Steerman Load Moving Systems
"Lifting Loads the Professional Way"
Operating Instructions for
Hydraulic Toe Jacks
Model: HTJ-3 Capacity 3t
Model: HTJ-6 Capacity 6t
Model: HTJ-10 Capacity 10t
CCCC
Before attempting to use this equipment please
ensure that you read and fully understand the
correct operating procedures.
Steerman Load Moving Systems
Advertisement
Table of Contents
Summary of Contents for Steerman Load Moving Systems HTJ-3
- Page 1 Steerman Load Moving Systems “Lifting Loads the Professional Way” Operating Instructions for Hydraulic Toe Jacks Model: HTJ-3 Capacity 3t Model: HTJ-6 Capacity 6t Model: HTJ-10 Capacity 10t CCCC Before attempting to use this equipment please ensure that you read and fully understand the correct operating procedures.
- Page 2 These jacks ARE NOT recommended for use in lifting or positioning of housing/buildings. SPECIFICATIONS Model Capacity Base Size Lifting Range- Lifting Range- L x W Head HTJ-3 3,000 151 x 110mm 16 x 146mm 230 x 360mm HTJ-6 6,000 280 x 190mm 22 x 172mm 268 x 420mm...
- Page 3 BEFORE USE 1. Verify that the product and the application are compatible; if in doubt call your authorised Steerman Distributor for further advice. 2. Before using this product, read the operating instructions thoroughly and familiarize yourself with the product and the hazards associated with its improper use. 3.
- Page 4 CAUTION! ENSURE THAT ALL PERSONNEL AND TOOLING ARE CLEAR BEFORE LOWERING THE LOAD. DANGEROUS DYNAMIC SHOCK LOADS ARE CREATED BY QUICKLY OPENING AND CLOSING THE RELEASE VALVE AS THE LOAD IS BEING LOWERED. THE RESULTING OVERLOAD MAY CAUSE HYDRAULIC SYSTEM FAILURE, WHICH COULD CAUSE SEVERE PERSONAL INJURY AND OR EQUIPMENT DAMAGE.
- Page 5 TROUBLE SHOOTING Symptom Possible Causes Corrective Actions Jack will not lift the load Release valve not tightly Ensure release valve is closed tightly closed Overload condition Remove the overload condition Jack will not hold pressure Release valve not tightly Ensure release valve is closed tightly closed Overload condition...
- Page 6 Replacement Parts Illustration for Steerman Hydraulic Toe jacks Models HTJ-3, HTJ-6 and HTJ-10 Please ensure you supply model type/number, serial number and a full description of the parts and part numbers when placing an order. Fax or telephone your parts...
