- Page 1 DAB CD Soundmachine AZ6000 User manual...
- Page 2 Important notes for users in the U.K. Mains plug This apparatus is fitted with an approved 13 Amp plug. To change a fuse in this type of plug proceed as follows: Remove fuse cover and fuse. Fix new fuse which should be a BS1362 5 Amp, A.S.T.A.
- Page 3 7 8 90! &...
-
Page 4: Table Of Contents
CD player and CD handling ...18 Troubleshooting ...19 ...5 ...8 ...8 ...14 ...16 ...17 This set complies with the radio interference requirements of the European Union PHILIPS reserves the right to make design and specification changes for product improvement without prior notice. -
Page 5: General Information
ABOUT DIGITAL AUDIO BROADCASTING (DAB) DAB digital radio is a new way of broadcasting radio via a network of terrestrial transmitters. It provides listeners with more choice and information delivered in crystal clear, crackle-free sound quality. – The technology allows the receiver to lock on to the strongest signal it can find. –... -
Page 6: Controls
CONTROLS TOP AND FRONT PANEL 1 OPEN•CLOSE - press to open/close CD door. 2 p - 3.5 mm stereo headphone jack Helpful hints: The speakers will be muted when headphones are connected to the set. 3 LINE IN - 3.5mm LINE-IN jack for external audio appliance 4 STANDBY ON y - power on/ off switch 5 DAB MENU - enables access to advanced... -
Page 7: Power Supply
SUPPLIED ACCESSORIES – AC mains lead – Remote control MAINS SUPPLY Whenever convenient, use the mains supply to conserve battery life. Make sure you remove the power plug from the set and wall socket before inserting batteries. BATTERIES (NOT INCLUDED) Main set •... -
Page 8: Basic Functions
BASIC FUNCTIONS SWITCHING ON/OFF AND SELECTING FUNCTION 1. Press STANDBY ON y to switch on. 2. Press Source selector once or more to select: CD, DAB, FM (or CD, FM, DAB on the remote control) . 3. Press y to switch off the set. Helpful hints: –... -
Page 9: Dab Radio
DAB RECEPTION 1. Press STANDBY ON y to on, then press Source selector to select DAB (or press DAB on the remote control). Display shows Welcome to Digital Radio, followed by and/or The list of available stations is created/restored, and the set tunes to the last station detected / selected. -
Page 10: Tuning/Retuning
DAB RADIO TUNING / RETUNING AUTOSCAN Autosan local - scans all the UK frequencies (in default setting) Autosan full - scans Band III frequencies. To start Autoscan local, briefly press SMART SCAN. • To start Autoscan full, press and hold SMART SCAN until •... -
Page 11: Selecting A Station
SELECTING A STATION After your DAB has been tuned, you can select a station using the Navigation controls. 1. Push left/right 1,2 once or more (or 5, 6 on the remote control) to scroll the list of stored stations. 1st display line: current station you are tuning to. 2nd display line: station name changes as you scroll through the list. -
Page 12: Saving Presets
DAB RADIO SAVING PRESETS You can store up to 10 DAB radio stations in the memory, manually or automatically (Autostore) AUTOSTORE Automatic programming will start from preset 1. It allows you to save your favorite stations as presets. 1. Sort the list of available stations by Fav station (See Fav station, SORTING STATIONS). -
Page 13: Recalling A Preset
RECALLING A PRESET 1. Press PRESET 3,4 (or PRESET -, + on the remote control) once or more to find your desired preset. Display shows: current station name at the top display line and available presets at the bottom. 2. Press ENTER to confirm. Your desired preset radio station plays. -
Page 14: Sorting Stations
DAB RADIO SORTING STATIONS By sorting stations, you can define in what order the available stations are listed when the DAB is tuned. 1. Press DAB MENU (or MENU on the remote control). 2. Push left/right 1,2 (or 5, 6 on the remote control) and press ENTER to select Station order. -
Page 15: Fm Tuner
TUNING TO FM STATIONS 1. Press y to on, then press Source selector to select FM. (or FM on the remote control) ™ FM is displayed and then the radio station frequency and, if programmed, a preset number are shown. ™... -
Page 16: Cd Player
CD PLAYER PLAYING A CD This CD player plays Audio Discs including CD-Recordables and CD-Rewritables. 1. Press y to on, then Source Selector to select CD. 2. Insert a CD with the printed side facing up and close the CD door. is displayed as the CD player scans the contents of a disc, and then the total number of tracks and playing time are shown. -
Page 17: Programming Track Numbers
PROGRAMMING TRACK NUMBERS You can store up to 20 tracks in the desired sequence. If you like, store any track more than once. 1. In the stop position, press PROG to activate programming. Display shows Tr1 P-01, indicating the start of the program. -
Page 18: Aux
AUX/MAINTENANCE AUX (Audio cable not included) This 3.5mm socket allows you to connect other audio equipment to your system e.g. a MP3-CD player. 1. Use an audio cable to connect the LINE IN socket to the LINE OUT/headphone socket on your external equipment. Display shows Playback of CD, DAB or FM source stops automatically. -
Page 19: Troubleshooting
If a fault occurs, first check the points listed below before taking the set for repair. If you are unable to remedy a problem by following these hints, consult your dealer or service centre. WARNING: Do not open the set as there is a risk of electric shock. Under no circumstances should you try to repair the set yourself, as this will invalidate the guarantee. -
Page 20: Class 1 Laser Product
Meet Philips at the Internet http://www.philips.com AZ 6000 CLASS 1 LASER PRODUCT Printed in China AL/JW-424-01...
