- Page 1 Register your product and get support at MCD120 www.philips.com/welcome User manual ZH-TW...
-
Page 2: Table Of Contents
Contents 1 Important Safety Notice Trademark notice 2 Your DVD Micro Theater Introduction What’s in the box Overview of the main unit Overview of the remote control 3 Connect Place the unit Connect speakers Connect TV Connect power 4 Get started Prepare the remote control Turn on Find the correct viewing channel... -
Page 3: Important
1 Important Safety Know these safety symbols CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN AVIS NE PAS OUVRIR RISQUE DE CHOC ELECTRIQUE This ‘bolt of lightning’ indicates uninsulated material within your unit may cause an electrical shock. For the safety of everyone in your household, please do not remove product covering. -
Page 4: Notice
Notice device that are not expressly approved by Philips Consumer Lifestyle may void the user’s authority to operate the equipment. This product complies with the radio interference requirements of the European Community. -
Page 5: Trademark Notice
Environmental information All unnecessary packaging has been omitted. We have tried to make the packaging easy to separate into three materials: cardboard (box), polystyrene foam (buffer) and polyethylene (bags, protective foam sheet.) Your system consists of materials which can be recycled and reused if disassembled by a specialized company. -
Page 6: Your Dvd Micro Theater
2 Your DVD Micro Theater Congratulations on your purchase, and support that Philips offers, register your product at www.philips.com/welcome. Introduction With this unit, you can: watch video from DVD/VCD/SVCD or USB devices enjoy audio from discs or USB devices view pictures from discs or USB devices... -
Page 7: Overview Of The Main Unit
Overview of the main unit Turn on the apparatus; switch to standby mode. Open or close the disc compartment. c Disc compartment d Display panel Display current status. e Remote control sensor USB socket. g VOLUME -/+ Adjust volume. Stop play. Start or pause play. -
Page 8: Overview Of The Remote Control
Overview of the remote control Turn on the apparatus; switch to standby mode. b Disc/USB Select a source. Skip to the next track, title, or chapter. Stop play. e OK / / / For menus: navigate up/down/left/ right. Pan through an enlarged picture. f SUBTITLE Select a subtitle language. -
Page 9: Connect
3 Connect Place the unit Place the unit near to the TV. Place the left and right speakers at equal distance from the TV and at an angle of approximately 45 degrees from the listening position. Note To avoid magnetic interference or unwanted noise, never place this apparatus and speakers too close to any radiation devices. -
Page 10: Connect Audio Cables
Option 2: Connect through component video Connect a progressive scan TV through component video for higher quality video. Note The progressive scan video quality is only available when a progressive scan TV is connected. If your TV does not support progressive scan, you cannot view the picture. -
Page 11: Connect Power
Connect power Caution Risk of product damage! Ensure that the power supply voltage corresponds to the voltage printed on the back or the underside of the unit. Before connecting the AC power cord, ensure you have completed all other connections. Connect the AC power cord to the wall socket. -
Page 12: Get Started
Always follow the instructions in this chapter in sequence. If you contact Philips, you will be asked for the model and serial number of this apparatus. The model number and serial number are on the bottom of the apparatus. Write the numbers here: Model No. -
Page 13: Change System Menu Language
[NTSC] For TV with NTSC color system. [PAL] For TV with PAL color system. [AUTO] For TV with multiple color systems. Press SETUP to exit. Change system menu language Press SETUP. Press / keys to select [LANGUAGE SETUP] page, and then press . Press to highlight an option, and then press... -
Page 14: Play
5 Play Note Play a disc Caution Never look at the laser beam inside the unit. Risk of product damage! Never play discs with accessories such as disc stabilizer rings or disc treatment sheets. Never put any objects other than discs into the disc compartment. -
Page 15: Play From Usb
Play from USB Note Ensure that the USB device contains playable music, pictures or video. Insert the USB device. Press DISC/USB to select the USB source. » Content menu of the USB source appears. Press / / / to select a folder and press OK. -
Page 16: Play Options
Search forward/backward During play, press and hold select a speed for fast search backward/ forward. To resume play at normal speed, press Fast search forward/backward is available only within the same track. Search by time or chapter/track number During video/audio play, press DISPLAY. »... -
Page 17: Adjust Settings
6 Adjust settings Press SETUP. / to navigate in the menu. Select a setting and then press OK. To exit the menu, press SETUP. Note Some of the features in the SETUP Menu Options are described in “Get Started”. System Setup On the [SYSTEM SETUP] page, you can set the following options: [TV SYSTEM]... -
Page 18: Language Setup
Go to [PASSWORD] to enter the preset password. Go to [RATING] and press . Select a rating level, and then press OK. Use the numeric buttons (0-9) to enter a password for this disc. Rating explanations [1 KID Kids material; recommended SAFE] especially for children and viewers of all ages. -
Page 19: Playable Discs
7 Product information Note Product information is subject to change without prior notice. System Power supply 110 - 240 V~, 50/60 Power consumption < 15 W Power consumption < 2.5 W in standby mode Output power 2 x 10 W USB Direct Version 2.0 Frequency response... -
Page 20: 8 Troubleshooting
If you encounter problems when using this apparatus, check the following points before requesting service. If the problem remains unsolved, go to the Philips web site (www. Philips.com/support). When you contact Philips, ensure that the apparatus is nearby and the model number and serial number are available. - Page 21 Black and white or distorted picture The disc does not match the TV color system standard (PAL/NTSC). Sometimes a slight picture distortion may appear. This is not a malfunction. Clean the disc. A distorted picture may appear during progressive scan setup. The aspect ratio of the TV screen cannot be changed even though you have set the TV display format.
- Page 23 If you require assistance with the operation of the product, its features or specifications, you may call the Philips Technology Care Centre on 1300 363 391 where support is provided by our trained staff. If the product fails within 12 months from the date of purchase, please return the faulty product to the place of purchase.
- Page 24 © 2010 Koninklijke Philips Electronics N.V. All rights reserved. MCD120_79_96_UM_V2.0...
