- Page 1 Register your product and get support at www.philips.com/welcome User Manual PrimeSuite xxHFL4373D/10 22HFL4373D/10 26HFL4373D/10 32HFL4373D/10 42HFL4373D/10 Page 1...
- Page 2 09 2311 3415 France 0821 611655 Deutschland 01803 386 852 Ελλάδα0 0800 3122 1280 Magyarország 0680018189 Ireland North 0800 055 6882 South 1800-PHILIPS 7445477 Italia 840320086 Қазақстан +7 727 250 66 17 Latvia 67228896 Lithuania 52737691 Luxemburg/Luxembourg 40 6661 5644...
-
Page 3: Table Of Contents
7 Connect devices 38 Back connector 38 Side connector 39 Connect a computer 39 Use a Conditional Access Module 40 Use Philips EasyLink 41 Use a Kensington lock 41 8 Product information 42 Supported display resolutions 42 Multimedia 42 Tuner/Reception/Transmission 42... -
Page 4: Notice
1. Notice 2010 © Koninklijke Philips Electronics N.V. All rights reserved. Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips Electronics N.V or their respective owners. Philips reserves the right to change products at any time without being obliged to adjust earlier supplies accordingly. - Page 5 standardisation for early integration in its products. Mains fuse (UK only) This TV is fitted with an approved molded plug. Should it become necessary to replace the mains fuse, this must be replaced with a fuse of the same value as indicated on the plug (example 10A).
-
Page 6: Important
TV. If liquids are spilt on or into the TV, disconnect the TV from the power outlet immediately. Contact Philips Consumer Care to have the TV checked before use. • Never place the TV, remote control or batteries near naked flames or other heat sources, including direct sunlight. - Page 7 • Risk of hearing damage! Avoid using earphones or headphones at high volumes or for prolonged periods of time. • If the TV is transported in temperatures below 5°C, unpack the TV and wait until the TV temperature matches room temperature before connecting the TV to the power outlet.
-
Page 8: Tv Overview
3. TV overview This section gives you an overview of commonly used TV controls and functions. Please read section 3 to 6 to set the basic consumer menu first, and then follow the instructions in section 7 to set the Professional mode menu. -
Page 9: Guest Remote Control
Guest remote control PrimeSuite xxHFL4373D/10 1 (Standby-On) • Switches the TV to standby if it is on. • Switches on the TV if it is in standby. 2 EPG/TELETEXT Accesses the browse menu to select TV channel list, the Electronic Programme Guide and teletext. -
Page 10: Basic Tv Menus
15 (Volume +/-) Increases or decreases volume. 16 BACK • Returns to a previous screen. • Returns to the previously viewed channel. 17 Colour buttons • Selects tasks or options. • When Professional mode is On, press to operate Multi remote control function. Red button(DEMO) To select the red option, access digital Interactive TV services or watch TV... -
Page 11: Watch Tv
EPG/Teletext The EPG/Teletext menu gives you easy access to: • Electronic program guide • TV channel list • Teletext To access this menu, while watching TV, press a. the EPG/Teletext button on the remote control. 1. Press the Navigation buttons to select an item: •... -
Page 12: Adjust Tv Volume
Switch Channels Press P +/- on the remote control or P /CH +/- on the side of the TV. • Press , then select [Channel list] to use the channel list. Press to return to the previously-viewed • channel. • Enter a channel number using the Numeric buttons. -
Page 13: Watch A Connected Device
• [Energy saving] : The most energy- conscious settings. • [Standard] : Adjusts picture settings to suit most environments and types of video. Factory default settings. • [Photo] : Ideal settings for viewing photos. • [Custom] : Allows you to use the customize stored picture settings. -
Page 14: Use More Of Your Product
4. Use more of your product Use Teletext Select a page 1. Press 2. Select [Text], then press OK. 3. Select a page by: • Entering the page number with the Numeric buttons. • Pressing ▲ or ▼ to view the next or previous page. -
Page 15: Use Epg
Use EPG Overview The Electronic Programme Guide (EPG) is an on-screen guide available for digital channels. EPG allows you to: • View a list of digital programmes being broadcast • View upcoming programmes • Group programmes by genre • Set reminders when programmes start •... -
Page 16: Access Multimedia
You can view photos or play music and videos on TV from a USB storage device. •Philips is not responsible if the USB storage device is not supported nor is it responsible for damage or loss of data from the device. -
Page 17: Universal Access
4. Select [TV/Radio] > [Radio], then press OK. Use Hotel Information Activate Hotel Information You can use Hotel Information to display a picture as Information sheet on your TV. Make sure that the location of your TV is set to [Home] mode. -
Page 18: Set Up The Tv
5. Set up the TV Introduction This TV is a special TV, that allows the TV to be configured for a hotel application This section describes how to install and operate this TV. Before reading this section, please also read section 4 to understand the basic functionality of this TV. -
Page 19: Professional Mode Options
Professional mode options This paragraph describes the functionality of each item in the Professional mode setup menu. Enter the next layer by pressing [OK], or [>]. Return to a previous level by pressing [<]. Navigate in the current layer by pressing [^], or [v]. Layer 1 Layer 2 PBS Setup menu language... - Page 20 Speaker settings Factory default TV setup Enter Consumer Mode Channel Enter TV Channel Setup setup Store Save all made changes Settings Smart USB to TV Clone TV to USB SW types Download Program Info Start Download Software Upgrade Express Clone Channels To Special SP Communication PrimeSuite xxHFL4373D/10 Erase key option...
-
Page 21: Setup Settings
Setup settings PBS Setup [PBS Setup menu language] Select Setup menu language to be English, French, German or Italian. [PBS Mode] Enables / disables the Professional Hotel mode. [On]: All settings in the Professional mode Setup menu are in effect. [Off]: The TV operates as a normal (consumer) [Room ID] Entry field to store 4 digits to identify Room... - Page 22 [Off]: When set to Off, the TV will hide the Welcome Logo at start-up. [Browse USB] Enables / disables the USB Browse icon to be presented in the Guest Menu. [On]: When set to On, the TV will show the USB icon in the Home menu.
- Page 23 [Enable Subtitles] Enables or disables the use of subtitles in a DVB broadcast channel: [Off]: No subtitles services available (Prison Mode) [On]: Subtitles services available [Enable Channel Map] Select Channel Map to be viewed: [Native]: Show standard default channel [BDS]: To be used only if a STB is connected [Power settings]...
- Page 24 TTV button on the RC. [VSecure] VSecure is the hospitality content scrambling method used by the Philips Hospitality TVs. With its internal VSecure Authorization key a VSecure Unprotect key can be generated. If this VSecure Unprotect key is stored in the TV, the TV is able to descramble protected content.
- Page 25 [Vsecure self test] [Action] Internal self test to validate VSecure. After this load proper hotel specific keys. [Program Info] This function is to set the necessary DVB parameters to locate the proper VSecure RF channel to load the VSecure RF Static or RF Dynamic key(s): [Frequency] Frequency of MUX...
-
Page 26: Change Picture And Sound Settings
TV Setup With this option, all basic TV functionality can be configured. If any setting is changed within the PBS Menu, they should be stored before pressing [OK], otherwise they will be discarded. Select Setup to make changes to the TV settings Change picture and sound settings (with PBS setup RC) Picture settings... - Page 27 • [Screen edges]: Changes the picture size. Press OK to confirm your choice. • [Picture shift]: Adjusts the position of the picture. Not applicable if selected picture format is [Auto zoom] or [Wide screen]. Press OK to confirm your choice. 4 Press [Back/PP] to return to TV Setup Menu.
- Page 28 Press OK to confirm your choice. 4 Press [Back/PP] to return to TV Setup Menu. 5 Press [Back/PP] to exit. Preferences 1 Press [Home/Menu] ] > [TV Setup>. 2 Select [Setup] > [TV settings] > [Preferences], then press OK. 3. Select a setting to adjust and press <OK>: •...
- Page 29 Reinstall TV Starts a TV initialization to reset all settings to default and replace (reinstall) all channels. 1 Press [Home/Menu] ] > [TV Setup> [OK]. 2 Select [Setup] > [TV settings] > [Reinstall TV], then press OK. TV will perform a power down cycle going into standby and then starts-up again.
- Page 30 8 Press [Start] to continue. 9 If a preset Network Frequency is not available, or the Network Frequency Mode is set as manual, Enter the Network Frequency and press [Done] to continue. Press [Cancel] if no DVB-C to install (only DVB-T and Analogue). 10 Once the channel list is configured, the TV shows how many digital and analog channels are captured and returns to the...
- Page 31 [Symbol rate mode]: Automatic TV will use the preset Symbol rate (6.900/6.875) Manual Option to set Symbol rate 1 and Symbol rate 2 [Symbol rate 1]: 0.000 (to set) [Symbol rate 2]: 0.000 (to set) [Search]: Start the test scan Set the frequency for the selected MUX [000.00] and press [Search].
-
Page 32: Change Channel Settings
Change channel settings After installation, you may want to reorder the channel list to suit your preference. ► 1 Press [Home/Menu] [Channel setup] ► 2. Select a channel to adjust and press <OPTIONS>: • [Rename] ►: Press <OK> to bring up the virtual keyboard and edit the name. -
Page 33: Smart Clone
Instead of using a USB memory device to do cloning and firmware update, this upgrading is also possible using the RF infrastructure. This is supported by SmartInstall (Philips Hospitality RF Download mechanism) and allows a simultaneous upgrade of all installed televisions. -
Page 34: Connect Devices
6. Connect devices This section describes how to connect various devices with different connectors and supplements examples provided in the Quick Start. ••Different types of connectors may be used to connect a device to your TV, depending on availability and your needs. Back connector 1) EXT 1 (CVBS and RGB) Analogue audio and video input from analogue... -
Page 35: Side Connector
Side connector 1) COMMON INTERFACE Slot for a Conditional Access Module (CAM). 2) USB Data input from USB storage devices. PrimeSuite xxHFL4373D/10 3) HDMI Digital audio and video input from high- definition digital devices such as Blu-ray players. Connect a computer Before you connect a computer to the TV •... -
Page 36: Use A Conditional Access Module
• DVI-HDMI cable • HDMI cable and HDMI-DVI adaptor • VGA cable PrimeSuite xxHFL4373D/10 Use a Conditional Access Module A Conditional Access Module (CAM) is provided by digital TV service operators to decode digital TV channels. ••If required, refer to documentation from your operator on how to insert a smart card into the Conditional Access Module. -
Page 37: Use Philips Easylink
EasyLink-compliant devices. ••Compliant devices must be connected to your TV via HDMI. Enable or disable EasyLink ••Do not enable Philips EasyLink if you do not intend to use it. 1. Press 2. Press Navigation buttons to select [Setup] > [TV settings] > [EasyLink]. -
Page 38: Product Information
• Ambient temperature: 5 to 40 degrees Celsius Supported TV mounts To mount the TV, purchase a Philips TV mount or a VESA-compatible TV mount. To prevent damage to cables and connectors, be sure to leave a clearance of at least 2.2 inches or 5.5cm from the back of the TV. -
Page 39: Troubleshooting
••Disconnect the power cable from the power outlet. Wait until the TV cools down before reconnecting the power cable. If the blinking reoccurs, contact Philips Consumer Care. You forgot the code to unlock the TV lock feature ••Enter ‘8888’. The TV menu is in the wrong language. -
Page 40: Sound Issues
If you cannot resolve your problem, refer to the FAQs for this product at: www.philips.com/support. If the problem remains unresolved, contact Philips Consumer Care in your country as listed in the warranty leaflet. Warning ••Do not attempt to repair the product yourself. - Page 41 9. A Attachment 1 0 This section describes commonly encountered issues when installing DVB-T channels. DVB-T installation issues The TV does not switch on: • Disconnect the power cable from the power outlet. Wait for one minute then reconnect it. •...
- Page 42 Index age rating 15 Alarm 15 ALARM 7 audio language 23 Audio lip sync 26 Batteries 44 Blue mute 35 Channel list PayTV channel 37 Troubleshooting 46 clock 16 Computer Connect 41 display resolutions 44 Troubleshooting 47 Consumer setup 33 Digital channels CAM 42 Display resolutions 44...
- Page 43 picture format 12 picture setting 20 picture settings 20 POWER 10 Technical specifications 44 Professional mode Activate 30 Options 31 PBS mode 33 Store settings 37 Remote control Multi remote control 36 Professional Setup Remote control 29 RC lock 34 Remote control usage 8 Technical specifications 44 Troubleshooting 46...
- Page 44 © 2011Koninklijke Philips Electronics N.V. All rights reserved. PrimeSuite xxHFL4373D/10 Page 44...
- Page 45 PrimeSuite xxHFL4373D/10 Page 45...
- Page 46 PrimeSuite xxHFL4373D/10 Page 46...
- Page 47 PrimeSuite xxHFL4373D/10 Page 47...
