- Page 1 Register your product and get support at www.philips.com/welcome EN User manual ES Manual del usuario ZH-TW CED370...
-
Page 2: Table Of Contents
Contents 1 Important Safety Notice 2 Your car audio system Introduction What’s in the box Overview of the main unit Overview of the remote control 3 Get started Install the unit Install remote control battery Turn on Select display language Set clock Use map 4 Listen to radio... -
Page 3: Important
1 Important Safety • Read and understand all instructions before you use the apparatus. If damage is caused by failure to follow instructions, the warranty does not apply. • Use of controls or adjustments or performance of procedures other than herein may result in hazardous radiation exposure or other unsafe operation. - Page 4 European Community. Any changes or modifications made to this device that are not expressly approved by Philips Consumer Lifestyle may void the user’s authority to operate the equipment. Environmental information All unnecessary packaging has been omitted.
- Page 5 Note This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 6: Your Car Audio System
2 Your car audio system Congratulations on your purchase, and welcome to Philips! To fully benefit from the support that Philips offers, register your product at www.philips.com/welcome. Introduction With the car entertainment system, you and your passengers can enjoy: •... -
Page 7: Overview Of The Main Unit
Overview of the main unit a LED indicator (green/red) • Answer phone (green). • Dial number (green). • Terminate call (red). b SOURCE • Select audio/video source. c +/- • Increase/decrease volume. d Remote control sensor • Unlock the panel •... -
Page 8: Overview Of The Remote Control
i DISP • Switch back light mode. • During video play, press and hold to adjust display contrast. • Tune to a radio station. • Skip track. • Fast backward/forward playback. /MUTE/OK • Turn the unit on or off. • Turn mute on or off. -
Page 9: Dvd Menu
• Adjust display brightness/contrast. f VOLUME +/- • Adjust volume. g EQ/AUDIO • Select equalizer (EQ) settings. • Access audio setting menu. h GOTO • Select track/chapter. • Tune for radio station. • Skip to previous track/chapter. • Search backward. j DVD MENU •... -
Page 10: Get Started
Always follow the instructions in this chapter in sequence. If you contact Philips, you will be asked for the model and serial number of your apparatus. The model number and serial number are on the bottom of your apparatus. Write the numbers here: Model No. - Page 11 Connect wires: ISO connectors Caution • Ensure that all loose leads are insulated with electrical tape. Pull out the ISO connectors from the car dashboard and connect them to the bigger end of the supplied standard connector. Connect the other end of supplied standard connector to the unit.
- Page 12 Connect wires: without ISO connectors Caution • Ensure that all loose leads are insulated with electrical tape. Cut off the bigger end of the supplied standard connector. Check the car’s wiring carefully, then connect them to the standard connector. Connector Yellow wire Blue wire Orange wire Illumination switch...
- Page 13 Connect the supplied standard connector to the unit. • If necessary, do the other connections. (See the last step in section Connect wires: ISO connector) Connect radio antenna If your car has built-in radio antenna, connect it to the radio antenna of the system for better radio signal.
- Page 14 Connect reverse driving cable Refer to the illustration below to connect reverse driving wire. Connect parking brake wire Refer to the illustration below to connect parking brake wire. Green/White...
-
Page 15: Mount In The Dashboard
Mount in the dashboard Note • For proper operation of the DVD player, the chassis must be mounted within 20 degree horizontal. Ensure that the unit is mounted within this limitation. If the car does not have an on-board drive or navigation computer, disconnect the negative terminal of the car attery. -
Page 16: Attach The Front Panel
Place the rubber cushion over the end of the bolt. Slide the unit into the dashboard until a click sound is heard. Reconnect the negative terminal of the car battery. Attach the front panel Attach the trim plate. Insert the left side of the panel in the chassis until it is correctly engaged. -
Page 17: Install Remote Control Battery
Install remote control battery Caution • Risk of explosion! Keep batteries away from heat, sunshine or fire. Never discard batteries in fire. • Risk of decreased battery life! Never mix different brands or types of batteries. • Risk of product damage! When the remote control is not used for long periods, remove the batteries. -
Page 18: Set Clock
Touch [Setting]to display setting menu. Touch [Language]. » The screen below displays. Touch [OSD Language]. » Available languages display. Touch to navigate all the available languages. Touch and select the preferred language. » The display language changed to the selected language. Set clock Touch to display main menu. -
Page 19: Listen To Radio
4 Listen to radio Tune to a radio station Touch to display main menu. Touch [Radio]. » Radio menu displays. Touch [FM] repeatedly at the right-lower corner to switch among the band options. • FM band options: [FM1], [FM2], [FM3] •... -
Page 20: Store Radio Stations In Memory
Press to exit the menu. Select AM tuner step Before you start to search for AM radio stations, you can select how much hertz per step in AM radio searching. Under radio menu, touch » Radio option menu displays. Touch to navigate to the second page of the option menu. -
Page 21: Store Stations Manually
Touch [Auto Scan]. » Auto search starts. The six strongest stations of the selected band are saved in preset channels 1-6 automatically. Store stations manually Tune to the preferred station. » If the station is not in the preset list, displays on the lower line of the screen. - Page 22 • EON (Enhanced Other Networks) local stations ‘break into’ a national station’s broadcast for the duration of a Traffic Announcement. • CT (clock time): synchronizes the clock of the unit with that on the RDS station. Search for an RDS station by PTY information Touch [PTY] under RDS menu.
-
Page 23: Tune To A Preset Station
Tune to a preset station Select the band with preset stations. Touch on the left side of the screen. » Preset station list displays. Touch / to navigate through all the preset stations. Select and touch on a preset station. »... -
Page 24: Insert Usb Device
Note • Depends on where you bought the unit, you can play DVD discs with one of the following region codes: Countries where you Supported DVD bought the unit region code China Asia Pacific, Taiwan, Korea Latin America Russia, India Insert USB device Slide the USB socket cover to the left. -
Page 25: Play/Pause
Play/Pause Once the disc, USB or SDHC card is inserted, play starts automatically. • For video discs, if a menu appears: touch / to navigate through the menu, then touch on an item to start play. • For disc/USB/SD card that contain MP3s, WMAs, or JPEGs: touch / to navigate through the tracks/pictures, then touch on an item to start play. -
Page 26: Repeat
Repeat You can play tracks, folders, all files or certain section within one track repeatedly. During play, touch to display option menu. Touch: • repeatedly to switch among different repeat modes. • to repeat play certain section within one track. Random play You can play tracks/files in random order. -
Page 27: Zoom
Zoom You can zoom in pictures for a close view. During video play or picture view, touch to display option menu. Touch repeatedly to zoom in/out the picture. Touch , , to pan through the enlarged picture. Select slide show duration During viewing pictures, touch display option menu. -
Page 28: Make A Call
Disconnect Bluetooth devices To disconnect one device, touch icon). » (green icon) displays. • The device will also be disconnected when the device is moved beyond the operational range. • If you want to reconnect the device to the unit, place it within the operational range. •... -
Page 29: Switch Phone Call To The Mobile
If there is incoming call, [Incoming call...] flashes on the screen. Speak into the Bluetooth microphone. When conversation ends, touch to terminate the call. • You can select to receive calls manually by set [Auto Answer] to [Off] status. Switch phone call to the mobile If you do not want your passenger to hear your incoming call, you can switch the call to the... -
Page 30: Adjust Sound
7 Adjust sound Adjust volume Prees +/- on the front panel to increase/ decrease volume. Mute During play, press • To turn the sound back on, press again. • You can also turn off sound by touching the screen. Note •... -
Page 31: Set Dynamic Bass Boost (Dbb)
Touch to select subwoofer volume. • [Subwoofer] subwoofer volume: 0 to 24. Touch F, R, L, or R to adjust fader/balance value. • [Fad] fader range: +24 to -24. (F = front speaker, R = rear speaker) • [Bal] balance range: -24 to +24. (L = left speaker, R = right speaker) Touch to exit the menu. -
Page 32: Adjust Sound Settings
System Options Description settings [Dimmer [Off] Never turn on mode] the screen dim. [On] Turn on the screen dim automatically 5 seconds after last operation. [Key color] [Red]/ Button backlight [Blue] turns red/blue. [Background [Blue]/ Change the image] [Black] background color to blue/black. -
Page 33: Adjust Bluetooth Settings
Touch an option repeatedly to select: Video Options Description settings [Video [Auto] The correct format Input] is set automatically. Select this option if you are not sure which format should be selected. [NTSC] Used in the United States, Canada, Japan, Mexico, the Philippines, South Korea, Taiwan, and some other... -
Page 34: Adjust Language Settings
Adjust language settings Touch >[Setting]>[Language] to display language setting menu. Touch an option repeatedly to select: Language Options Description settings [OSD [English]/ Select on-screen- Language] [Español]/ display language. [Português]/ [DVD Select DVD audio Audio] language. Options available depend on DVD disc. [DVD Select DVD subtitle]... -
Page 35: Others
9 Others Listen to other devices You can connect an external audio/video device to the unit. Connect the device to the unit with the supplied MP3-Link cable. Touch >[Media]>[MP3-LINK]. » MP3-Link screen displays. Begin play on the device (see the device instructions). -
Page 36: Replace Fuse
Buy a fuse that matches the voltage of the damaged fuse (15A) Replace the fuse. If the fuse gets damaged immediately after it has been replaced, there may be an internal malfunction. In such case, consult your Philips dealer. 10 Product information Note •... - Page 37 Tuner Frequency range - FM 87.5 - 108.0 MHz (Europe) Frequency range - 522 - 1620 KHz AM (MW) (Europe) Usable sensitivity - FM 5 uV Usable sensitivity - 50 uV AM (MW) Screen size 3.5 inches (16:9) Display resolution 320 x 240 dots Contrast ratio Brightness...
-
Page 38: Troubleshooting
If you encounter problems when using this apparatus, check the following points before requesting service. If the problem remains unsolved, go to the Philips web site (www.philips.com/support). When you contact Philips, ensure that your apparatus is nearby and the model number and serial number are available. -
Page 39: Glossary
The paired mobile phone connects and disconnects constantly. • The Bluetooth reception is poor. Move the mobile phone closer to the system or remove any obstacle between the mobile phone and the system. • Some mobile phones may connect and disconnect constantly when you make or end calls. - Page 40 SDHC Secure Digital High Capacity (SDHC) is a type of flash memory card based on the SDA 2.00 specification. The SDA 2.00 specification enables SD cards to reach higher capacities from 4GB to 32GB, and growing. WMA (Windows Media Audio) An audio format owned by Microsoft, is a part of Microsoft Windows Media technology.
- Page 41 © 2010 Koninklijke Philips Electronics N.V. All rights reserved. Document order number: CED370_00_UM_V3.1...
