Summary of Contents for BlokCam X2
- Page 1 X2 Installation and User Manual V1.0.3 ®...
-
Page 2: Table Of Contents
Viewing & Downloading the Recordings Viewing & Downloading the Screenshots Logging Out & Disconnecting the Laptop Logging In Accessories Office Link VC4 - V-Cam VC4a - V-Cam (Audio) FS1 - Footswitch BlokCam ® X2 Installation and User Manual V1.0.3 Issue Date 01/06/2018... -
Page 3: Remarks
Remarks 1. Always adhere to the crane manufacturer’s instructions. BlokCam ® is a wireless system that can be quickly and easily deployed to the hook block or boom tip of a crane. The sound and view from below the camera is then transmitted and 2. -
Page 4: What's Included
1 x Magnetic Ram Mount with 1.5” Ball • 1 x Ram Mount Arm - Double Socket Arm • 1 x Ram Mount with U-Bolts • 1 x Ram Mount with Strap Base BlokCam ® X2 Installation and User Manual V1.0.3 Issue Date 01/06/2018... -
Page 5: Technical Information
Operating Conditions: -20 °C to 60 °C (-4 °F to 140 °F) Humidity 10-85% RH (non-condensing) Storage Conditions: -40 °C to 65 °C (-40 °F to 149 °F) IP Rating: IP 67 (with external ports connected) BlokCam ® X2 Installation and User Manual V1.0.3 Issue Date 01/06/2018... -
Page 6: B4 - Battery
Storage Conditions: -40 °C to 90 °C (-40 °F to 194 °F) MSDS: available from www.blokcam.com Humidity Max 90% (non-condensing) IP Rating: IP 67 (with external ports connected) IP Rating: IP 67 (with external ports connected) BlokCam ® X2 Installation and User Manual V1.0.3 Issue Date 01/06/2018... -
Page 7: P2 - Processor
Operating Conditions: 0 °C to 40 °C (32 °F to 104 °F) Humidity up to 10% to 90% (non-condensing) Storage Conditions: -40 °C to 70 °C (-40 °F to 158 °F) Humidity 5% to 90% (non-condensing) BlokCam ® X2 Installation and User Manual V1.0.3 Issue Date 01/06/2018... -
Page 8: M2 - Monitor
Depth: 161mm (6.34 inches) Weight: 3800g (8.38 pounds) Casing: Plastic Power: 12Vdc 3.3A - Provided by Processor Operating Conditions: -20 °C to 60 °C (-4 °F to 140 °F) BlokCam ® X2 Installation and User Manual V1.0.3 Issue Date 01/06/2018... -
Page 9: System Configuration
System Configuration Foreword BlokCam ® X2 Crane Camera is a modular system. The required set up and installation are dependent on the machine and the environment. The following characterise the most common crane installations Luffing Flat Top Telescopic BlokCam ® X2 Installation and User Manual V1.0.3... -
Page 10: Installation
7. Choke and secure a lanyard to a fixed and secure point. 8. Attach the loose end of Lanyard to the Quick Link. 9. Firmly tighten the Quick Link. When necessary reverse the above steps for removal. × × BlokCam ® X2 Installation and User Manual V1.0.3 Issue Date 01/06/2018... -
Page 11: Mount, Connect & Secure The Sensor
7. Choke and secure a lanyard to a fixed and secure point. 8. Attach the loose end of lanyard to the Quick Link. 9. Firmly tighten the Quick Link. When necessary reverse the above steps for removal. BlokCam ® X2 Installation and User Manual V1.0.3 Issue Date 01/06/2018... -
Page 12: Mount & Secure The Repeater/S
1. Fit 1 x Lan Port Blanking Plug to the LAN Port Socket. Always adhere to correct antenna alignment. Duck Bill 2. Mount, connect and secure the BlokCam ® Battery as Antennas are omni directional. For best performance, the instructed on page 11. -
Page 13: Position And Connect The Processor
1. Attach the best suited RAM Mount, Ball Joint Bracket to a the monitor position; fixed and secure point. If the supplied brackets are not the distance to the Monitor. suitable please seek advice from an authorised BlokCam ® dealer. Systems with... -
Page 14: Battery Charging Instructions
Battery Charging Instructions Operating Instructions Foreword Foreword The BlokCam ® X2 camera system runs on a non-hazardous Operation is reliant on correct installation, charged batteries battery. Under normal operating conditions each battery should and/or reliable power source. provide approximately 12 hours of use. Certain operating conditions will decrease the standard runtime of the battery, 1. -
Page 15: Accessing & Downloading Saved Data
Octet must be identical for connectivity across all paired units. The forth Octet must be unique to avoid conflicting Foreword IP Addresses. To access and download saved data, ensure the BlokCam ® system and components are installed correctly and fully IPv4 Octet... -
Page 16: Set Up The Video Management Software
7. Select ‘Next’. 3. Choose and type your preferred site name into the ‘Site name’ box. 4. Obtain the Site password from an authorised BlokCam ® dealer. Do not create a password. Creating a password will lead to system failure. - Page 17 12. 13. Select ‘Next’. 9. If the desired camera is not automatically discovered, obtain the cameras IP Address from an authorised BlokCam ® dealer and add the camera manually. 10. Type the procured IP Address into the ‘Enter camera address’...
- Page 18 15. Select ‘Finish’ on the ‘Ready to install’ page. 16. Wait until the VMS installs the selected camera/s. BlokCam ® X2 Installation and User Manual V1.0.3 Issue Date 01/06/2018...
-
Page 19: Selecting The Storage Location
2. Select ‘Customize’ on the ‘Go to Configuration’ Screen. 7. Repeat steps 3 – 6 for the ‘Recordings’ section. 3. Under the heading ‘Snapshot folder’ locate and select ‘Browse…’. 4. Select the desired storage location. BlokCam ® X2 Installation and User Manual V1.0.3 Issue Date 01/06/2018... -
Page 20: Viewing & Downloading The Recordings
For speed and storage reasons, please keep the download duration to a minimum. 10. Repeat Steps 1 – 9 to extract more recording intervals if required. BlokCam ® X2 Installation and User Manual V1.0.3 Issue Date 01/06/2018... -
Page 21: Viewing & Downloading The Screenshots
9. Exit Investigation mode using the ‘X’ at the top right of the 4. Locate the required image and select the ‘Investigation ‘Investigation Mode’ page. Mode’ icon on the bottom right of the VMS screen. BlokCam ® X2 Installation and User Manual V1.0.3 Issue Date 01/06/2018... -
Page 22: Logging Out & Disconnecting The Laptop
Insert a suitable tool (not supplied) into the cable release port, push the patch cable latch and simultaneously disconnect the Cat5e RJ45 Patch Cable from the Processor. 6. Select ‘LOG IN’. BlokCam ® X2 Installation and User Manual V1.0.3 Issue Date 01/06/2018... -
Page 23: Accessories
When necessary reverse the above steps for removal. Overview BlokCam Office Link allows the data from your BlokCam to be captured in a site office for site and crane monitoring and surveillance. Your host computer could monitor and record data from multiple systems. -
Page 24: Vc4A - V-Cam (Audio)
Overview The Versatile-Cam is our hardwired option which gives you the ability to expand your BlokCam ® system to include additional Sensors. The build quality of the VC4 coupled with its non- intrusive size and mounting versatility means it can be deployed in seconds and used in a multitude of scenarios. -
Page 25: Fs1 - Footswitch
5. Install and secure the sensor as instructed on page 11. When necessary reverse the above steps for removal. 6. Ensure the sensor cable does not limit or dictate the rotation of the Pendulum. BlokCam ® X2 Installation and User Manual V1.0.3 Issue Date 01/06/2018... - Page 26 The above images show the Transmitter BlokMag ® BM1-X) configured for installation on a cylindrical surface. The below images show the Transmitter BlokMag ® BM1-X) configured for installation on a spherical surface. 112.5 157.5 BlokCam ® X2 Installation and User Manual V1.0.3 Issue Date 01/06/2018...
- Page 27 6. Attach the loose end of lanyard to the Quick Link. 7. Firmly tighten the Quick Link. 8. Refer to the installation guide for the mating Transmitter, Sensor and/or Battery. When necessary reverse the above steps for removal. BlokCam ® X2 Installation and User Manual V1.0.3 Issue Date 01/06/2018...
- Page 28 BlokCam Ltd ® Unit 5 Sidings Court Priory Park East Hull East Yorkshire HU4 7DY United Kingdom +44 1482 351546 uk@blokcam.com BlokCam ® X2 Installation and User Manual V1.0.3 Issue Date 01/06/2018...
