Note - Notes
®
192HR23S5A1_HR23S5_ IV
Manuale d'uso, manutezione
e parti di ricambio Parte 2
Use, maintenance
and spare parts manual Part.2
23
Misure impiegabili mm (inch)
( 7/8")
Usable lenghts mm (inch)
Capacità caricatore n° punti
130
Magazine capacity No. of fasteners
5÷7
Pressione d'esercizio bar (psi)
(70÷100)
Working pressure bar (psi)
Consumo aria litri/colpo a 6 bar
1,50
Air consumption litres/shot at 6 bar
Peso kg
1,43
Weight kg
Dimensioni (AxBxH) mm
198x91x340
Dimensions mm
EN 12549:1999
ISO 11201:1995
Pressione sonora in posizione operatore
84 dBA
Max A-Weighted pressure level at operator's position
EN 12549:1999
ISO 3744:1994
Potenza sonora emessa
94 dBA
Max A-Weighted sound power level
ISO 8662-11:1999
Vibrazione
< 2,5 m/s
Vibration
omer
s.p.a.
Via Foresto, 42 - 31058 SUSEGANA (TV) ITALY
Tel. 0438 455 318
HR23 S5
cod. 192HR23S5A1
Indice di modifica
Upgrade number
33 mm
HR23
1,80
23
Gauge: 15
2
Fax 0438 455 530
e-mail: omer@omer.it
A1
7,9 ÷ 10,7
www.omer.it
