UNIT DOES NOT FUNCTION
ARE EXTERNAL SUPPLY
STOPS OPEN?
YES
IS INTERNAL SUPPLY
STOP OPEN?
YES
REPEATED DOUBLE FLASH
ON SENSOR?
NO
RECONNECT BATTERY TO SENSOR.
DOES SENSOR FLASH FOR 5 SECONDS?
YES
REPLACE SOLENOID
WATER IS CONTINUOUSLY RUNNING
RECONNECT BATTERY TO SENSOR.
DOES SENSOR FLASH FOR 5 SECONDS?
YES
REPLACE SOLENOID
LOW FLOW ISSUES
ARE INTERNAL & EXTERNAL SUPPLY
STOPS OPEN ALL THE WAY?
YES
LOW FLOW COULD BE CAUSED BY DEBRIS
IN THE FILTER SCREEN. REMOVE, CLEAN,
AND INSERT FILTER SCREEN BACK TO ITS
ORIGINAL POSITION.
