- Page 1 mini hifi system FW890P 5 speaker dolby pro logic 3139 116 18731...
-
Page 2: How To Connect Plug
Copyright Act 1956 and The Performer’s Protection Acts 1958 to 1972. Italia DICHIARAZIONE DI CONFORMITA’ Si dichiara che l’apparecchio FW890P Philips risponde alle prescrizioni dell’art. 2 comma 1 del D.M. 28 Agosto 1995 n. 548. Fatto a Eindhoven , il 15/04/1999... - Page 3 INDEX English ...5 Français ...29 Español ...55 Deutsch ...81 Nederlands ...109 Italiano ...135 Svenska ...161 Dansk ...185 Suomi ...211 Português ...235 ∂ÏÏËÓÈο ... 261 CLASS 1 LASER PRODUCT 3139 116 18731...
- Page 4 3139 116 18731...
-
Page 5: Table Of Contents
CONTENTS GENERAL INFORMATION General Information General Information ... 5 • The typeplate (which contains the Safety Information ... 5 serial number) is located at the rear of the system. Preparation ... 6 - 7 • Recording is permissible if Dolby Pro Logic ... 8 - 9 copyright or other rights of third parties are not infringed. -
Page 6: Preparation
PREPARATION Rear Connections STANDBY ON CUT OFF FREQUENCY HIGH POWER SUBWOOFER 60Hz 150Hz surr. surr. MAINS surr. surr. AUDIO OUT DIGITAL SURROUND SUB- WOOFER AUX/CDR IN LINE OUT FM ANTENNA 75 AM ANTENNA – REAR SURROUND FRONT – – – –... -
Page 7: Center Speaker
D Rear Speakers’ Connection G Connecting other equipment to your system Connect the black (non-marked) wires to the black REAR SURROUND terminals and You can connect the audio left and right the white (marked wires) to the grey REAR OUT terminals of a TV, VCR, Laser Disc SURROUND terminals. -
Page 8: Dolby Pro Logic
DOLBY PRO LOGIC • Rear (surround) speakers: Connect Dolby Pro Logic This state of the art Dolby Pro Logic mini system enables you to experience and enjoy a Home Cinema sound ambience. The Pro Logic system allows more accurate definition of the individual sound sources. It produces greater sound separation between channels and provides pinpoint sound localization. - Page 9 When you have completed the Dolby Pro Dolby Center Phantom Logic setup, you are ready to enjoy Home This setting is for use without the center Cinema sound. speaker. It redistributes the center speaker • Press DPL (PRO sound to the left and right speakers, LOGIC) repeatedly to providing conventional stereo across the select and cycle through...
-
Page 10: Controls
CONTROLS DISC CHANGE MINI HIFI SYSTEM STANDBY CLOCK/ TIMER PROG ¤ ⁄ OPEN•CLOSE DISC 1 DISC 2 DISC 3 C H A N G E R PRO LOGIC TUNER TAPE C D 1 • 2 • 3 BAND TAPE 1 • 2 A.REV SEARCH •... - Page 11 – to store and confirm the personal Controls on the system and equalizer setting. remote control 9 CLOCK/TIMER 1 STANDBY ON – to view the clock, set the clock or set – to switch the system on or to standby the timer.
-
Page 12: Operating The System
CONTROLS § MIC ‹ REPEAT – to connect microphone jack. – ≥ VOLUME › BALANCE L/R – to adjust the volume. • OPEN – – to open tape deck 2. ª TAPE DECK 2 fi REAR +/- º INTERACTIVE SOUND STUDIO –... - Page 13 To start the demonstration mode • When searching RDS time; • Press and hold Ç (on the system only) ™ “SEARCH RDS TIME” will be for 5 seconds when the system is in displayed. ™ When RDS time is read, “RDS standby mode.
- Page 14 OPERATING THE SYSTEM You can change the digital sound setting Sound Control level for all except CLASSIC with the JOG. VOLUME ADJUSTMENT • First select the DSC feature, then rotate Adjust VOLUME to increase or decrease the sound level. For Personal Listening Connect the headphones plug to the n socket at the front of the system.
- Page 15 HOLD 5 Press ENTER to confirm the store location. This feature allows you to simulate the sound effect like scratching a vinyl LP • Repeat 1 – 5 to adjust the other record and is only applicable during CD personal settings. play mode.
- Page 16 DISC CHANGE DISC 1 DISC 2 MINI HIFI SYSTEM STANDBY CLOCK/ TIMER TUNER TAPE PROG C D 1 • 2 • 3 BAND TAPE 1 • 2 SEARCH • TUNING STOP • CLEAR PLAY • SIDE SURF PERSONAL INTERACTIVE SOUND STUDIO Warning! You may load three discs in the CD 1) This system is designed for...
- Page 17 • If you press í once it will skip to the Disc Change beginning of the current track and play You can change the outer two discs while the track again. the third inner disc is stopped or is playing. 1 Press DISC CHANGE.
-
Page 18: Tuner
Shuffle Repeat (only on remote control) In shuffle mode, the system plays all the You can play the current track, a disc or all available discs and their tracks in random available discs repeatedly. order. Shuffle may be used also when 1 Press REPEAT on the remote control tracks are programmed. -
Page 19: Station Name
™ The system will search for every 4 Press TUNING à or á to tune to the available station in the FM waveband desired frequency. first, then search by the MW and LW • If you wish to store the radio station to wavebands. - Page 20 TUNER News/TA (Traffic Announcement) (only available in Radio Station with RDS) You can activate NEWS or TA function in Standby, Demonstration or any source mode except Tuner mode. Once the News • When NEWS/TA transmission is Program Type (for NEWS function) or Traffic Announcement data (for TA function) is detected in any of the selected RDS stations, it will switch to TUNER mode...
-
Page 21: Tape
MINI HIFI SYSTEM STANDBY CLOCK/ TIMER TUNER TAPE TAPE 1 • 2 PROG C D 1 • 2 • 3 BAND SEARCH • TUNING STOP • CLEAR PLAY • SIDE SURF STROBE PERSONAL HOLD INTERACTIVE SOUND STUDIO Loading a tape •... -
Page 22: Aux/Cdr
TAPE During playback Dolby B Noise Reduction • Press and hold à or á until the System desired passage is located. 1 Press DOLBY B NR to switch on Dolby ™ During searching, the sound is reduced to a low volume. ™... -
Page 23: Recording
MINI HIFI SYSTEM STANDBY CLOCK/ TIMER TUNER TAPE PROG C D 1 • 2 • 3 BAND TAPE 1 • 2 A.REV SEARCH • TUNING STOP • CLEAR PLAY • SIDE PRESET SURF STROBE PERSONAL HOLD INTERACTIVE SOUND STUDIO SWITCH OFF DOLBY PRO LOGIC WHEN RECORDING Notes: –... - Page 24 RECORDING – You can listen to another source while Dubbing tapes (from tape deck 1 to tape deck 2) – Dolby NR button has no influence during 1 Press TAPE ( TAPE 1•2 ) to select tape deck 2. 2 Load the prerecorded tape into tape deck 1 and a blank tape into tape deck ™...
-
Page 25: Clock
CLOCK MINI HIFI SYSTEM STANDBY CLOCK/ TIMER TUNER TAPE PROG CD1 • 2 • 3 BAND TAPE 1 • 2 SEARCH • TUNING STOP • CLEAR PLAY • SIDE SURF STROBE PERSONAL HOLD INTERACTIVE SOUND STUDIO Viewing the Clock Setting the Clock You can view the clock (if it is set) while The clock is set in 24-hour mode, e.g. -
Page 26: Sleep Timer
CD lens. To ensure mode. good playback quality, clean the CD lens with Philips CD Lens Cleaner or any commercially available cleaner. Follow the instructions supplied with cleaner. "OFF" is displayed, or press the Cleaning the Heads and the Tape Paths STANDBY ON button. -
Page 27: Specifications
Specifications AMPLIFIER Output power DPL Mode Left/Right Channel ... 2 x 240 W MPO / ... 2 x 120 W RMS Center Channel ... 80 W MPO / 40 W RMS, 12 Surround Channel ... 2 x 40 W MPO / ... -
Page 28: Troubleshooting
TROUBLESHOOTING Warning! Under no circumstances Radio Reception you should try to repair the set yourself Poor radio reception. as this will invalidate the guarantee. • The signal is too weak. Do not open the set as there is a risk of ™...
