AMF-BRUNS BSL 350 Short Operation Manual

AMF-Bruns

IMportAnt InForMAtIon

Swivel lift BSL 350
It's prohibited to stay in swivelling or
lowering range!
(top view)
It is only possible and allowed to lower
or raise the lift if both roll-off stops are
folded up!
Any warranty work is only regulated if
accepted and approved by AMF-Bruns
beforehand!

EMErGEnCy opErAtIon

Swivel lift BSL 350

1. EmErgEncy lowEring

1. Remove cover on platform side
2. Press down the lowering valve's red knurled head
screw, and rotate anti-clockwise at the same time
until it snaps up
3. Lift platform is now lowering
4. Press red knurled head screw again, and rotate
clockwise this time
5. Raise platform via manual pump, and stow it into
the vehicle

2. EmErgEncy lifting

Raise platform via manual pump, and stow it into the
vehicle
February 2012 / Subject to modifications
(top view)
Please note: The short operation manual does not replace the
regular operation manual! Please read the regular operation
manual carefully before using the product!
AMF-Bruns GmbH & Co. KG
Hauptstraße 101 I 26689 Apen I Germany
Telefon (Sale) +49 (0) 44 89 / 72 72 50
Telefon (Service) +49 (0) 44 89 / 72 72 37
Telefax +49 (0) 44 89 / 62 45
hubmatik@amf-bruns.de I www.amf-bruns.de
February 2012
AMF-Bruns
Short operation manual
Swivel lift BSL 350
