Erica Synths Drum Series Quick Start Manual

SAFETY INSTRUCTIONS
Please follow the instructions for use of the Erica Synths module
below, 'cause only this will guarantee proper operation of the module
and ensure warranty from Erica Synths.
Water is lethal for most of the electric devices, unless they are made waterproof.
This Erica Synths module is NOT intended for use in a humid or wet environment.
No liquids or other conducting substances must get into the module. Should this
happen, the module should be disconnected from mains power immediately,
dried, examined and cleaned by a qualified technician.
Do not expose the module to temperatures above +50° C or below -20° C.
If you have transported module in extreme low temperatures, leave it
in room temperature for an hour before plugging it in.
Transport the instrument carefully, never let it drop or fall over.
Warranty does not apply to modules with visual damages.
The module has to be shipped in the original packaging only. Any module
shipped to us for return, exchange and/or warranty repair has to be in its
original packaging. All other deliveries will be rejected and returned to you.
Make sure you keep the original packaging and technical documentation.
This device complies to the EU guidelines and is manufactured RoHS conforming
without use of lead, mercury, cadmium and chrome. Nevertheless, this device is
special waste and disposal in household waste is not recommended.
You will find Erica Synths terms of warranty at www.ericasynths.lv
Items for return, exchange and/or warranty repair have to be sent to:
Andrejostas Str. 43
User manual by Girts Ozolins@Erica Synths.
Design by Ineta Briede@Carre Branding.
Copying, distribution or any commercial use in any way
is prohibited and needs the written permission by Erica Synths.
Specifications are subject to change without notice.
In case of any questions, feel free to contact us through
www.ericasynths.lv or via e-mail info@ericasynths.lv
Erica Synths
Riga
Latvia
LV-1045
THANK YOU FOR PURCHASING
ERICA SYNTHS DRU ODULE!
Erica Drum Series modules include high-end,
unique functionality and superior quality modules,
which allow you to design extensive, feature rich
modular system for sound design and live
performances. Enjoy!
Erica Synths Cowbell is developed in collaboration with
French company e-licktronic and it's our take on analogue
cowbell circuits adapted for modular systems. Accent and
CV control over Tune make it distinctively expressive in
studio and live performances.
FEATURES
Tune and Decay controls
CV control with an attenuator over Tune
Manual trigger
Accent for better expression
SPECS
Decay range
Audio output level
CV level (full span)
Accent CV level
Tigger level
Trigger time
Power consumption
Module width
Module depth
120ms - 1100ms
-5...+5V
-5V - +5V
10V
5V
1ms
14mA @ +12V,
10mA @ -12V
6HP
30mm
