Summary of Contents for Philips/Magnavox AZ2750/07
- Page 1 Portable CD Mini System Toll Free Help Line Ligne d'assistance en service libre Linea de ayuada telefónica sin cargo 800-531-0039 TUN ER TUN ER TAP E TAP E PRO G PRO G STO P STO P SEA RCH SEA RCH PLA Y/P AU SE PLA Y/P AU SE BAN D...
- Page 2 23 4 TUN ER TAP E PRO G STO P SEA RCH PLA Y/P AU SE BAN D – – SPEAKERS 4 110-127V 10-127V MAINS 220-240V 220-240V &...
-
Page 3: Top And Front Panels
CONTROLS TOP AND FRONT PANELS 1 POWER - to switch the set ON/OFF 2 DBB (Dynamic Bass Boost) - to enhance bass response 3 VOLUME - to adjust volume level 4 CD, TUNER, TAPE - to select source of sound 5 CD Display - to show the CD functions 6 OPEN - to open/ close the CD door 7 p 3.5 mm jack for stereo headphone... -
Page 4: Power Supply
BATTERIES (OPTIONAL) 1. Open the battery compartment and insert six batteries, type R-20, UM-1 or D-cells, (preferably alkaline) with the correct polarity as indicated by the " compartment. 2. Replace the compartment door, making sure the batteries are firmly and correctly in place. The set is now ready to operate. 3. -
Page 5: Connecting The Speakers
SPEAKERS REMOVABLE LOUDSPEAKERS Taking off the speakers Keep the lever (found on the back corner of the speaker) pressed and slide the speaker upwards. Attaching the speakers Slide the speakers from above into the sleeves on the sides of the cabinet. - Page 6 RADIO RADIO RECEPTION 1. Press POWER to on position. 2. Press TUNER source button. – The TUNER indicator lights up. 3. Adjust BAND to select the desired FM/ AM waveband. 4. Tune to a radio station using the tuning knob. –...
- Page 7 CD PLAYER Playing a CD 1. Press POWER to on position. 2. Press CD source button. – The CD indicator lights up. 3. To open the CD door, press OPEN on the CD door. 4. Insert a CD with the printed side facing up and press the CD door gently to close.
- Page 8 Different play modes : Shuffle and Repeat The SHUFFLE and REPEAT buttons allow you to select various play modes. The modes can be selected or changed during playback. SHUFFLE - all tracks are played in random order REPEAT - plays the current track continuously REPEAT ALL - repeats the entire CD 1.
-
Page 9: Cassette Recorder
CD PLAYER Programming track numbers You may store up to 20 tracks in the desired sequence. If you like, store any track more than once. 1. In the stop position, press SEARCH ¡ or ™ for your desired track. 2. When your chosen track number appears, press PROG once to store the track. -
Page 10: General Information On Recording
CASSETTE RECORDER Continuous Playback 1. Repeat steps 1 - 4 above, but load both decks. Press PLAY 2 on deck 2 and deck 2 will start. 2. Press PAUSE ; on deck 1 and then PLAY 2. As soon as deck 2 stops (end of tape or STOP/EJECT 9 / pressed), PAUSE ;... - Page 11 RECORDING Recording from the radio 1. Press TUNER source button. 2. Tune to the desired radio station (See ‘RADIO RECEPTION’). 3. Press STOP/ EJECT 9/ to open the cassette holder. 4. Insert a blank tape and close the cassette holder. 5.
-
Page 12: Maintenance
PRECAUTIONS AND SYSTEM MAINTENANCE • Place the set on a hard, flat surface so that the system does not tilt. • Do not expose the set, batteries, CDs or cassettes to humidity, rain, sand or excessive heat caused by heating equipment or direct sunlight. -
Page 13: Troubleshooting
TROUBLESHOOTING If a fault occurs, first check the points listed below before taking the set for repair. If you are unable to remedy a problem by following these hints, consult your dealer or service center. WARNING: Do not open the set as there is a risk of electric shock. Under no circumstances should you try to repair the set yourself, as this would invalidate the guarantee.
