Contents 1 Important Safety Notice 2 Your car audio system Introduction What’s in the box Overview of the main unit 3 Get started Install the car audio Turn on Set date and time Adjust screen 4 Use map Upgrade the map 5 Listen to radio Tune to a radio station Store radio stations in memory...
DivX, Inc. and are used under license. registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Philips is under license. Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
What’s in the box Check and identify the contents of your package: a Main unit b Power connector c Audio out cable d I/O cable e GPS antenna f CMMB connector g AV in cable h Screen cleaning cloth i Printing material (include User manual, Quick start guide)
Overview of the main unit a Disc slot b TUNE/ SELECT Skip to the previous or next title, chapter, or track. Search backward/forward at different speeds. Start, pause or resume play. Eject disc. d DISP/ / Adjust screen brightness/contrast/ color. Turn on/off the screen display.
These instructions are for a typical installation. However, if your car has different requirements, make the corresponding adjustment. If you have any questions regarding installation kits, consult your Philips car audio dealer. Caution This unit is designed for negative ground (earth) 12 V DC operation only.
Page 8
Check the car’s wiring carefully, then do the other connections: Yellow Green Blue Gearbox Mount in the dashboard Note Check wire connection before you mount the unit into a car. If preset radio stations are lost when the ignition key is turned OFF and then back ON, reconnect the red leads crosswise to the yellow ones.
Slide the unit into the dashboard until a click sound is heard. Mount on the screws. Reconnect the negative terminal of the car battery. Turn on Caution Risk of road accidents! Never watch video or adjust settings while you drive. Press to turn on the unit.
Touch [Settings]. Touch [Time]. » The date/time setup menu is displayed. Set date Touch [Date]. Touch on the displayed date information. » A submenu is displayed. Touch to set year, month and day. Set clock mode Touch [Clock mode]. Touch on [12Hr] or [24Hr] to select clock mode.
4 Use map Note You may need to upgrade the map before using it (see “Upgrade the map” section) Touch the upper left corner to display home menu. Touch [Navigation]. » The navigation menu is displayed in a few seconds. Refer to the map manual (in Chinese) to operate the navigation tool.
5 Listen to radio Tune to a radio station Touch the upper left corner to display home menu. Touch [Radio]. » Band and frequency information is displayed. Touch on FM or AM to select band: FM band options: FM1, FM2, FM3 AM band options: AM1, AM2 to tune to a radio station by step.
Touch [Save]. Touch one of the channels 01 to 06 to save the select band. Store stations automatically You can search for a station with intro search, which broadcasts a 10-second preview of each detected radio station. Select band. Touch Touch [Search].
Connect USB device Note Ensure that the device contains playable content. Open the USB door. Insert the USB device to the USB socket. » Play starts automatically. Note To remove the USB device, switch to disc, radio Insert SD/MMC card Note Ensure that the device contains playable content.
To pause, touch To resume play, touch again. Search for a folder Touch to return to playlist menu. Touch folders. Touch a folder, then touch Touch to start play. Touch to return to playlist menu. Touch to display all available audio folders.
Touch to display the 2nd menu. Touch to select: [Repeat chapter]: play the current chapter repeatedly. [Repeat title]: play all chapters in the title repeatedly. [Repeat off]: cancel repeat play. For VCD karaoke or audio CD: Touch anywhere except for the upper left corner to display menu on the screen, if necessary.
Select audio mode When you play VCDs, you can select an audio mode (R/L/Stereo). During play, touch anywhere except for the upper left corner to display menu on the screen. Touch repeatedly until the audio mode is selected. Select subtitle language For DVD or DivX discs that contain two or more subtitle languages.
7 Play with Bluetooth device You can make or receive phone calls with Bluetooth-enabled phones through the unit. You can also listen to music from a Bluetooth- enabled device. Pair the Bluetooth-enabled devices To connect your Bluetooth device to the unit, you need to pair the device to the unit.
[Missed calls] [Received calls] [Dialed calls] [Phone book] [Sim phone book] [Local phone book] Or touch to dial number directly, then touch to dial. Receive call By default, all incoming calls are received automatically. If there is incoming call, [Incoming call...] Bluetooth microphone.
Adjust Bluetooth settings You can change below Bluetooth settings: [Bluetooth]: to turn on or off “Bluetooth” function [Auto connect]: to turn on or off “Auto connect” function [Auto answer]: to turn on or off “Auto answer” function [Pairing code]: to set paring code [Phone Book Sync]: to synchronize phone book In Bluetooth menu, touch...
9 Adjust settings Display system setup menu Touch the upper left corner to display main menu. Touch in the middle right side of the screen. » The second main menu is displayed. Touch [Settings]. » The settings menu is displayed. When the setup adjustment is completed, touch to return to...
General Options Description settings [Beep] [On] Turn on the beep sound. Each time you press a button, the unit beeps. [Off] Turn off the beep sound. [WallPaper] [Blue] Turn background color to blue. [Black] Turn background color to black. [Red] Turn background color to red.
Touch an option repeatedly to select: Video Options Description settings [Aspect [Full] For widescreen ratio] display. [Normal] For normal display. [Video [Auto] The correct format input] is set automatically. Select this option if you are not sure which format should be selected.
Adjust language settings Touch [Language]. Touch an option repeatedly to select: Language Options Description settings [OSD] [English] Select on-screen- display language. [DVD [English] Select DVD audio audio] language. Options available are depends on DVD disc. [DVD [English] Select DVD subtitle subtitle] language.
Touch an option repeatedly to select: Options Description rating [Set Set password to password] restrict the play of discs. The default password is 0000. [Rating [Kid safe] Acceptable for level] children. Acceptable for general viewers. [PG] Parental guidance suggested. [PG-13] Unsuitable for children under age 13.
Check the electric connection. Buy a fuse that matches the voltage of the damaged fuse (15A). Replace the fuse. If the fuse gets damaged immediately after it has been replaced, there may be an internal malfunction. In such case, consult your Philips dealer.
11 Product information Note Product information is subject to change without prior notice. General Power supply 12 V DC (11 V - 16 V), negative ground Fuse 15 A Suitable speaker 4 - 8 impedance Maximum power 50 W x 4 channels output Continuous power 24 W x 4 channels...
If you encounter problems when using this apparatus, check the following points before requesting service. If the problem remains unsolved, go to the Philips web site (www.philips.com/welcome). When you contact Philips, ensure that the apparatus is nearby and the model number and serial number are available.
Video connection is improper. Check the connections. Noise in broadcasts Signals are too weak. Select other stations with stronger signals. Check the connection of the car antenna. Change broadcast from stereo to mono. Preset stations lost Battery cable is not correctly connected. Connect the battery cable to the terminal that is always live.
13 Glossary Bite rate The max data transfer through the USB port. Bluetooth that is meant to allow mobile devices to share information and applications without the worry of cables or interface incompatibilities. Denmark. Operate at 2.4GHz. For more information, see www.bluetooth.com. MultimediaCard.
