Philips AZ1316/37B Quick Use Manual

Quick Use
Quick Use
Guide
Guide
AZ1316
1
Choosing Power Supply
a Connect the AC power cord to the
AC Mains inlet and the wall socket.
-OR-
b Open the battery door and insert
6 x C batteries .
(not included)
2
Listening to the Radio
a Push the source selector to
AM or FM.
b Press and hold PROG unti
l
AutO flashes.
3a
• Available stations are
programmed.
4a
c Press ALBUM/ PRESET -, +
3,4
(on the remote control )
until the desired preset station is
3d
displayed.
3e
3
Playing a disc
This player plays Audio Discs
including CD-R/CD-RW, and
MP3-CD.
IMPORTANT: For a disc with CD
Audio tracks and MP3 files, the
MP3 files may be unplayable,
depending on the encoding
software..
a Adjust the source selector to
CD/MP3.
b Press OPEN•CLOSE to open
the disc door.
c Insert a disc with the printed
side facing up and close the
door.
38
d Press to start playback.
e To stop disc playback, press 9.
1b
R-14, UM-2 or C-cells
(not included)
2a
4b
3b
4e
2b
4d
2c
4
Playing a tape
a Adjust the source selector to TAPE/OFF.
b Press 9/ to open the cassette holder.
c Insert a cassette and close the door.
1
d Press to start playback.
9/
e To stop the tape, press .
Telescopic antenna
Improves FM reception.
Source selector
Slide to select function:
CD/MP3, radio (AM,
1a
FM) or tape.
∞ §
Skips & searches CD
tracks backwards/
forwards;
Tunes to radio stations
(down/up).
DBB
Press to turn the bass
enhancement on/off.
38
Press to start or
pause disc play-
back.
9
Press to stop disc
playback or erase a
disc program.
Display
Shows disc functions
CASSETTE
RECORDER keys
Press to operate a tape.
OPEN•CLOSE
Press to open/close the
disc door.
MODE
Press to select different
play modes, such as
REPEAT or SHUFFLE
(random order)
PROG
Use to program CD
tracks or preset radio
stations.
VOL 3 , 4
Press to adjust volume
level.
ALBUM/ PRESET -, +
Press to select an album.
(MP3 only);
Press to select a preset
radio station.
REMOTE CONTROL
Insert 2 batteries,
type AAA, R03 or
UM4 (not included)
