- Page 1 HDAC .64 User Manual Connector Assembly Reference Manual REV 1 – May 9, 2006 Downloaded from Elcodis.com electronic components distributor...
- Page 2 Table of Contents Section 1: Product Introduction Section 2: Product Summary Section 3: Connector Assembly Section 4: Connector Mating Section 5: Service Instructions HDAC 0.64 User Manual Downloaded from Elcodis.com electronic components distributor...
-
Page 3: Product Introduction
Product Introduction HDAC 0.64 Product Line HDAC 0.64 User Manual Downloaded from Elcodis.com electronic components distributor... - Page 4 Section 1: Product Introduction This instructions manual contains supplemental information pertaining to the Molex HDAC 0.64 Product Line. For product ordering information, please contact your Molex Inside Sales Representative at (800)786-6539. For electronic copies and future updates of this document, and the Connector Reference Manual, refer to the Molex Website at http://www.molex.com...
-
Page 5: Section 2: Product Summary
Section 2: Product Summary A. Connector Assemblies HDAC 0.64 Receptacle Connector Assembly HDAC 0.64 Blade Connector Assembly Housing HDAC 0.64 User Manual Downloaded from Elcodis.com electronic components distributor... - Page 6 Section 2: Product Summary TYCO Blade Terminal • Base Material Copper Alloy • Plating Options Tin, Gold • Wire Sizes: 16,18,20,22 AWG Molex Receptacle Terminal PN 34083-3001 • Base Material Copper Alloy • Plating Options Tin, Gold • Wire Sizes: 16,18,20,22 AWG HDAC 0.64 User Manual...
-
Page 7: Section 3: Connector Assembly
Section 3: Connector Assembly A. Connectors shown in “As Shipped” Connector Position TPA’s shown in “as shipped” condition (pre-lock). The TPA must remain in the pre-lock position until all circuits are loaded. HDAC 0.64 User Manual Downloaded from Elcodis.com electronic components distributor... - Page 8 Section 3: Connector Assembly B. Terminal Installation: With TPA still in pre-lock position, orient terminal to rear of connector as shown below. Grip the wire no less than 1.25 inches from the terminal insulation crimp and insert through appropriate circuit opening. If resistance is encountered, retract the terminal and adjust the angle of insertion.
- Page 9 Section 3: Connector Assembly C. Seating the TPA With the receptacle terminals fully installed, the TPA can be seated into its final lock position by applying an even force to the TPA surface until it comes to a stop, with an audible click. With the blade terminals fully installed, the TPA can be seated into its final lock position by applying an even force to the TPA surface until it comes to a stop, with an audible click.
-
Page 10: Section 4: Connector Mating
Section 4: Connector Mating Note and align connector keying features, from receptacle connector to blade connector. Begin mating procedure by sliding the receptacle connector assembly and blade connector Keying Features assembly together, press firmly until you hear an audible click. CLICK HDAC 0.64 User Manual Downloaded from... -
Page 11: Section 5: Service Instructions
Section 5: Service Instructions A. Un-mate procedure To un-mate the connectors, push connector together to unload the latch system. Than depress the latch with your thumb (step 1). Continue to depress the latch, and gently pull apart connector assemblies (step2). Step 1 Step 2 HDAC 0.64 User Manual... - Page 12 Section 5: Service Instructions B. TPA Servicing Receptacle Step 1: Insert a small screwdriver, or service tool (max width = 2.0 mm) into the designated pry point. Step 2: Using the housing as a pivot point gently push out on the TPA until it is removed from the connector housing.
- Page 13 Section 5: Service Instructions C. TPA servicing the Blade connector Step 1: Insert a small screwdriver into the two small extraction holes Step 2: Push on opposite sides of the TPA latch until it is removed from the connector housing. If TPA is damaged, Do Not Reuse! Excessive force may damage the TPA! Step 1 Step 2...
- Page 14 Section 5: Service Instructions D. Terminal removal (continued) Step 3: Service tool should not be more than 2.0 mm wide. Using the designated service tool, disengage the terminal lock finger. Once the Lock finger is disengaged, gently pull on the wire to release the terminal. If the terminal resists, the service tool may not be fully engaged.
