 44: Ncm Screen

    C-5000 Owner’s Manual OwnC-C-3000 Manual The following functions manage how the scans display on the screen: 1. The Arrow buttons (↑, ↓,←,→) move between scans. The selected scan is highlighted with a border. 2. To view a single scan in detail, double click the scan with the mouse or highlight the scan using the arrow keys and hit the Enter key.
  • Page 45 C-5000 Owner’s Manual OwnC-C-3000 Manual either the meter or digital displays. If you observe the lower portion of the NCM screen: (after loading a test patient) 33.34 C (left DT) 25.27 C Ambient 33.22 (right DT) Please note the three circled temperatures when you pull the trigger and AIM at the floor (AMB should be around 23 C as well as both Left and Right vertical thermometers.

  • Page 46: Mastoid Fossa / Chronometer Readings

    C-5000 Owner’s Manual OwnC-C-3000 Manual 3.12 Mastoid Fossa / Chronometer Readings Mastoid Fossa or Chronometer readings are always made using the RIGHT SIDE PROBE ONLY. Fossa readings are taken after a spinal scan. 1. After a spinal scan is performed, hit the F key, or click the Fossa button in the upper right of the screen.

  • Page 47: Printing Reports

    C-5000 Owner’s Manual OwnC-C-3000 Manual 3.13 Printing Reports Hitting the P key presents you with a pop-up menu for you to select the type of report you want to print: Lines: This report is a simple printout of the line graphs on the screen Lines History: This report will produce a simple printout up to 10-line graphs as presented on the screen.

  • Page 48: The Notes Screen

    C-5000 Owner’s Manual OwnC-C-3000 Manual 3.14 The Notes Screen: Notes: The Notes feature allows you to create, edit, and manage notes of any length. You may also attach files to the notes (x-rays, photos, documents, etc.) Notes are stored in the database linked to the individual patient files. The “Z” key opens the notes screen from most areas of the program.

  • Page 49: Database Backup

    “locks up”. 3.16 Database Backup The database backup popup option opens when you close the software. Titronics recommends backing up the software to a removable flash drive at least once a week.

  • Page 50: Database Restoration

    C-5000 Owner’s Manual OwnC-C-3000 Manual 3.17 Database Restoration If the computer malfunctions, causing damage to the patient database, the Database Restoration process will restore the database back to the point of the last backup. The Database Restoration process only works if the patient database has been previously backed up! To perform a restoration, follow these steps: 1.

  • Page 51: Resolving Recoup Suite Issues

    C-5000 Owner’s Manual OwnC-C-3000 Manual protocol. The patient needs this minimum acclimation period in order to eliminate any artifacts left over from the adjustment procedure. Please note that if any type of physical therapy is performed, it is after the post-adjustment scan is taken. To activate the Recoup Suite function, click the Setup button at the home screen and select the Main tab.

  • Page 52: Export / Import

    Export CVS – allows you to save patient list to a text file to be able to be put into a spread sheet Export ROM – allows you to sync patient DB to Titronics ROM DB Export All – allows you to save all patients to a folder Export –...

  • Page 53: Network Setup Instructions

    C-5000 Owner’s Manual OwnC-C-3000 Manual 3.20 Network Setup Instructions 1. Install the Tytron Software on each computer to be networked. 2. Select a computer to be the server (main computer). Perform the following tasks: • Open My Computer, then open Drive C. Right click on the C3000 folder and select Properties.
  • Page 54 C-5000 Owner’s Manual OwnC-C-3000 Manual 3. On the client computers, run the Tytron Program and click the Setup button. At the Main tab, change the Data Folder to reflect the location specified as the server. (In this example, \\ServerName\C3000\DB). Note that the Control Folder will automatically fill in as you type the path into the Data Folder.

  • Page 55: Periodic Maintenance

    15 minutes. Heavy Cleaning • For large amounts of debris in the barrels, Titronics recommends using a cotton swab lightly moistened with water. Insert the moistened cotton swab approximately 1” into the barrel tip. Do not touch the lenses! Trap debris along the wall of the barrel and pull debris out.

  • Page 56: Safety Instructions

    C-5000 Owner’s Manual OwnC-C-3000 Manual 4 Safety Instructions 4.1 Safety Information for Devices Intended for Single Use Not Applicable. The Tytron scanner is not a single use device. 4.2 How to Use the Product Safely There are no contra-indications to recording a patient’s skin temperatures with an infrared thermometer.

  • Page 57: Instrument Protection

    C-5000 Owner’s Manual OwnC-C-3000 Manual have some form of a disinfectant wipe such as the Sani-Cloth available. A quick “wipe” of the barrels and wheels after each patient would easily allow 2-minute contact time against enveloped/ non-enveloped viruses, bacteria, TB, fungi, multi-drug resistant organisms and bloodborne pathogens to be destroyed.

  • Page 58: Personal Protective Equipment

    C-5000 Owner’s Manual OwnC-C-3000 Manual Right actual temperature readings and +/- 2 degrees C. for the differential or Delta display. Any dis-continuity in the trace would indicate a reading or transmission error and is an obvious alert to the person performing the scan. Patient Skin Contamination: There are two materials that touch the patient: The distance measuring wheels are an elastomeric “rubber”...

  • Page 59: Graphical Symbols

    C-5000 Owner’s Manual OwnC-C-3000 Manual 4.3 Graphical Symbols 4.3.1 Explanation of graphical sysmbols Symbol Meaning Degrees Centigrade Degrees C. (°C) Degrees F. (°F) Degrees Fahrenheit cm, mm Centimeters, Millimeters Committee of Europe 4.4 Potential health consequences: There are no potential health consequences in the use of the instrument as all exposed surfaces have passes all standards for skin contact.

  • Page 60: Packaging

    C-5000 Owner’s Manual OwnC-C-3000 Manual 5 Packaging 5.1 Transport and Store the Product Keeping the storage case and instrument from coming in contact with any corrosive liquids is critical (saltwater for example). Conductive liquids could reach the circuit boards and damage them. Short periods of contact (less than 2 hours) to saltwater may be taken care of by flushing the scanner with warm clean water.

  • Page 61: Lifting, Handing And Transporting The Product

    C-5000 Owner’s Manual OwnC-C-3000 Manual 5.1.2 Lifting, handing and transporting the product To lift the product safely: At less than 5 KG, the instrument and case are within safe limits for lifting by most adults. To handle the product safely: Handle with care as you would with any fragile instrument (camera, glass ware, etc.) To transport the product safely: Package the instrument as shown on the previous page, place the instrument case in a...

  • Page 62: Securing The Product Against Shocks

    C-5000 Owner’s Manual OwnC-C-3000 Manual position minimizes any air borne dust particles from entering the open ends of the barrels and “blocking” the IR emissions from reaching the sensors. If left over night in an office that has automatic temperature control, allow sufficient time before use for the instrument to return to it’s operating temperature range (21 c to 25C ) before use if the room is being warmed or cooled after opening the office.

  • Page 63: Verification Of The Product

    C-5000 Owner’s Manual OwnC-C-3000 Manual 5.2.4 Verification of the product The Tytron scanner is indicated for use in detecting, measuring, recording, and graphing the skin temperature on both sides of the spine of adults and children by chiropractors and other health care professionals. It is to be used before and after therapy is rendered as part of monitoring the patient’s response to care, similar to a common thermometer.

  • Page 64: Installation Of The Software

    C. (three of the white lines) and you have followed the cleaning procedure outlined in the www.titronics.com video and below, it is an appropriate time to allow us to replace the lenses and perform an “in house”...
  • Page 65 C-5000 Owner’s Manual OwnC-C-3000 Manual LEFT DT DELTA T RIGHT DT As can be seen in this example a scan made with a calibrated instrument is centered (GREEN) compared to a scan done with “dust” in the left barrel (YELLOW) – reducing the LEFT DT temperature and there by shifting the center DELTA T line graph to the...

  • Page 66: Sterilization Of The Scanner Is Not Required Of The Product Before Use

    C-5000 Owner’s Manual OwnC-C-3000 Manual Left Barrel after dry Q-Tip cleaning Right Barrel after dry Q-tip cleaning A Closer Look at the Lenses at the base of the Barrels Left Lens as received Right Lens as received Left Lens after air blast Right Lens after air blast The Dust-Off air cans come with a plastic “nozzle”...

  • Page 67: Operation/Use

    The rubber tires can be replaced should they become worn or difficult to clean well. There are spares in the “Repair Kit” , more can be ordered online (www.titronics.com). See section 5.3.2 for calibration checks. When the Delta-T (center) line graph remains more than 1 degree off to the left or right of center after following the cleaning procedures the scanner should be returned to Titronics R&D or a qualified repair /...

  • Page 68: Identification And Replacement Of Consumable Components

    The rubber tires can be replaced should they become worn or difficult to clean well. There are spares in the “Repair Kit” and more can be ordered online at www.titronics.com. 6.4 Verification of correct calibration of the device – follow procedure...

  • Page 69: To Calibrate The Product

    C-5000 Owner’s Manual OwnC-C-3000 Manual If the center graph isn’t “centered” follow the cleaning instructions in section 2.3.2. If this doesn’t bring balance back to the average center graph scans, a factory calibration will be required. The Fresnel lenses will be replaced, and the instrument will be brought to a stable temperature in a temperature controlled room and calibrated against...

  • Page 70: The C-5000 Does Not Emit Any Radiation And Complies With Emitting Hazardous Radiation

    C-5000 Owner’s Manual OwnC-C-3000 Manual 6.7.4 The C-5000 does not emit any radiation and complies with emitting hazardous radiation:...

  • Page 71: Manual Operation

    C-5000 Owner’s Manual OwnC-C-3000 Manual 6.7.5 Manual operation The C-5000 must be used with a computer. The only control on the instrument is the “Trigger” which, when depressed connects the scanner to the computer as long as it is depressed. All other operations are controlled from the computer keyboard or touch screen.

  • Page 72: In Emergency And Exceptional Situations

    C-5000 Owner’s Manual OwnC-C-3000 Manual 6.8 In Emergency and Exceptional Situations The user or patient may report to the manufacturer or competent authority of the member state any serious incident that may occur in relationship to the use of the C-5000. If in the EU, report is to be made to the member state in which the user/or patient is established.

  • Page 73: 7 Maintenance

    Q-tip and warm soapy water. If the C-5000 is dropped and damaged, it must be checked, re-conditioned, and calibrated by the manufacturer - Titronics R&D – 400 Stephans St. Unit D, Tiffin, Iowa 52340 – USA. 7.1.1 Disinfection of the device The use of a germicidal disposable wipe is an excellent tool to minimize the risk of patient to patient or doctor to patient contamination.

  • Page 74: Product Maintenance By Non-Skilled Persons

    If the operator that is performing the thermal scans is unable to create a graph, they are to contact the office doctor or office manager. A call or e-mail to Titronics R&D may be indicated if the technical person in the office is unable to resolve the issue.

  • Page 75: Troubleshooting And Repair

    C-5000 Owner’s Manual OwnC-C-3000 Manual 8 TROUBLESHOOTING AND REPAIR When following the barrel cleaning procedure outlined in 5.3.2, wear eye protection as debris exiting the front of the barrel may be blown toward your face. If there is a problem with the graphs re-check the calibration and cleaning procedure in 5.3.2.

  • Page 76: Troubleshooting And Repair By Skilled Persons - Only Trained And Qualified Personnel May Do This, Or The Warranty Is Void

    C-5000 Owner’s Manual OwnC-C-3000 Manual Graphs are not within their patient is perspiring, has Return patient to waiting specified boxes on the scan recently showered, has not room for additional time screen acclimated long enough 8.2 Troubleshooting and repair by skilled persons - Only trained and qualified personnel may do this, or the warranty is void.

  • Page 77: Repairing A Damaged Scanner

    C-5000 Owner’s Manual OwnC-C-3000 Manual USB port ok, LED lights in Internal processor failure Contact factory for handle – still no or communication IC instructions to return communication failure scanner for repair 8.3 Repairing a damaged scanner 8.3.1 Tools The following tools are needed for reparation tasks: Task Tools Tool 1 - 7/64...

  • Page 78: Repair Instructions

    C-5000 Owner’s Manual OwnC-C-3000 Manual 8.4 Repair Instructions 8.4.1 Barrels Replacing the Tytron Scanner Barrels Required tool - 7/64 Allen Wrench – remove 4 plastic screws holding handle to head Required tool - 0.050” Allen Wrench to “loosen” the 4-40 set screws securing barrels...
  • Page 79 C-5000 Owner’s Manual OwnC-C-3000 Manual...

  • Page 80: Lenses

    C-5000 Owner’s Manual OwnC-C-3000 Manual The small 4-40 Allen set screws may be very tight - use the short end of the Allen wrench and make sure it is in all the way before you try to loosen them - just enough to free the barrel - pull straight out (turning may cause the barrel to bind.
  • Page 81 C-5000 Owner’s Manual OwnC-C-3000 Manual The JAWS of the wrench should be well protected so they don't mar the barrels. If the barrel won't come out with reasonable force DO NOT PROCEED - send the scanner to us. When the barrel does come out, use a nail file to smooth over the spot (dimple) on the barrel body created by the set screw so it will go back in easily.
  • Page 82 C-5000 Owner’s Manual OwnC-C-3000 Manual lens. These ridges can be felt with your fingernail - they are to FACE OUT towards the front of the barrel. I find the best way to insert the lens is to place it on the back of the barrel (groves facing front) and at a 45-degree angle encourage it to enter the head using the barrel to guide it in.

  • Page 83: Replacing The Scanner Trigger

    C-5000 Owner’s Manual OwnC-C-3000 Manual 8.4.3 Replacing the scanner trigger Trigger Replacement in Titronics Thermal Scanners The trigger assembly in the C-3000, C-4000, C-5000, and C-6000 scanners consists of the following parts: The Stainless Steel trigger A stabilizing plastic sleeve...
  • Page 84 C-5000 Owner’s Manual OwnC-C-3000 Manual The plastic stabilizing sleeve will "click" into a round cutout in the back of the handle as you insert the pieces. Do this in such a way to keep clearance between the assembly and the wires or cables between the handle and head. The metal tab on the switch should not be caught in any of the spring loops, but should be up against the rear of the main trigger body.

  • Page 85: Trigger Assembly Replacement And Adjustment - Critical

    C-5000 Owner’s Manual OwnC-C-3000 Manual 8.4.4 Trigger Assembly Replacement and Adjustment – CRITICAL Remove the defective trigger switch assembly using the 3/32” Allen wrench, unplug the leads going to the female socket on the handle board. Plug in the leads from the new switch and mount the new assembly as shown.
  • Page 86 C-5000 Owner’s Manual OwnC-C-3000 Manual If the micro switch itself just became detached you may re-attach it following the instructions below. The positon that it is epoxied back to is critical: When you re-attach the switch (clean / sand surfaces first ) use 2 part quick set epoxy and make sure the BRACKET and PlASTIC...

  • Page 87: Replacing Scanner Wheel Assemblies

    C-5000 Owner’s Manual OwnC-C-3000 Manual 8.4.5 Replacing scanner wheel assemblies Replacing the Tytron Scanner Wheels Required tool - 7/64 ” Allen Wrench – remove 4 plastic screws holding handle to head Required tool - 0.050” Allen Wrench to “loosen” the 4-40 set screws securing barrels Right Wheel Replacement and “Adjustment To replace the RIGHT (idler) wheel and “arm”...
  • Page 88 C-5000 Owner’s Manual OwnC-C-3000 Manual The wheels should be positioned to the scanner doesn’t “rock” side to side when the barrels are on a flat surface. When both barrels and both wheel assemblies are on a flat surface the back of the “head” should be just a little forward of horizontal (level).
  • Page 89 C-5000 Owner’s Manual OwnC-C-3000 Manual With the handle off to one side, remove the male white plug from the socket on the computer ( A to D board ). It is tight – a small screwdriver may be used to “pry” them apart or the “nose”...

  • Page 90: Disposal

    C-5000 Owner’s Manual OwnC-C-3000 Manual 9 DISPOSAL The C-5000 may be disposed of without concern for any toxic substances, 95% of the scanner is Aluminum and stainless steel. These can be re-cycled by opening the scanner and removing the two circuit boards. The circuit boards are RoHS Compliant based on the EU RoHS 2.

  • Page 91: Disposal Of The Device

    C-5000 Owner’s Manual OwnC-C-3000 Manual Double check with the technically qualified IT person with knowledge of the C-5000 to make sure that after following all the trouble shooting guides the scanner is nonfunctional there are two choices: 1) return to the manufacturer for repair (recommended) 2) follow disposal procedures.

  • Page 92: Frequently Asked Questions

    C5000 and C6000 are USB connection and can be found in the Device Manager under USB Connections. No ports are needed to be put in the software. In this case, most standard drivers can be found on Titronics website under Resources or on the flash drive under drivers.

  • Page 93: Restoring A Broken Data Base

    C-5000 Owner’s Manual OwnC-C-3000 Manual In the Setup on the Scans Tab, there is an option of Center Bar graph. That should be checked YES. This is also an indication that your scanners calibration might need to be checked. 10.5 Restoring a Broken Data Base Close the software on all computers that are networked.

  • Page 94: What Are The Scanning Modes For The Tytron Software

    C-5000 Owner’s Manual OwnC-C-3000 Manual 10.8 What are the scanning modes for the Tytron software? If a scan is 25cm or less, the software recognizes it as a Cervical Scan, anything longer is a Full Spine. There are also the modes of Scan Segment and Infant Scan located at the top right of the scan screen.

  • Page 95: Data Base Error - How Do I Rebuild The Files In The Patient Db Files In The C-3000 Folder

    10.10 How do INSTALL / BACKUP / RESTORE the Tytron Software & Patient DATA from a USB Flash Drive? View the contents of the Flash Drive and double click on the Titronics.exe file. 10.11 SCANNER SOFTWARE INSTALLATION / BACKUP / AND RESTORE PROCEDURES Insert the Flash Drive into the USB Port –...

  • Page 96: Tytron Data Base Backup Procedures

    Chose Next again on the Ready to Install screen. Allow a few seconds for Titronics Instant Support to be installed. This will place an ICON on your Windows™ desk top. Should you need Titronics tech support – this will send to our service center your location and alert us to connect.

  • Page 97: I Just Bought A Scanner From Another Doctor; Do I Need To Contact Titronics

    10.13 I just bought a scanner from another doctor; do I need to contact Titronics? Titronics is under FDA guidelines. This means that Titronics is responsible for keeping a record of where the devices are. A transfer of a scanner from Doctor to Doctor can be done over the phone.
  • Page 98 C-5000 Owner’s Manual OwnC-C-3000 Manual F4 Scan Utilities:The Scan Utilities screen has 9 basic functions. Click the Scan Utilities button or hit the F4 key while at the Home Screen to perform scan utilities. First, a scan must be selected to perform a scan utility function (either click on it or select the corresponding letter) —...

  • Page 99: Do I Need To Back Up My Database

    C-5000 Owner’s Manual OwnC-C-3000 Manual screen listing and all subsequent scans performed. F12 Select Scans: Allows the selection of up to 10 scans for individual history viewing. Once the scans have been selected, click OK or hit the Enter key to view the scans. Hit the Esc key to return to the Select Scans screen.

  • Page 100: Appendix I - Supplied Accessories, Consumables And Spare Parts

    ( 4 count ) McMaster-Carr # 3/32” Allen Wrench 7122A42 0.050 “ Allen McMaster-Carr # Wrench 7122A13 McMaster-Carr # 7/64” Allen Wrench 7122A42 Titronics R & D 6-32 x ½” Allen nylon screws Tiffin, Iowa USA (8 extra in kit)

  • Page 101: Consumables - May Be Ordered From Titronics Website

    C-5000 Owner’s Manual OwnC-C-3000 Manual 4-40 x 3/16 Allen McMaster-Carr # head set screw 92765A005 11.2 Consumables - may be ordered from Titronics Website Image Name Article Number McMaster-Carr Chicago, Illinois Large (inner) rolling wheel tire # 9452K31- 213 McMaster-Carr...
  • Page 102 C-5000 Owner’s Manual OwnC-C-3000 Manual Titronics R & D Trigger micro switch Tiffin, Iowa USA Titronics R & D 6-32 x ½” Allen Head Tiffin, Iowa USA plastic screws – Website - ( 4 per package )
  • Page 103 C-5000 Owner’s Manual OwnC-C-3000 Manual...

  • Page 104: Clinical Evaluation

    C-5000 Owner’s Manual OwnC-C-3000 Manual 12 CLINICAL EVALUATION [Make sure that the clinical evaluation as most recently updated, is appropriately reflected in the instructions for use and, where applicable, the summary of safety and performance] Welfare on Thermal Imaging Thomas Tierney, Director of US Dept. of HEW “the 1972 First Position Paper of the U.S.
  • Page 105 C-5000 Owner’s Manual OwnC-C-3000 Manual For further documentation and information on clinical evaluation see Clinical Evaluation Report in accordance with MEDDEV 2.7/1 revision 4...

  • Page 106: Related Documentation

    C-5000 Owner’s Manual OwnC-C-3000 Manual 13 RELATED DOCUMENTATION Version Document Title Location Author...

  • Page 107: Safety Signs

    C-5000 Owner’s Manual OwnC-C-3000 Manual 14 SAFETY SIGNS 14.1 ISO 3864 Safety Signals 14.2 ANSI Z535.6 Safety Signals...
  • Page 108 C-5000 Owner’s Manual OwnC-C-3000 Manual...
  • Page 109 C-5000 Owner’s Manual OwnC-C-3000 Manual...
  • Page 110 C-5000 Owner’s Manual OwnC-C-3000 Manual...

Table of Contents
